LUMIEN CORE Instruction Manual

WARNING – To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before replacing lamp.
• Lamp gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the hot lens, guard, or enclosure.
• Keep lamp away from materials that could burn.
• Do not touch the lamp at any time. Use a soft cloth. The oils from skin could damage lamp.
• Do not operate the fixture with a missing or damaged shield.
WARNING – Risk of Electric Shock:
• Install all luminaires at least 10 feet (3.05 m) from a pool, spa, fountain, etc.
• A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.

IMPORTANT:

DO NOT EXCEED 15 VOLTS IN THIS FIXTURE!
This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range could damage the
fixture, shorten the life, and cause unsatisfactory performance. The use of improper voltage voids the product warranty.
Lumien Lighting | Website: www.lumienlighting.com | E-mail: orders@lumienlighting.com
INSTRUCTION MANUAL
Integrated LED
(

MODELS

CORE
RGBWW PRO
)
Brass
W4B4
W9B4
Wattage CORE: 2.5W
PRO: 2.5W
Voltage Range 10-15V
Lumen Output CORE: 110 Lumens
PRO: XXX Lumens
Color Temp 3000K, 2700K RGBWW
CRI 80+
Lifespan 50,000 Hrs.
Finishes Antique
Housing Material Brass
Wet Rated? Yes
Light Source Modular LED
