FUSES

(1/3)
1
A
Fuse boxes
If any electrical component does not
work, check the condition of the fuses.
Passenger compartment fuses A
Unclip the access flap 1.
To comply with current legislation, or
as a precaution, you can obtain an
emergency kit from your approved
dealer containing a set of spare
bulbs and fuses.
B
2
Fuses located in the passenger
compartment behind a flap in the B
glovebox
Unclip the access flap 2.
Check the fuse in question
and replace it, if neces-
sary, by a fuse of the same
rating.
If a fuse is fitted with too high a
rating, it may cause the electrical
circuit to overheat (risk of fire) in the
event of an item of equipment using
an excessive amount of current.
C
Tweezers 3
Remove the fuse using the tweezers 3
on the back of the flap.
To remove the fuse from the tweezers,
slide the fuse to the side.
It is not advisable to use the free fuse
locations.
Note: Tweezers 3 is located on the
back of flap 1.
3
