TEMPERATURE CHANNEL SETUP
Changing System Labels
The M2 allows the user to change the labels that are displayed above each channel. Each channel can have a maximum of 16 characters however in
the summary screens only the first 11 or 12 characters of the channel label are displayed.
Changing Label Names
To change the name of a temperature channel, follow the instructions below:
1. Navigate to the setup menu for the desired temperature channel. Menu->Setup->Temp. 1 Setup.
2. In the battery setup menu, move the cursor to temperature channel name to be changed (indicated by the >> symbol).
3. Press Select to enter the name editing mode.
4. Use the LEFT ← ← and RIGHT → → arrow buttons to move the cursor over the characters.
5. When the cursor is over a character, press Enter to edit that character. The cursor will start blinking.
6. Use the UP ↑ ↑ and DOWN ↓ ↓ arrow buttons to select a new character and press Ok to set that character.
7. Once all desired characters have been changed, press the Cancel button to exit the name editing mode.
Note: Although the maximum label length is 14 characters, some screens may only be able to display the first 5 or so characters.
Additional Temperature Settings
The meter provides custom settings for each temperature input. To access these settings, first go to the Setup menu.
Scroll to the desired temperature channel.
The temperature setup settings are described below. To make a change, scroll to setting and press Enter. Press the LEFT ← ← or RIGHT → → arrow
buttons to view the available setting options. Press Enter to save the setting. Press Cancel to cancel a change.
Enable
To display the temperature and its measurements, change this setting to ON. If enable is OFF, the temperature along with its measured
values will not be displayed.
However, any associated alarm or relay settings are still activate. To deactive the alarm or relay, disable them in the Alarm Setup
and Relay Setup menus.
Min/Max Reset
Resets the minimum and maximum values for the temperature channel.
Graph Hi/Graph Lo
On the graphical summary screens, set the highest and lowest value on the graph. For example, if we were monitoring our ice box temperature, we
might want to have the maximum temperature displayed at 50°F and the minimum value set to 30°F.

VERSION INFO

The Version Info option in the Setup menu displays the product name, serial number, and software version. This information will be displayed on a
screen after scrolling to Version Info and pressing Select. Pressing any button will return to the Setup menu.

FACTORY RESET

The Factory Reset option in the Setup menu allows the user to restore the meter's factory default settings. First scroll to Factory Reset and press
Select. Text will appear asking to confirm or cancel the reset request. Press Yes to confirm or No to cancel the reset.
WRITE CONFIG
Save a configuration file storing all of the meters current settings to a USB thumb drive. File will be saved as Config_BSSXXXX.bcf, where XXXX is the
model number of the meter, e.g. Config_BSS1830.bcf
