DRIVER'S HANDBOOK

Advertisement

   Also See for Renault Captur

   Summary of Contents for Renault Captur

  • Page 1

    CAPTUR DRIVER’S HANDBOOK...

  • Page 2

    Warning: to ensure the engine operates optimally, the use of a lubricant may be restricted to certain vehicles. Please ELF has developed a complete range of lubricants for RENAULT: refer to your maintenance document. engine oils manual and automatic gearbox oils Benefiting from the research applied to Formula 1, lubricants are very high-tech products.

  • Page 3: Driving

    This handbook may also contain information about items of equipment to be introduced later in the model year. Throughout the manual, the “approved Dealer” is your RENAULT Dealer. Enjoy driving your new vehicle.

  • Page 5: Table Of Contents

    Sections Getting to know your vehicle ....... Driving ..............Your comfort ............Maintenance ............Practical advice ............ Technical specifications ........Alphabetical index ..........

  • Page 7: Table Of Contents

    RENAULT card: general information, use, deadlocking ........

  • Page 8: Battery Life

    3 Switch on the courtesy lighting re- “KEYCARD BATTERY LOW” appears on the instrument panel (refer to the in- motely. Driver’s responsibility formation on the “RENAULT card: bat- 4 Unlocking/locking the tailgate Never leave your vehicle tery" in section 5). 5 Integrated key.

  • Page 9

    RENAULT card, cle and all of its RENAULT cards to then insert the RENAULT card into an approved Dealer to initialise the the card reader to start the vehicle.

  • Page 10: Luggage Compartment

    If a door or the luggage compartment is open RENAULT card not detected or not properly shut, or if a RENAULT alarm card is still in the reader, the doors and If you open a door while the engine...

  • Page 11: Unlocking The Vehicle

    “HANDs-fREE” RENAULT CARD: use (1/3) Unlocking the vehicle On equipped vehicles, in addition to With the RENAULT card in zone 1 and the functions of the remote control the vehicle locked, press button 3 on RENAULT card, it can be used to lock/...

  • Page 12: Locking The Vehicle

    The vehicle will lock. If a door or the boot is open or not closed properly, the vehicle will quickly lock/unlock. Note: a RENAULT card must be within the vehicle's access zone (zone 1) to be able to lock the vehicle using the button.

  • Page 13

    Risk of serious injury. After locking/unlocking the vehicle using the buttons on the RENAULT card, "hands-free" locking and unlocking is deactivated. To reactivate the “hands-free” mode: restart the vehicle.

  • Page 14

    The hazard warning lights flash once to indicate that the doors have been un- locked. Operating fault If the RENAULT card does not work (worn batteries in the RENAULT card, batteries run down, etc.), use the key integrated in the card to unlock the front-left door (refer to the information in “Locking, unlocking the opening ele-...

  • Page 15: Opening And Closing The Doors

    With the doors unlocked, pull handle 1. tion (radio, etc.) will continue to oper- Lights-on reminder buzzer special feature of the RENAULT ate. If you have switched off the ignition “hands-free” card They will cease on opening the driv-...

  • Page 16

    OPENING AND CLOsING THE DOORs (2/2) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. They may pose a risk to themselves Child safety or to others by starting the engine, activating equipment such as the...

  • Page 17

    “RENAULT Card” information in Section 1. In certain cases, the RENAULT card may not work: – if the RENAULT card battery is weak, flat, etc. – if equipment operating on the same frequency as the card (mobile phones, etc.) is used;...

  • Page 18

    Unlocking the vehicle from the outside is only possible with the RENAULT card in the vehicle's access zone or using Interior locking/unlocking the key integrated in the RENAULT card.

  • Page 19: Operating Faults, Operating Principle

    RENAULT ANTI-INTRUDER DEVICE (RAID) Activating/deactivating the function With the engine running, press the button 1 for approximately 5 seconds, until you hear a warning beep. Operating faults If you experience an operating fault (no automatic locking, the indicator light incorporated in button 1 does not light up when trying to lock the open- ing elements, etc.), firstly check that the...

  • Page 20: Front Headrests

    fRONT HEADREsTs To raise the headrest Raise the headrest to its highest po- sition (tilt the seatback backwards if necessary). Press button 1 and lift the headrest to release it. To refit the headrest Insert the headrest rods into the holes (tilt the seatback backwards if neces- sary).

  • Page 21: Front Seats, Heated Seats

    fRONT sEATs To move the seat forwards or To tilt the seatback Heated seats backwards Turn the control knob 3 and tilt the seat- With the ignition on, press the switch 4 back to the desired position. for the seat desired. The indicator light Lift handle 1 to unlock.

  • Page 22: Seat Belts

    sEAT BELTs (1/3) Before starting, first adjust your driv- Always wear your seat belt when trav- elling in your vehicle. You must also ing position, then ask all occupants comply with the legislation of the par- to adjust their seat belts to ensure ticular country you are in.

  • Page 23: Front Seat Belts

    sEAT BELTs (2/3) ß front seat belt reminder warning light This lights up on the central display when the engine is started then, if the driver’s or front passenger’s seat belt (if this seat is occupied) is not fastened and the vehicle has reached approxi- mately 12 mph (20 km/h), it flashes and a bleep sounds for around 2 minutes.

  • Page 24: Rear Seat Belts

    sEAT BELTs (3/3) The following information applies to the vehicle’s front and rear seat belts. – No modification may be made to the component parts of the originally fitted restraint system: seat belts, seats and their mountings. For spe- cial operations (e.g. fitting child seats), contact an authorised dealer. –...

  • Page 25: To The Front Seat Belts

    METHODs Of REsTRAINT IN ADDITION TO THE fRONT sEAT BELTs (1/4) Depending on the vehicle, they will con- – Have the entire restraint sist of: system checked following – front seat belt inertia reel preten- an accident. sioners; – No operation whatso- –...

  • Page 26: Methods Of Restraint In Addition To The Front Seat Belts

    METHODs Of REsTRAINT IN ADDITION TO THE fRONT sEAT BELTs (2/4) Load limiter Airbags for driver and front passenger Above a certain severity of impact, this mechanism is used to limit the force of Fitted to the driver and passenger side. the belt against the body so that it is at The presence of this equipment is in- an acceptable level.

  • Page 27

    METHODs Of REsTRAINT IN ADDITION TO THE fRONT sEAT BELTs (3/4) Operating faults Operation å This system is only operational when Warning light 4 will light up on the ignition is switched on. the instrument panel when the ignition In a severe frontal impact, the air bags is turned on and then go out after a few inflate rapidly, cushioning the impact seconds.

  • Page 28

    METHODs Of REsTRAINT IN ADDITION TO THE fRONT sEAT BELTs (4/4) All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. Warnings concerning the driver’s air bag –...

  • Page 29

    METHODs Of REsTRAINT IN ADDITION TO THE REAR sIDE sEAT BELTs force limiter Above a certain severity of impact, this mechanism is used to limit the force of the belt against the body so that it is at an acceptable level. –...

  • Page 30: Side

    sIDE PROTECTION DEVICEs side Airbags This airbag may be fitted to each of the front seats and is activated at the sides of the seats (door side) to protect the occupants in the event of a severe side impact. Warning relating to the side airbag –...

  • Page 31: Additional Methods Of Restraint

    ADDITIONAL METHODs Of REsTRAINT All of the warnings below are given so that the airbag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when it inflates. The airbag is designed to complement the action of the seat belt.

  • Page 32: Child Safety: General Information

    CHILD sAfETY: General information (1/2) Carrying children Children, and adults, must be correctly seated and strapped in for all journeys. The children being carried in your vehi- cle are your responsibility. A child is not a miniature adult. Children are at risk of specific injuries as their muscles and bones have not yet fin- Driver’s responsibility ished growing.

  • Page 33

    CHILD sAfETY: General information (2/2) Using a child seat Set a good example by always fas- The level of protection offered by the tening your seat belt and teaching child seat depends on its ability to re- your child: strain your child and on its installation. –...

  • Page 34

    CHILD sAfETY: choosing a child seat Rear-facing child seats forward-facing child seats Booster cushions A baby’s head is, proportionally, heavier The child’s head and abdomen need to From 15 kg or 4 years, the child can than that of an adult and its neck is very be protected as a priority.

  • Page 35

    CHILD sAfETY: choosing a child/baby seat mounting (1/2) Attachment using the IsOfIX There are two ways of attaching child Before using an ISOFIX seats: via the seat belt or using the system child seat that you pur- ISOFIX system. Authorised ISOFIX child seats are ap- chased for another vehicle, proved in accordance with regulation check that its installation is...

  • Page 36

    CHILD sAfETY: choosing a child/baby seat mounting (2/2) The two rings 1 are located between Rear seats front passenger seat the seatback and the seat base and are Put the rear parcel shelf down in order Attach the belt hook 3 to the ring 5. identified by a marking.

  • Page 37: Fitting A Child Seat

    CHILD sAfETY: fitting a child seat (1/4) In the front seat Some seats are not suitable for fitting After installing the child seat, if neces- child seats. The diagram on the follow- sary, the seat may be advanced (so as The laws concerning children travel- ing page shows you how to attach a to leave enough space in the rear seats...

  • Page 38

    CHILD sAfETY: fitting a child seat (2/4) In the rear side seat A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with their feet nearest the door. Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will go, although without al-...

  • Page 39

    CHILD sAfETY: fitting a child seat (3/4) fitting diagram Child seat attached using the IsOfIX mounting ü Seat which allows an ISOFIX child seat to be fitted. ± The seats ISOFIX are fitted with an anchorage point which allows a forward-facing ISOFIX child seat with “Universal”...

  • Page 40

    CHILD sAfETY: fitting a child seat (4/4) The table below summarises the information already shown on the diagram on the previous page, to ensure the regula- tions in force are respected. Weight of front passenger Rear centre Type of child seat seat size Rear side seats the child...

  • Page 41: Deactivating, Activating The Front Passenger Airbag

    CHILD sAfETY: deactivating/activating the front passenger air bag (1/3) Deactivating the front To deactivate the airbags: with the vehicle stopped and the ignition off, passenger airbags push and turn lock 1 to the Off posi- (on equipped vehicles) tion. You must deactivate the devices in ad- With the ignition on, you must check dition to the front passenger seat belt before fitting a child seat in the front...

  • Page 42

    CHILD sAfETY: deactivating/activating the front passenger air bag (2/3) The markings on the dashboard and labels A on each side of passenger sun blind 3 (example: label shown above) remind you of these instructions. DANGER Since operation of the front passenger airbag is not compatible with the position of a rear-facing child seat, NEVER...

  • Page 43

    CHILD sAfETY: deactivating/activating the front passenger air bag (3/3) Operating faults It is forbidden to fit a rear-facing child seat to the front passenger seat if the airbags activation/deactivation system is faulty. Allowing any other passenger to sit in that seat is not recommended. Contact your approved dealer as soon as possible.

  • Page 44: Driving Position

    DRIVING POsITION: LEfT-HAND DRIVE (1/2) 1.38...

  • Page 45

    25 Controls for: 14 Storage drawer. – electric headlight beam adjust- 6 Stalk: ment, 15 RENAULT card reader. – windscreen and rear screen – instrument panel lighting dimmer, wash/wipe; 16 Gear lever. – trip computer and warning – activate/deactivate the parking system information readout.

  • Page 46

    DRIVING POsITION: RIGHT-HAND DRIVE (1/2) 12 13 1 1.40...

  • Page 47

    – instrument panel lighting dimmer, 8 Windscreen demister outlet. socket. – activate/deactivate the parking 9 Stalk: 23 RENAULT card reader. distance control system, – direction indicator lights; – activation/deactivation of the Stop – exterior lights; 24 Glovebox. and Start function.

  • Page 48: Instrument Panel

    WARNING LIGHTs (1/4) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. å In some cases, the appearance of a Air bag warning light warning light is accompanied by a mes- This lights up when the ignition sage.

  • Page 49

    WARNING LIGHTs (2/4) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. À Handbrake on and brake cir- Oil pressure warning light cuit incident warning light This lights up when the ignition This comes on when the ignition is is switched on and goes out after a few switched on and goes out as soon as seconds.

  • Page 50

    WARNING LIGHTs (3/4) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. Ä Toxic fume filter system Anti-lock braking warning Warning Light light This lights up when the ignition is For vehicles equipped with this option, switched on and goes out after a few the light comes on when the ignition is seconds.

  • Page 51

    WARNING LIGHTs (4/4) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. Φ Š‰ speed limiter and cruise fuel economy indicator light control indicator lights This lights up to advise you to change to a higher gear (up arrow) or See the information on the “Speed lim- lower gear (down arrow).

  • Page 52: Displays And Indicators

    DIsPLAYs AND INDICATORs Rev counter 1 speedometer 2 Low engine oil level warning (graduations x 1000) (km or miles per hour) When the engine is started, display 3 alerts the driver when the oil level is at Overspeed buzzer its minimum. Refer to the information on the “Engine oil level”...

  • Page 53: On-board Computer

    ON-BOARD COMPUTER: general information (1/2) f) distance travelled; g) average speed; h) distance before service; – service counter; – oil change counter; i) cruise control/speed limiter pro- grammed speed; j) clock and temperature; k) trip log, operating faults and informa- tion message readout.

  • Page 54

    ON-BOARD COMPUTER: general information (2/2) Interpreting some of the Automatic resetting of the values displayed after journey parameters resetting Resetting occurs automatically when the maximum value of any of the pa- The values showing average fuel con- rameters is exceeded. sumption, range and average speed will become more stable and reliable the further you travel after pressing the...

  • Page 55: Trip Computer: Trip Settings

    TRIP COMPUTER: trip settings (1/5) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected 101778 km 112.4 km a) Total mileage and trip mileage recorder. FUEL USED b) Journey parameters. fuel used.

  • Page 56

    TRIP COMPUTER: trip settings (2/5) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected RANGE e) Estimated range with remaining fuel. 541 km The value is displayed after driving 400 metres. DISTANCE 522 km f) Distance travelled since last reset.

  • Page 57

    TRIP COMPUTER: trip settings (3/5) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected SERVICE IN SERVICE INTERVALS h) Mileage before service or oil change. 30,000 kms / 12 months Mileage before service With the ignition switched on but the engine not run- SERVICE DUE...

  • Page 58

    TRIP COMPUTER: trip settings (4/5) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected OIL CHANGE IN Mileage before service SERVICE INTERVALS 30,000 kms / 24 months With the ignition switched on and the engine not run- ning, when the “Mileage before service”...

  • Page 59

    TRIP COMPUTER: trip settings (5/5) The display of information shown below DEPENDs ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected SPEED LIMITER 90 km/H i) Cruise control/speed limiter programmed speed. Refer to the information on the “Speed limiter” and “Cruise control” in Section 2. CRUISE CONTROL 90 km/H j) Clock and temperature.

  • Page 60

    Interpreting the display selected « PARKING BRAKE ON » Indicates that the parking brake has been applied. « PLEAsE REMOVE Request to remove the RENAULT card from the reader when you leave the vehicle. KEYCARD » « TRACTION Indicates that you have deactivated the ASR function.

  • Page 61

    TRIP COMPUTER AND WARNING sYsTEM: operating fault messages © These appear with the warning light and mean that you should drive very carefully to an authorised dealer as soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle. They disappear when the display selection key is pressed or after several seconds and are stored in the computer log.

  • Page 62

    TRIP COMPUTER AND WARNING sYsTEM: warning message ® These appear with the warning light and require you to stop immediately, for your own safety, as soon as traf- fic conditions allow. stop your engine and do not restart it. Contact an approved Dealer. Examples of warning messages are given in the following pages.

  • Page 63: Steering Wheel/power-assisted Steering

    sTEERING WHEEL/POWER-AssIsTED sTEERING Power Assisted steering Never drive with an inadequately charged battery. Variable power assisted steering The variable power assisted steering system is equipped with an electronic control system which alters the level of assistance to suit the vehicle speed. Steering is made easier during parking manoeuvres (for added comfort) whilst the force needed to steer increases...

  • Page 64: Clock And Exterior Temperature

    CLOCK AND EXTERIOR TEMPERATURE (1/2) 9°C 12:00 Display A Wait a few seconds, the minutes will flash: repeatedly press or press and To access the display 2 for setting the hold button 3 or 4 to set the time. time, press button 3 or 4 on the stalk 1. When setting is complete, the hours Wait a few seconds;...

  • Page 65

    CLOCK AND EXTERIOR TEMPERATURE (2/2) External temperature indicator special note: When the exterior temperature is - 3°C to + 3°C, the °C characters flash (sig- nalling a risk of ice on the road). External temperature in- Display B dicator Vehicles fitted with touch-screen As ice formation is related multimedia, navigation aid systems, to climatic exposure, local...

  • Page 66: Door Mirrors, Heated Door Mirrors, Folding Door Mirrors, Interior Rear View Mirror

    REAR VIEW MIRRORs Heated door mirrors With the engine running, mirror de- icing is activated simultaneously with rear screen de-icing/demisting. folding door mirrors (depending on vehicle) Move button 1 to position F: the door mirrors fold away. To reset them for driving, return to position C, D or E.

  • Page 67: Exterior Lighting And Signals

    EXTERIOR LIGHTING AND sIGNALs (1/3) Dipped beam headlights Manual operation Turn the ring 2 until the symbol is oppo- site mark 3. This indicator light on the instrument panel comes on. Automatic operation (depending on vehicle) Turn ring 2 until the AUTO symbol is op- posite mark 3: with the engine running, the dipped beam headlights switch on or off automatically depending on the...

  • Page 68: Front Fog Lights

    EXTERIOR LIGHTING AND sIGNALs (2/3) switching off the lights front fog lights There are two possibilities: Turn centre ring 4 on the – Manually, move ring 2 to position 0; stalk 1 until the symbol faces mark 5, – automatically, the lights will go out then release it.

  • Page 69: Rear Fog Light, Turning Off The Fog Lights

    EXTERIOR LIGHTING AND sIGNALs (3/3) Turning off the fog lights There are two possibilities: – Manually, turn the ring 4 again to bring the reference mark 5 in line with the symbol corresponding to the fog light you want to turn off. The cor- responding indicator light will go out on the instrument panel;...

  • Page 70: Audible And Visual Signals

    AUDIBLE AND VIsUAL sIGNALs Direction indicators Move stalk 1 parallel to the steering wheel and in the direction you are going to turn it. One-touch mode When driving, it is possible that the steering wheel may not be turned suf- ficiently to return the stalk automatically to its starting position.

  • Page 71

    HEADLIGHT BEAM ADJUsTMENT (1/2) for manual settings Examples of positions for adjusting control A according to the load Driver alone or with front passenger Driver with a passenger in front, two or three passengers in the rear and luggage On vehicles fitted with this function, control A allows you to adjust the height Driver with luggage or (load) reaching the maximum of the beams according to the load.

  • Page 72: Headlight Beam Adjustment

    HEADLIGHT BEAM ADJUsTMENT (2/2) When driving on the left in a left- hand drive vehicle (or vice versa), you must adjust your lights tempo- rarily during your stay. Temporary adjustment Open the bonnet and identify the mark- ing B next to one of the front headlight projectors.

  • Page 73

    WINDsCREEN WAsH/WIPE (1/2) Vehicles with automatic wiper function With the engine running, move stalk 1 – A park. – B automatic wiper function When this position is selected, the system detects water on the wind- screen and triggers the wipers at a suitable wiping speed.

  • Page 74: Windscreen Washer

    WINDsCREEN WAsH/WIPE (2/2) Do not try to lift the wiper blades. They cannot remain detached from the windscreen. To replace the blades, refer to Section 5: “Wiper blades”. In freezing or snowy weather, ensure they are not stuck to the windscreen (including the central area located behind the interior rear-view mirror) and the rear screen before starting...

  • Page 75

    REAR sCREEN WAsH/WIPE Rear screen wash/wipe With ignition on, turn the end of the stalk 1 to bring the mark 2 in line with the symbol. When the stalk is re- leased, it returns to the rear windscreen In freezing or snowy weather, ensure wiper position.

  • Page 76: Fuel Grade

    fUEL TANK (1/3) fuel grade Petrol version It is essential to use unleaded petrol. Use a high-grade fuel that complies The octane rating (RON) must comply with the legislation in force in each with the information given on the label country and which must comply with on the cover A.

  • Page 77

    fUEL TANK (2/3) filling with fuel With the ignition off, insert the nozzle and insert it fully before turning it on to fill the fuel tank (risk of splashing). Keep the nozzle in this position through- out the entire filling operation. When the pump cuts out automatically at the end of the filling procedure, a maximum of two further filling attempts...

  • Page 78

    Running out of fuel on diesel Vehicles without priming bulb 4 wiring, fuel circuit, injectors, pro- versions Insert the RENAULT card into the 5 tective covers, etc.) as this may be Vehicles with priming bulb 4 card reader. Press the start button 3...

  • Page 79

    Section 2: Driving (Advice on use relating to fuel economy and the environment) Running in ..............Starting, stopping the engine .

  • Page 80

    RUNNING IN Petrol version Diesel version For the first 600 miles (1,000 km), do For the first 1,000 miles (1,500 km), not exceed 78 mph (130 km/h) in the do not exceed 80 mph (130 km/h) in highest gear, or 3,000 to 3,500 rpm. the highest gear, or 2,500 rpm.

  • Page 81: Special Features

    To start, press button 1. If a gear is en- gaged, depress the clutch pedal to start Starting with the boot open in the vehicle. hands-free mode In this case, the RENAULT card must not be located in the luggage compart- ment.

  • Page 82

    In certain cases, the hands-free RENAULT card, insert the card into RENAULT card may not work: reader 2; – when the RENAULT card battery is – vehicles with a RENAULT “hands- drained, flat battery, etc. free” card, with the card in the pas- –...

  • Page 83

    If the card is no longer in the reader cle, especially if you have when you try to switch the engine off, your RENAULT card with the message “NO KEYCARD PRESS you, check that the engine AND HOLD” will appear on the in- is completely switched off.

  • Page 84

    SToP AND START function (1/3) This system enables a reduced fuel Special feature of the automatic  consumption and lower greenhouse engine re-start Warning light is displayed on the gas emissions. instrument panel. This notifies you that Under certain conditions, the engine The system is activated automatically the engine is on standby.

  • Page 85

    SToP AND START function (2/3) Conditions preventing the Special cases – the “Clear View” function is activated (please see the information on “Air standby of the engine – Depending on the vehicle, while the conditioning” in Section 3); system is operating and the engine Depending on the vehicle, certain con- –...

  • Page 86

    SToP AND START function (3/3) operating faults The system is automatically reactivated each time the vehicle is started using When the message “CHECK STOP the start button (please see “Starting, AND START” appears on the instru- stopping the engine)”. ment panel and the integrated warn- Special note: engine on standby, ing light 2 lights up on the switch 1, the press switch 1 to automatically restart...

  • Page 87: Special Features Of Petrol Versions

    SPECIAL FEATURES oF PETRoL VERSIoNS The following operating conditions: If you notice any of the above operating faults, have the necessary repairs car- – driving for long periods when the low ried out as soon as possible by an ap- fuel level warning light is lit;...

  • Page 88: Running Out Of Fuel

    SPECIAL FEATURES oF DIESEL VERSIoNS Diesel engine speed Precautions to be taken in winter Diesel engines are fitted with injection equipment which prevents the engine To avoid any faults in icy weather: speed being exceeded irrespective of – ensure that the battery is always fully the gear selected.

  • Page 89: Gear Lever

    GEAR LEVER/HANDbRAkE Handbrake To release: Pull the lever 3 up slightly, press button 2 and then lower the lever to the floor. The red warning light on the instrument panel will come on if you are driving with an incorrectly released handbrake. To apply: Pull lever 3 upwards.

  • Page 90: Journey Record

    ECo-DRIVING (1/2) Depending on the vehicle, you will have various functions which enable you to lower your fuel consumption: – the rev counter; – the gear change indicator; – the driving style indicator; – the journey record and eco-driving advice via the multimedia display; –...

  • Page 91

    ECo-DRIVING (2/2) The ECO mode is reactivated once you relax the accelerator pedal, the 5  light will remain lit on the instru- ment panel. Disabling the function Press switch 4.  The 5 light goes out on the in- strument panel to confirm deactivation.

  • Page 92: Engine Adjustments

    ADVICE: antipollution, fuel economy and driving (1/3) Aiding fuel economy Your vehicle complies with criteria for Have your vehicle adjusted and recycling and recovering vehicles at the checked by an approved Dealer, in ac- Depending on the vehicle, in order to end of their service life which will come cordance with the instructions given in optimise consumption, an indicator light...

  • Page 93

    ADVICE: antipollution, fuel economy and driving (2/3) Exhaust gas monitoring – Brake as little as possible. If you an- ticipate an obstacle or bend in ad- system vance, you may then simply release The exhaust gas monitoring system will the accelerator pedal. detect any operating faults in the vehi- –...

  • Page 94

    ADVICE: antipollution, fuel economy and driving (3/3) – In vehicles fitted with air condi- tioning, it is normal to observe an increase in fuel consumption (es- pecially in urban conditions) when it is used. For vehicles fitted with manual air conditioning, switch off the system when it is not required.

  • Page 95

    ENVIRoNMENT Emissions Your vehicle has been designed with – At the end of the vehicle’s service respect for the environment in mind for life, it should be sent to approved Your vehicle has been designed to its entire service life: during production, centres to ensure that it is recycled.

  • Page 96

    DRIVER CoRRECTIoN DEVICES AND AIDS (1/4) Anti-lock braking system operating faults: Depending on the vehicle, this is com- posed of: (AbS) © – anti-lock braking system (AbS); – lit up on the in- Under heavy braking, the ABS prevents – electronic stability control (ESC) strument panel alongside messages the wheels from locking, allowing the with understeer control and trac-...

  • Page 97: Electronic Stability Program

    DRIVER CoRRECTIoN DEVICES AND AIDS (2/4) Electronic stability program Understeer control operating faults (ESC) with understeer control This system optimises the action of the When the system detects an operating and traction control (ASR) ESC in the case of pronounced under- fault the message “CHECK ESC”...

  • Page 98: Emergency Brake Assist

    DRIVER CoRRECTIoN DEVICES AND AIDS (3/4) Emergency brake assist Hazard warning lights switching on Depending on the vehicle, these may This system supplements the ABS light up in the event of sudden decel- and helps reduce vehicle stopping dis- eration. tances.

  • Page 99

    DRIVER CoRRECTIoN DEVICES AND AIDS (4/4) Hill start assistance The hill start assistance This function assists the driver when system cannot completely starting on hills. It prevents the vehicle prevent the vehicle from from rolling backwards, depending on rolling backwards in all sit- the slope, by automatically applying the uations (extremely steep gradients, brakes when the driver lifts his/her foot...

  • Page 100

    CRUISE CoNTRoL/SPEED LIMITER: speed limiter function (1/3) Controls Switching on The speed limiter function helps you stay within the driving speed limit that  1 Main “On/Off” switch. Press the side switch 1 . Indicator you choose, known as the limit speed. light 6 comes on, lit orange, and the 2 Limit speed activation, storage and message “SPEED LIMITER”...

  • Page 101

    CRUISE CoNTRoL/SPEED LIMITER: speed limiter function (2/3) Varying the limit speed Exceeding the limit speed The limit speed may be changed by re- It is possible to exceed the limit speed peatedly pressing: at any time. To do this: press the accel- erator pedal firmly and fully (beyond –...

  • Page 102

    CRUISE CoNTRoL/SPEED LIMITER: speed limiter function (3/3) Recalling the limit speed If a speed has been saved, it can be re- called by pressing switch 4 ((R)). Putting the function on Switching off the function standby The speed limiter function is deac- tivated if you press switch 1: in this The speed limiter function is suspended case a speed is no longer stored.

  • Page 103

    CRUISE CoNTRoL/SPEED LIMITER: cruise control function (1/4) This function is an addi- tional driving aid. However, the function does not take the place of the driver. Therefore, it can under no circum- Controls The cruise control function helps you to stances replace the driver’s respon- maintain your driving speed at a speed sibility to respect speed limits and to...

  • Page 104

    CRUISE CoNTRoL/SPEED LIMITER: cruise control function (2/4) Switching on Activating cruise control Driving  At a steady speed (above 18 mph Once a cruising speed is stored and Press switch 1 side (30 km/h approximately)) press switch 2 the cruise control function is active, Indicator light 6 comes on, lit green, and or (+): the function is activated and the you may lift your foot off the accelera-...

  • Page 105

    CRUISE CoNTRoL/SPEED LIMITER: cruise control function (3/4) Exceeding the cruising speed The cruising speed may be exceeded at any time by depressing the accelera- tor pedal. While it is being exceeded, the cruising speed flashes on the in- strument panel. Then, release the accelerator: after a few seconds, the vehicle will automati- cally return to its set cruising speed.

  • Page 106

    CRUISE CoNTRoL/SPEED LIMITER: cruise control function (4/4) Returning to the cruising speed If a speed is stored, it can be recalled, once you are sure that the road con- ditions are suitable (traffic, road sur- face, weather conditions, etc.). Press switch 4 (R) if the vehicle speed is above 20 mph (30 km/h).

  • Page 107: Parking Distance Control

    PARkING DISTANCE CoNTRoL (1/2) operating principle Ultrasonic detectors, installed in the rear bumper (depending on the vehi- cle), measure the distance between the vehicle and an obstacle whilst revers- ing. This measurement is indicated by beeps which become more frequent the closer you come to the obstacle, until they become a continuous beep when the vehicle is approximately 30 centi-...

  • Page 108

    PARkING DISTANCE CoNTRoL (2/2) operating faults Depending on the vehicle, when the system detects an operating fault, the message “check parking distance con- trol” appears on the instrument panel, accompanied by the warning light © and a beep lasting approxi- mately 5 seconds.

  • Page 109

    REVERSING CAMERA (1/2) operation Note: This function is an additional – ensure that the reversing camera is When going into reverse gear (and up aid. It cannot, therefore, not obscured (dirt, mud, snow, etc.); to around 5 seconds after shifting into under any circumstances –...

  • Page 110

    REVERSING CAMERA (2/2) Static guide line 4: The fixed clearance gauge comprises coloured markers A, B and C, indicat- ing the distance behind the vehicle: – A (red) approximately 30 centime- tres from the vehicle; – B (yellow) approximately 70 centi- metres from the vehicle;...

  • Page 111: Selector Lever

    AUToMATIC TRANSMISSIoN (1/3) Driving in automatic mode Move lever 1 to position D. In most road conditions you will en- counter, you will not need to touch your lever again: the gears will change au- tomatically at the right time and at the most suitable engine speed because the automatic system takes into ac- count the vehicle load and road contour...

  • Page 112

    AUToMATIC TRANSMISSIoN (2/3) Special cases Special circumstances In certain driving conditions (for exam- – If the bends and road surface do ple, engine protection, operation of the not allow you to stay in automatic Electronic Stability Programme: the au- mode (e.g. in the mountains), we tomatic system may change gear auto- recommend that you change to matically.

  • Page 113: Automatic Transmission

    AUToMATIC TRANSMISSIoN (3/3) Parking the vehicle operating faults When the vehicle is stopped, move the – when driving, if the ‘check gearbox’ lever to position P while keeping your message appears on the instrument foot on the brake pedal: the gearbox is panel, it indicates a fault.

  • Page 114

    2.36...

  • Page 115: Your Comfort

    Section 3: Your comfort Air vents............... Manual air conditioning and heating system .

  • Page 116

    air vents, air outlets (1/2) 1 Left-hand side window demister 5 Right-hand air vent. outlet. 6 Right-hand side window demister 2 Left-hand air vent. outlet. 3 Windscreen demisting vents. 7 Passenger footwell heater out- 4 Centre air vents. lets. 8 Control panel...

  • Page 117

    air vents, air outlets (2/2) Centre air vents. side air vents air flow air flow Move the control knob 10 (beyond the To open air vent 11, press on the air resistance point). vent (point 12) until it is open as far as required.

  • Page 118

    Manual air ConDitioning (1/3) the controls switching air conditioning on or off 1 Adjusting the air temperature. (depending on vehicle) 2 Adjusting the ventilation speed. The button 3 allows you to put the air 3 Air conditioning. conditioning on (indicator light lit) or off (indicator light unlit).

  • Page 119: Manual Air Conditioning, Passenger Compartment

    Manual air ConDitioning (2/3) Distribution of air in the passenger compartment There are five air distribution options. Turn control 4 to choose the distribution option. The air flow is directed to the windscreen and the front side window demisting vents. The air flow is distributed be- tween all the air vents, the front side window demisting vents, the...

  • Page 120

    Manual air ConDitioning (3/3) adjusting the air temperature Turn control 1 to obtain the desired temperature. The further towards the red the slide is, the higher the tempera- ture will be. When the air conditioning system is used for long periods, it may begin to feel cold.

  • Page 121: Automatic Climate Control, Automatic Mode

    autoMatiC CliMate Control (1/4) varying the ventilation speed In automatic mode, the system uses the most suitable amount of air to reach and maintain the desired comfort level. You can still adjust the ventilation speed by turning control 6 to increase or reduce the ventilation speed.

  • Page 122

    autoMatiC CliMate Control (2/4) Clear view function Press button 3 – the integrated indica- tor light comes on. This function quickly demists and de- ices the windscreen, the rear screen, the front side windows, and the door mirrors (depending on the vehicle). The air conditioning and rear screen de-ic- ing functions must be activated.

  • Page 123

    autoMatiC CliMate Control (3/4) rear screen de-icing/ switching air conditioning on demisting or off Press button 8 – the integrated indica- In automatic mode, the system switches tor light comes on. This function en- the air conditioning system on or off, ables rapid demisting or de-icing of the depending on the climate conditions.

  • Page 124

    autoMatiC CliMate Control (4/4) air recirculation (isolation of the passenger compartment) This function is managed automatically (operation is confirmed by a warning light on button 7), but you can also acti- vate it manually. The system determines whether or not the air recycling function is used, based on the quality of the outside air.

  • Page 125: Maintenance

    air ConDitioning: information and advice on use advice on use Fuel consumption operating faults In some situations, (air conditioning You will normally notice an increase in As a general rule, contact your ap- off, air recirculation activated, ventila- fuel consumption (especially in town) proved dealer in the event of an oper- tion speed at zero or low, etc.) you may when the air conditioning is operating.

  • Page 126: Electric Windows

    4. A confirmation message is displayed on the instrument panel. Driver’s responsibility Never leave your vehicle with the RENAULT card inside and never leave a child (or a pet) unsuper- vised, even for a short while. They electric windows...

  • Page 127

    eleCtriC WinDoWs (2/2) one-touch mode operating faults Depending on the vehicle, this mode In case of a fault when closing a window, works in addition to the operation of the the system reverts to normal mode: electric windows described previously. pull the switch concerned up as often It is only fitted to the driver’s window.

  • Page 128: Interior Lighting, Courtesy Light

    interior ligHting Courtesy light soft lighting 4 Boot light 5 Press switch 2 for: It comes on: It comes on when the boot is opened. – on opening the storage drawer; – permanent lighting; – on opening one of the doors. This –...

  • Page 129

    Passenger CoMPartMent storage, Fittings (1/5) Front door storage pockets 1 sun visor storage 2 Centre console storage compartment 3 They can hold a 1.5-litre bottle. This can be used for storing motorway tickets, cards, etc. Nothing should be placed Ensure that no hard, heavy on the floor area in front of or pointed objects are the driver as such objects...

  • Page 130

    Passenger CoMPartMent storage, Fittings (2/5) Dashboard storage Passenger storage drawer glovebox compartment 5 To open, press the button 7 to unlock To open the glovebox, lift catch 8. the drawer and pull the handle 6. To open it, press the lid 4. Maximum load allowed in the pas- senger storage compartment: 6 kg, evenly distributed.

  • Page 131

    Passenger CoMPartMent storage, Fittings (3/5) storage compartment 9 Front seat storage net 11 Cup holders 10 This can be used for storing a mobile ashtray, cup holder, etc. When turning corners, accelerating or braking, Ensure that no hard, heavy ensure that the recepta- or pointed objects are cle being held by the cup placed in the “open”...

  • Page 132

    Passenger CoMPartMent storage, Fittings (4/5) rear centre console storage removable rear central rear door storage compartment 12 storage compartment 13 compartment 14 This can be used for storing a mobile It is fixed on the rear central storage They can hold a 0.5-litre bottle. ashtray, cup holder, etc.

  • Page 133: Sun Visor

    storage, CaBin Fittings sun visor (5/5)/ grab handle 15 Front sun visor This offers support and can be held Lower sun visor 16. when the vehicle is being driven. Do not use it for getting into or out of the Courtesy mirrors vehicle.

  • Page 134

    asHtray, Cigarette ligHter, aCCessories soCket ashtray accessories socket 2 It can be housed in either position 1 It is provided for connecting acces- or 3. sories approved by our Technical Department with a maximum power of 120 Watts (12V). Cigarette lighter 2 With the ignition on, push in the ciga- rette lighter 2.

  • Page 135

    rear HeaD rests Position for use to raise the headrest Raise the headrest as far as possible to Raise the headrest as far as it will go, use it in the high position. Check that it then press button A and remove the is correctly locked.

  • Page 136

    sliDing rear BenCH seat (1/2) to move forwards or backwards To unlock the seat: When moving the rear – lift one of the levers 1 under the rear seats, ensure that nothing seats; obstructs the anchorage points (passenger’s arm or –...

  • Page 137

    sliDing rear BenCH seat (2/2) to replace the seatback, proceed in the reverse order to removal. Refit the seatback and click it back into place. When moving the rear seats, ensure that nothing obstructs the anchorage points (passenger’s arm or leg, a pet, gravel, cloth, toys, etc.).

  • Page 138

    Boot to open opening the doors manually from the inside Press button 1 and lift the tailgate. If it is impossible to unlock the tailgate, it can be done manually from inside: to close – access the luggage compartment by Lower the tailgate using the handles 2 tilting the rear bench seatback(s), inside the tailgate to help you.

  • Page 139: Rear Parcel Shelf

    rear ParCel sHelF removal – lift one side of the parcel shelf; – pull the parcel shelf towards you – Unhook the two straps 1 of the door (movement B), beginning with the of the boot; part most raised. – lift the parcel shelf 2 to half height in To refit, proceed in the reverse order to order to unclip it (movement A);...

  • Page 140

    Boot Fittings (1/2) Mobile floor 1 intermediate position storage position In the blocked position, it allows you to This allows for more space to store Depending on the vehicle, the mobile access the tools stored under the boot things in the boot. floor is reversible.

  • Page 141

    Boot Fittings (2/2) Hook 4 anchorage points You can use this to secure a bag. Attachment points 5 If your vehicle is not equipped with anchorage points, you can get them from an authorised dealer. 3.27...

  • Page 142: Transporting Objects In The Luggage Compartment

    transPorting oBJeCts in tHe luggage CoMPartMent Always position the objects transported so that the largest surface is against: – The rear bench seatback for normal loads (example A). – The front seatbacks with the rear seatbacks folded down, the mobile floor in the flat-floor position (exam- ple B).

  • Page 143

    transPorting oBJeCts towbar A: 777 mm. Permissible nose weight, maxi- mum permissible towing weight, braked and unbraked: refer to the information on “Weights” in Section 6. For fitting and conditions of use, If the towbar ball obscures the regis- refer to the equipment’s fitting in- tration plate or the rear fog lights, it structions.

  • Page 144

    rooF Bars/sPoiler Precautions during use Handling the tailgate Before handling the tailgate, check the objects and/or accessories (bike rack, roof box, etc.) fitted to the roof bars: these must be correctly positioned and secured, so as not to hinder the opera- tion of the tailgate.

  • Page 145: Multimedia Equipment

    MultiMeDia equiPMent The presence and location of this equip- ment depends on the vehicle version. 1 Multimedia touch-screen; 2 Multimedia sockets; 3 Steering column control; 4 Voice commands; 5 Microphone. To use this equipment, consult the instructions for the equipment which should be kept with the other vehi- cle documentation.

  • Page 146

    3.32...

  • Page 147

    Section 4: Maintenance Bonnet ............... . Engine oil level: general information .

  • Page 148: Opening The Bonnet

    BONNET Closing the bonnet Check that nothing has been left in the engine compartment. To close the bonnet again, hold the bonnet in the middle and lower it to 30 cm above the closed position, then release it. It will latch automatically under its own weight.

  • Page 149

    ENGINE OIL LEVEL: general information It is normal for an engine to use oil for lubrication and cooling of moving parts and it is normal to top up the level be- In order to prevent splashback, it is tween oil changes. recommended that a funnel be used when topping up/filling with oil However, contact your approved...

  • Page 150

    ENGINE OIL LEVEL: topping up/filling (1/2) Topping up/filling – Unscrew cap 1; – top up the level (as a guide, the ca- The vehicle must be parked on level pacity between the minimum and ground and the engine should be cold maximum reading on the dipstick 2 (for instance, before the engine is is between 1.5 and 2 litres, depend-...

  • Page 151

    ENGINE OIL LEVEL: topping up, filling OIL ChANGE (2/2) Oil change Engine oil grade Service interval: refer Refer to the Maintenance Service Maintenance Service Booklet for your Booklet for your vehicle. vehicle. Average capacities for oil change including oil filter (for information) Filling: take care when Engine 0.9 TCe: 4.1 litres...

  • Page 152: Coolant Level

    LEVELS (1/3) Frequency of checking coolant level Replacement interval Check the coolant level regularly Refer to the Maintenance Document for (very severe damage is likely to be your vehicle. caused to the engine if it runs out of coolant). If the level needs to be topped up, only use products approved by our Technical Department which ensure: –...

  • Page 153: Brake Fluid Level

    LEVELS (2/3) Level 2 It is normal for the level to drop as the brake shoes become worn, but it must never drop lower than the “MINI" warn- ing line. If you wish to check the disc and drum wear yourself, you should obtain the document explaining the checking pro- cedure from the manufacturer’s net- work or web site.

  • Page 154

    LEVELS /FILTERS (3/3) Filters The replacement of filter components (air filter, cabin filter, diesel filter, etc.) is scheduled in the maintenance opera- tions for your vehicle. Replacement intervals for filter el- ements: refer to the Maintenance Document for your vehicle. Windscreen washer reservoir Jets To adjust the angle of the windscreen...

  • Page 155: Tyre Pressure

    TyRE pRESSURE E: front tyre pressure. F: rear tyre pressure. G: tyre pressure for the emergency spare wheel. Special note concerning fully laden vehicles (Maximum Permissible All-Up Weight) and towing a trailer: the maxi- mum speed must be limited to 60 mph (100 kph) and the tyre pressure in- creased by 0.2 bar.

  • Page 156: Replacing The Battery

    BATTERy Replacing the battery As this operation is complex, we advise you to contact an approved Dealer. This is located under cover 1 and does Label A not need to be serviced. Observe the indications on the battery: – 2 naked flames and smoking are for- bidden;...

  • Page 157

    BODyWORk MAINTENANCE (1/2) What you should not do you should A well-maintained vehicle will last longer. It is therefore recommended to Do not degrease or clean mechani- Wash your car frequently, with the maintain the exterior of the vehicle reg- cal components (e.g.

  • Page 158

    BODyWORk MAINTENANCE (2/2) Vehicles with a matte paint Using a roller type car wash Respect local regulations about wash- ing vehicles (e.g. do not wash your ve- finish Return the windscreen wiper stalk to hicle on a public highway). the Park position (refer to the informa- This type of paint requires certain pre- Observe the vehicle stopping distances tion on the “Windscreen washer, wiper”...

  • Page 159: Seat Belts

    INTERIOR TRIM MAINTENANCE (1/2) Glass instrument panel Textiles (seats, door trim, etc) A well-maintained vehicle will last longer. It is therefore recommended to (e.g. instrument panel, clock, exterior For vehicles fitted with removable seat maintain the interior of the vehicle regu- temperature display, radio display, etc.) covers, refer to the information on “Seat larly.

  • Page 160

    INTERIOR TRIM MAINTENANCE (2/2) Removal/replacing removable you should not: equipment originally fitted in You are strongly advised not to po- the vehicle sition objects such as deodorants, scents, etc. near air vents, as this could If you need to remove equipment in damage your dashboard trim.

  • Page 161

    SEAT COVERINGS (1/5) Depending on the vehicle, it is possible to remove the seat covers (cleaning, customisation, etc.). principle of seat cover For safety reasons, carry removal out these operations when precautions in use Whether it’s for the back or the base, the vehicle is stationary.

  • Page 162: Front Seat

    SEAT COVERINGS (2/5) Replacing the seatback cover Removing the base cover – Incline the seatback towards the – Open the zip fastener 4 of the base; rear; – remove the cover according to the – position the cover on the seatback; method shown (movement A).

  • Page 163

    SEAT COVERINGS (3/5) Rear bench seat Removing the base cover B Replacing the base cover B – Open the zip fasteners 7 and 8 for – Position the cover on the base B; – Bring the front seats forward; the base B; –...

  • Page 164

    SEAT COVERINGS (4/5) – attach the self-grip bands; – ensure that the seatback cover is correctly positioned C under the guide of the central seatbelt 10; – slide the lower cover between the seatback C and the base B; – fold down the seatback C to the base using the stalk 11;...

  • Page 165

    SEAT COVERINGS (5/5) Replacing the seatback cover D – Position the cover on the seat- back D; – close the zip fastener 20; – slide the lower cover between the seatback D and the base; – move the seatback D onto the base using the stalk16;...

  • Page 166

    4.20...

  • Page 167: Practical Advice

    RENAULT card: battery ........

  • Page 168: Emergency Spare Wheel

    PUNCTURE, EMERGENCY SPARE WHEEL In case of puncture Emergency spare wheel Depending on the vehicle, a tyre infla- – Open the tailgate; tion kit or emergency spare wheel is – place the mobile floor in the mid-way provided (refer to the following pages). position (please refer to the section on “Boot storage”...

  • Page 169

    TYRE PRESSURE KIT (1/3) Do not attempt to use the The kit is only approved for inflation kit if the tyre has inflating the tyres of the ve- been damaged as a result hicle originally equipped of driving with a puncture. with the kit.

  • Page 170

    TYRE PRESSURE KIT (2/3) With the engine running and the – after a maximum of 15 minutes, stop parking brake applied, inflating and read the pressure (on pressure gauge 5). – unroll the hose from the container; Note: while the container is empty- –...

  • Page 171

    TYRE PRESSURE KIT (3/3) Precautions when using the – Affix the driving recommendation label to the dashboard where it can easily be seen by the driver; The kit should not be operated for more – Put the kit away. than 15 consecutive minutes. –...

  • Page 172

    TOOLS Jack 2 Fold it correctly before refitting it in its housing (ensure that the wheelbrace is correctly positioned). Hubcap tool 3 This tool is used to remove the wheel trims. Wheel bolt guide 4 To finish loosening or starting to tighten the wheel bolts.

  • Page 173

    WHEEL TRIMS - WHEEL Remove the wheel trim using hubcap tool 1 (located in the tool kit) by en- gaging the hook in the opening near valve 2. To refit it, align it with valve 2. Push the retaining hooks in fully, starting with side A near the valve, followed by B and C, finishing at D opposite the valve.

  • Page 174: Changing A Wheel

    CHANGING A WHEEL (1/2) Vehicles equipped with a jack Continue to crank the jack so that the baseplate is correctly positioned (it and wheelbrace should be underneath the vehicle and If necessary, remove the wheel trim. aligned with the jack head). Use the wheelbrace 1 to slacken off the Turn it a few times to lift the wheel off wheel bolts.

  • Page 175

    CHANGING A WHEEL (2/2) Undo the bolts and take off the wheel. Fit the emergency spare wheel on the central hub and turn it to locate the mounting holes in the wheel and the hub. Tighten the bolts, checking that the wheel is correctly positioned on its hub.

  • Page 176

    TYRES (1/3) Tyre and wheel safety When the tyre tread has been worn to the level of the warning strips, they The tyres are the only contact between become visible 2: it is then neces- the vehicle and the road, so it is essen- sary to replace your tyres because the tial to keep them in good condition.

  • Page 177: Tyre Pressures, Emergency Spare Wheel

    TYRES (2/3) Tyre pressures Emergency spare wheel Pressures should be checked when the tyres are cold; ignore higher pressures Adhere to the tyre pressures (including Refer to the information on the which may be reached in hot weather the emergency spare wheel). The tyre “Emergency spare wheel”...

  • Page 178

    TYRES (3/3) Use in winter Snow or Winter tyres Studded tyres We would recommend that these be This type of equipment may only be Chains fitted to all four wheels to ensure that used for a limited period and as laid For safety reasons, fitting snow your vehicle retains maximum adhe- down by local legislation.

  • Page 179: Front Headlights: Changing Bulbs

    FRONT HEADLIGHTS: changing bulbs (1/3) Main beam headlight To change the bulb: – remove cover B; – disconnect the wiring 4 (black lead); – unclip the spring 3 and remove the bulb. Bulb type: H1. It is essential to use anti-U.V. 55W bulbs so as not to damage the plastic on the headlights.

  • Page 180

    FRONT HEADLIGHTS: changing bulbs (2/3) Front side light To change a bulb, remove the cover B. Pull the bulb holder 6 to access the bulb. Bulb type: W5W. To comply with local legislation, or as a precaution, you can obtain an emergency kit containing a set of spare bulbs and fuses from an ap- proved dealer.

  • Page 181

    FRONT HEADLIGHTS: changing bulbs (3/3) Additional lights If you wish to fit fog lights to your ve- hicle, please see an authorised dealer. Daytime running lights 7 Please see an authorised dealer. Front fog lights 8 – Access the bulb holder via the un- Any operation on (or modi- derneath of the vehicle;...

  • Page 182

    REAR AND SIDE LIGHTS: changing bulbs (1/2) Side lights/brake and Pull on the outside A of the light and 4 Side light and brake light remove the rear light unit. Bulb type: P21/5W. direction indicator lights Remove the bulb holder by releasing 5 Direction indicator lights Open the boot lid and remove screws 1.

  • Page 183

    REAR AND SIDE LIGHTS: changing bulbs (2/2) High-level brake light 6 Number plate lights 8 Side indicator lights 10 Consult an approved dealer. – Unclip light 8 by pressing tab 9; The wing mirror needs to be removed; consult an authorised dealer. –...

  • Page 184

    INTERIOR LIGHTING: changing bulbs (1/2) Courtesy light Soft lighting 2 Unclip the lens (using a flat-blade Please contact an authorised dealer. screwdriver or similar). Remove the bulb concerned. Bulb type 1: W5W. The bulbs are under pres- sure and can break when replaced.

  • Page 185: Luggage Compartment Light

    INTERIOR LIGHTING: changing bulbs (2/2) Luggage compartment light Press tab 4 to release the bulb holder and access bulb 5. Unclip light 3 by pressing the tabs on Bulb type: C5W festoon type bulb. each side (using a flat-blade screw- driver or similar).

  • Page 186

    (insert the the next time the vehicle is started, the strument panel, replace the RENAULT RENAULT card in the card reader) and message will disappear. card battery, press button 1 pulling lock/unlock the vehicle (refer to the in-...

  • Page 187

    FUSES (1/3) Fuses in passenger compartment A Clip 1 Fuses in engine compartment B Some functions are protected by fuses If any electrical component does not Remove the fuse using tweezers 1, lo- located in the engine compartment work, check the condition of the fuses. cated at the back of flap A.

  • Page 188

    FUSES (2/3) Allocation of fuses (the presence of certain fuse depends on the vehicle equipment level) 5.22...

  • Page 189

    FUSES (3/3) Number Allocation Number Allocation Number Allocation Central locking of opening Power-assisted steering Rear windscreen wiper elements Injection UCE energy management Empty location Airbag UCE energy management Headlight beam adjustment Alarm Automatic gearbox, LPG Daytime running lights Instrument panel Dipped beam headlights Brake lights Front fog lights, front...

  • Page 190: Connecting A Battery Charger

    BATTERY: breakdown recovery (1/2) To avoid all risk of sparks: Connecting a battery charger – Ensure that any electrical consumers The battery charger must be com- (courtesy lights, etc.) are switched patible with a battery with nominal off before disconnecting or recon- voltage of 12 volts.

  • Page 191

    BATTERY: breakdown recovery (2/2) Starting the vehicle using the battery from another vehicle If you have to use the battery from an- other vehicle to start, obtain suitable jump leads (with a large cross section) from an approved dealer or, if you al- ready have jump leads, ensure that they are in perfect condition.

  • Page 192

    FITTING A RADIO – In all cases, it is very important to follow the manufacturer’s instruc- tions carefully. – The specifications of the brack- Radio location 1 Door speakers 2 ets and wires (available from our network) vary depending on the Unclip the blanking cover.

  • Page 193

    ACCESSORIES Electrical and electronic accessories Before installing this type of accessory, make sure it is compatible with your vehicle. You can get advice from an au- thorised dealer. Connect accessories with a maximum power of 120 watts only. Fire hazard. No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected system may result in damage being caused to the electrical equipment and/or the components connected to it.

  • Page 194: Windscreen Wiper Blades

    WINDSCREEN WIPER BLADES (1/2) Check the condition of the wiper blades. You are responsible for their service life: – clean the blades, windscreen and rear screen regularly with soapy water; – do not use them when the wind- screen or rear screen are dry; –...

  • Page 195

    WINDSCREEN WIPER BLADES (2/2) To refit To refit the wiper blade, proceed in re- verse order to removal. Make sure that the blade is correctly locked in position. Rear screen wiper blade 5 – In frosty weather, make sure that the wiper blades –...

  • Page 196: Automatic Gearbox

    If your vehicle is the towing or R for vehicles with automatic gear- vehicle, do not exceed the maximum boxes), insert the RENAULT card in the towing weight for your vehicle (refer card reader, then press the engine start to the information on “Weights”...

  • Page 197

    Unclip cover 5 or 7 by sliding a flat tool (never use the drive shafts or any other (or the key integrated in the RENAULT part of the vehicle) card) under the cover. These towing points may only be used...

  • Page 198: Locking, Unlocking The Opening Elements

    Dealer as soon as possible. Using the RENAULT card POSSIBLE CAUSES WHAT TO DO The RENAULT card does not lock or Card battery is flat. Replace the battery. You can still lock/ unlock the doors. unlock and start your vehicle (refer to the in- formation on “Locking, unlocking the open-...

  • Page 199

    Starting conditions are not Please refer to the information on “Starting, stopping fulfilled. the engine” in Section 2. The RENAULT “hands-free” Insert the card in the card reader in order to start the card does not work. engine. Please refer to the information on “Starting, stopping the engine”...

  • Page 200

    OPERATING FAULTS (3/6) On the road POSSIBLE CAUSES WHAT TO DO Vibrations. Tyres not inflated to correct pres- Check the tyre pressures: if this is not the sures, incorrectly balanced or dam- problem, have them checked by an ap- aged. proved Dealer.

  • Page 201

    OPERATING FAULTS (4/6) On the road POSSIBLE CAUSES WHAT TO DO Steering becomes heavy. Assistance overheating. Consult an approved dealer. The engine is overheating. The cool- Engine cooling fan not working. Stop the vehicle, switch off the engine and ant temperature indicator is in the contact an approved dealer.

  • Page 202

    OPERATING FAULTS (5/6) Electrical equipment POSSIBLE CAUSES WHAT TO DO The wipers do not work. Wiper blades stuck. Free the blades before using the wipers. Faulty electrical circuit. Consult an approved dealer. Fuse damaged. Replace the fuse, refer to the information on “Fuses”.

  • Page 203

    OPERATING FAULTS (6/6) Electrical equipment POSSIBLE CAUSES WHAT TO DO Traces of condensation in the lights. Traces of condensation may be a nat- ural phenomenon caused by varia- tions in temperature. In this case, the traces will disappear slowly once the lights are switched The front seat belt reminder light An object is stuck between the floor Remove all objects from underneath the...

  • Page 204

    5.38...

  • Page 205: Technical Specifications

    Section 6: Technical specifications Vehicle identification plate ............Engine identification plate .

  • Page 206: Vehicle Identification Plates

    Vehicle identification plates the information shown on the ve- 4 MAM (Maximum Authorised Mass) hicle identification plate should be for front axle. quoted on all correspondence or 5 GTW (Gross train weight: vehicle orders. fully loaded, with trailer). 6 MPAW (Maximim Permissible the presence and location of the in- Weight) for front axle.

  • Page 207: Engine Identification Plates

    enGine identification plates please quote the information on the engine plate or label A in all corre- spondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine number.

  • Page 208

    dimensions (in metres) 0,865 2,605 0,649 1,524 4,121 1,579* 1,504 1,957 * unladen...

  • Page 209: Engine Specifications

    enGine specifications Versions 0.9 tce 1.2 tce 1.5 dci engine type H4B Turbo H5F Turbo K9K Turbo (see engine plate) cubic capacity (cc) 1 197 1461 type of fuel It is essential that you use unleaded It is essential that you use unleaded Diesel: the label located octane rating petrol of the octane rating stated on...

  • Page 210

    WeiGhts (in kg) the weights indicated for a basic vehicle without options: they vary depending on the your vehicle’s equipment. consult your approved dealer. maximum permissible all-up weight (mmac) Weights are indicated on the vehicle identification plate (refer to maximum permissible all-up weight (mmta) the information on “Vehicle identification plates”...

  • Page 211: Replacement Parts And Repairs

    Replacement paRts and RepaiRs Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the repair order.

  • Page 212

    seRVice sheets (1/6) Vin: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □ ........□ anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □...

  • Page 213

    seRVice sheets (2/6) Vin: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □ ........□ anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □...

  • Page 214

    seRVice sheets (3/6) Vin: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □ ........□ anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □...

  • Page 215

    seRVice sheets (4/6) Vin: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □ ........□ anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □...

  • Page 216

    seRVice sheets (5/6) Vin: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □ ........□ anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □...

  • Page 217

    seRVice sheets (6/6) Vin: .................. Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □ ........□ anti-corrosion check: OK □ Not OK* □ *See specific page Date: Miles (Km): Invoice number: Comments/miscellaneous type of operation: stamp Service □...

  • Page 218

    anticoRRosion check (1/5) If the continuation of the warranty is subject to repair, it is indicated below. Vin: ............stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: stamp Date of repair: Repair to be carried out: stamp Date of repair: 6.14...

  • Page 219

    anticoRRosion check (2/5) If the continuation of the warranty is subject to repair, it is indicated below. Vin: ............stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: stamp Date of repair: Repair to be carried out: stamp Date of repair: 6.15...

  • Page 220

    anticoRRosion check (3/5) If the continuation of the warranty is subject to repair, it is indicated below. Vin: ............stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: stamp Date of repair: Repair to be carried out: stamp Date of repair: 6.16...

  • Page 221

    anticoRRosion check (4/5) If the continuation of the warranty is subject to repair, it is indicated below. Vin: ............stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: stamp Date of repair: Repair to be carried out: stamp Date of repair: 6.17...

  • Page 222

    anticoRRosion check (5/5) If the continuation of the warranty is subject to repair, it is indicated below. Vin: ............stamp Corrosion repair operation to be carried out: Date of repair: Repair to be carried out: stamp Date of repair: Repair to be carried out: stamp Date of repair: 6.18...

  • Page 223: Alphabetical Index, To The Rear Seat Belts

    AlphAbeticAl index (1/5) ABS ..............1.44, 2.18 → 2.21 catalytic converter............. 2.9 – 2.10 accessories................ 5.27 central door locking ......1.4 → 1.8, 1.11 → 1.13 accessories socket ............3.20 changing a bulb .............5.13 → 5.19 additional methods of restraint .......... 1.25 changing a wheel............

  • Page 224

    AlphAbeticAl index (2/5) driving ..2.2 → 2.5, 2.9 – 2.10, 2.14 → 2.16, 2.18 → 2.30, front seat adjustment ............1.15 2.33 → 2.35 front seats ................4.15 driving position adjustment ............1.14 → 1.16 settings ............1.16 → 1.18 fuel advice on fuel economy ..........

  • Page 225

    AlphAbeticAl index (3/5) indicators: reversing lights ............. 5.17 direction indicators ............1.64 side lights ..........1.61, 5.13 → 5.16 instrument panel ..........1.42 → 1.48 load permitted on the roof............ 6.6 instrument panel ............1.42 → 1.56 locking the doors .............1.2 → 1.13 instrument panel messages........1.47 →...

  • Page 226

    ............3.22 – 3.23 storage compartment..........3.15 → 3.19 rear view mirrors ..............1.60 storage compartments ...........3.15 → 3.19 RENAULT ANTI-INTRUDER DEVICE (RAID) ....1.13 sun visor ................3.19 RENAULT card switching on the vehicle ignition ........2.3 → 2.5 battery ................5.20 use .............

  • Page 227

    AlphAbeticAl index (5/5) tyres ..............4.9, 5.10 → 5.12 unlocking the doors ..........1.11 – 1.12 variable power-assisted steering ........1.57 vehicle identification plates ..........6.3 ventilation ..............3.2 → 3.11 warning lights............1.42 → 1.56 washing ..............4.11 – 4.12 weights ................6.6 wheelbrace ................

  • Page 229

    à999108573Rë ë ñ ä RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 13-15, QUAI LE GALLO 92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / TÉL. : 0810 40 50 60...

This manual also for:

?aptur

Comments to this Manuals

Symbols: 0
Latest comments:
  • Gab Mar 21, 2017 02:56:
    Can the handsfree keycard interfere with a pacemaketk
