Model
(W/mW)
Transmit Power
(dBm)
Max Receiver Sens-
itivity (dBm)
Overload Power
(dBm)
Extinction Ratio
(dB)
Operating Case
Temperature
Hot-swappable

QSFP+ Port

The modules supported by SG-6000 X series (IOM-2Q8SFP+ -200, IOM-2Q8SFP+, IOM-P40-
300, and SIOM-P40-300) are designed with two 40GE(QSFP+) ports.
Table 2-57 Table: QSFP+ Port Attribute
Attribute Description
Connector QSFP+
Type
Frame Format Ethernet_II
Ethernet_SNAP
110
TRAN-XFP-SR TRAN-XFP-LR
-2.8～-1.5 -6.0～-1.0
-7.5 -10.3
0.5 0.5
3.0 6
-5ºC-70ºC -5ºC-75ºC
Yes Yes
TRAN-XFP- TRAN-XFP-
LX40 LX80
-1.0～+2.0 0～+4.0
-11.3 -22.5
2.0 4.0
8.2 9.0
-5ºC-75ºC 0ºC-70ºC
Yes Yes
