  • Page 2 ACEA : A3/B3 Consult your Renault Dealer All types MANUAL GEARBOX RENAULTMATIC D2 All types POWER STEERING DEXRON II FRELUB 650 All types BRAKE FLUID DOT 4 ELF recommends its lubricants as approved by RENAULT. For more information, go to www.elf-lub.com...
  • Page 3 Welcome to your new Renault This driver’s handbook contains the information necessary: • to enable you to get to know your Renault, to use it to the best advantage and to benefit from all the latest technical developments it incorporates.
  • Page 4 Brief overview • Tyre pressures ......................0.04 • Adjusting the seats and driving position ..........1.09 1.12 • Child restraint devices ................1.22 1.31 • Warning and indicator lights ..............1.34 1.45 • De-icing/demisting .............. 1.51 - 3.04 - 3.05 - 3.10 •...
  • Page 5 Sections Getting to know your car ..............Driving ....................... Your comfort ....................Maintenance ....................Practical advice ................... Technical specifications ................ Alphabetical index ..................0.03...
  • Page 6 (1) For vehicle with trailer, refer to the information on Weights in section 6. Refer to the label affixed to the driver's door pillar. Consult a Renault Dealer should you wish to fit tyres of dimensions other than those listed above. Tyre safety, spare wheel and use of snow chains.

  • Page 7: Table Of Contents

    Section 1: Getting to know your car Keys - Remote control unit ..........................1.02 Doors ..............................1.03 1.05 Engine immobiliser ............................1.06 Head restraints - Seats ......................... 1.07 1.10 Front seat belts ............................1.11 - 1.12 Methods of restraint in addition to front seat belts ................. 1.13 1.18 Rear seat belts ............................
  • Page 8 Dealer. frequency as the remote control). • To replace a remote control, it will be necessary to take the vehicle to your Renault Dealer because both the vehicle and the remote control are needed to initialise the 1 Remote control locking system.

  • Page 9: Doors

    OPENING AND CLOSING THE DOORS Locking and unlocking the Locking, unlocking the doors doors manually Press remote control Front doors: approximately one second to lock Use the key to lock or unlock the or unlock the doors. (Indicator door. light 2 on the key will light up.) Tailgate: The hazard warning lights flash twice to indicate that the doors have...
  • Page 10 (padlock side) for about the doors are properly closed. If 5 seconds, until you hear the beep. they are closed correctly, consult your Renault Dealer. To deactivate it Also make sure that locking has not With the ignition on, press the been inadvertently deactivated.
  • Page 11 OPENING AND CLOSING THE DOORS Opening the doors from the Opening the doors from inside outside Move handle 3. Unlock using the remote control or the key (the key must be pushed Lights on warning buzzer into the lock 1 as far as it can go). A warning buzzer will sound when Place your hand behind handle 2 one of the front doors is opened if...

  • Page 12: Engine Immobiliser

    Renault Dealer because only Indicator light 1 lights up for three dealers in the Renault network are seconds when the ignition is turned qualified to repair the engine on and then goes out. immobiliser. You can then start the engine.
  • Page 13 FRONT HEAD RESTRAINT To refit the head restraint Insert the rods into the sleeves, with the notches facing the front. Lower the head restraint until it locks in position. To adjust the angle of the head restraint The angle of the head restraint can be adjusted.
  • Page 14 REAR HEAD RESTRAINT Side head restraint Centre head restraint To raise it: To raise it: Simply slide it upwards (only one Simply slide it upwards (only one position possible). position possible). head restraint To remove it: To remove it: important for safety. Ensure Press tabs 1 on the head restraint Press tabs 1 on the head restraint that it is in place and in the...
  • Page 15 FRONT SEATS To adjust the lumbar support: Use button 4. To move forwards or backwards: To raise or lower the driver's seat: Pull lever 1 up to unlock the seat. Use button 3. Release the lever in the required position and ensure that the seat is locked in place.
  • Page 16 FRONT SEATS (continued) Access to the rear seats Heated seats (Initiale version) Pull lever 1 towards you and tip the From the rear, pull the lever 3 to tip the seat forwards. seat forwards. With the ignition on, press switch 2; the corresponding indicator light on The seat has a memory which the instrument panel will light up.

  • Page 17: Front Seat Belts

    FRONT SEAT BELTS Always wear your seat belt when Adjusting your driving position travelling in your car. Comply with • Sit with your back firmly against the local legislation in the particular the seatback. country you are in. This is essential to ensure that your spinal cord is in the correct Before driving off: position.
  • Page 18 - unwind it again. - if the problem persists, consult your Renault Dealer. Unlocking: - Press the button 5, the belt is rewound onto the inertia reel. - Guide the buckle to help the Locking: operation.

  • Page 19: Methods Of Restraint In Addition To Front Seat Belts

    Depending on the force of the • Only qualified Renault Network impact the system may engage: personnel may work on the pretensioner system; otherwise - the seat belt;...
  • Page 20 Renault Dealer. detector and a monitor controlling lower part of the windscreen and on the electrical trigger system for the The seat belt pretensioners and the door box section indicate that gas generator;...
  • Page 21 Service bag(s) inflate(s) rapidly, message. cushioning impact driver's head and chest against the Consult your Renault Dealer as soon steering wheel front as possible. Your protection will be passenger's head against reduced until this problem is dashboard. The air bag then deflates rectified.
  • Page 22 • As a safety precaution, have the air bag system checked if your vehicle has been involved in an accident, is stolen or broken into. • When selling or lending the vehicle, inform the user of these points and hand over this handbook with the vehicle. • When scrapping your vehicle, contact your Renault Dealer for disposal of the gas generator(s). 1.16...
  • Page 23 • Do not attach any objects (pin, logo, clock, etc.) to the steering wheel boss. • The steering wheel boss must not be removed (except by authorised Renault Network personnel). • Do not sit too close to the steering wheel. If you sit with your arms slightly...
  • Page 24 Consult your Renault Dealer to find out if these covers may be purchased from Renault outlets. The use of any covers other than those designed for your vehicle (and including those designed...

  • Page 25: Rear Seat Belts

    REAR SEAT BELTS The strap must pass through the side of the head rest. Clip the black buckle into the black unlocking catch 4 and then fit the last sliding buckle 2 into the catch 5. Note: Label 3 will remind you of these instructions.
  • Page 26 REAR SEAT BELTS (continued) If you have to fold down the part of the rear seat behind the front left-hand seat: - lift the seat base 2 against the front seat. - remove the head rest; - lower seatback while holding catch 1 so that it remains Before replacing the rear visible when the seatback is...
  • Page 27 • No modification may be made to the component parts of the restraint system (belts and seats and their mountings) fitted originally. For special applications (e.g. fitting a child seat) consult your Renault Dealer. • Do not use any devices which give any play in the belts (clothes pegs, clips, for example).

  • Page 28: Child Safety

    CHILD SAFETY In all countries there are regulations Child restraints for which approval governing the use of restraint was obtained after January 1992 systems for children and babies. offer a much higher level of safety than those approved before that In Europe children under 12 years date.
  • Page 29 CHILD SAFETY (continued) SEATS AGE GROUP At the front, At the rear, At the rear, At the rear, passenger's side right side seat centre seat left side seat < 10 kg or 22 lb U - L U - L (0-9 months) <...
  • Page 30 Renault vehicles. obtained from a Renault Dealer. Consult your Renault Dealer and If your vehicle is fitted with an ask him to help you install it.
  • Page 31 CHILD SAFETY (continued) Place the head restraint at the top position to allow you to press the seat back of the child seat firmly against the vehicle seat back. Category: Category: - under 13 kg or 28 lb - from 9 to 18 kg or 20 to 40 lb (9 - 24 months) (9 - 48 months) Between the ages of 2 and 4, a...
  • Page 32 CHILD SAFETY (continued) booster seat with If a booster seat without a seatback height-adjustable seatback and a is used (figure 4), the car's head belt guide are recommended as this restraint must be adjusted to suit the child's stature; the upper edge of the will allow the belt to be worn as close to the base of the neck as head restraint must be at the same...
  • Page 33 CHILD SAFETY (continued) • No modifications may be made to the component parts of the restraint system (belts and seats and their mountings) fitted originally. • Follow carefully the fitting instructions provided by the manufacturer of the restraint system. • Always avoid dressing the child in bulky garments and do not place any objects between the child and the restraint system.
  • Page 34 CHILD SAFETY (continued) DANGER A rear-facing child/baby seat must not be fitted to the front passenger seat. The child may suffer very serious injuries if the air bag inflates. Label 5 (on the front passenger door frame) and label 6 (beneath the sun visors) will remind you of these instructions.
  • Page 35 - Two anchoring rings 1 per seat located between the seat the seatback. - A special Renault child seat fitted with two catches which hook onto the two rings. • Make sure that there is Only the specific Renault seat is nothing obstructing the type approved for this vehicle.
  • Page 36 CHILD SAFETY (continued) Installation principle Fitting a child seat Front-facing Isofix seat Rear-facing Isofix seat - Before fitting and using the seat, read the instructions provided When a front-facing child seat is When a rear-facing child seat is carefully; installed, the front seat must not be installed, the front seat must not be moved back beyond the halfway moved forward beyond the halfway...
  • Page 37 To access the rings when first fitting right to left; the seat, contact your Renault - Push on the base of the seat firmly Dealer for details. to bring it into contact with the seatback and make sure it is securely in position.

  • Page 38: Driver's Layout, Left-Hand Drive

    DRIVER’S LAYOUT, LEFT-HAND DRIVE 10 11 12 13 14 15 25 24 22 21 1.32...
  • Page 39 DRIVER’S LAYOUT, LEFT-HAND DRIVE (continued) The equipment fitted, described below, depends on the version, option and country. 22 Accessories socket 1 Driver's control for heating, 11 Control instruments ventilation, air conditioning 12 Switches: 23 Handbrake • De-icing/demisting for rear 2 Speaker screen, rear-view mirrors and 24 Upper glove box windscreen...

  • Page 40: Driver's Layout, Right-Hand Drive

    DRIVER’S LAYOUT, RIGHT-HAND DRIVE 20 19 26 25 1.34...
  • Page 41 DRIVER’S LAYOUT, RIGHT-HAND DRIVE (continued) The equipment fitted, described below, depends on the version, option and country. 1 Passenger electric window 13 • Switch for windscreen and 22 Steering wheel height adjuster switch rear screen wash/wipe • On-board computer 23 Cruise control speed instrument panel information...

  • Page 42: Instrument Panel

    INSTRUMENT PANEL If these warning lights light up, you must stop as soon as traffic conditions allow: 1.36...
  • Page 43 If it lights up continuously, consult system. or brake pad wear. It may be your Renault Dealer as soon as dangerous to continue driving. possible. Call a Renault Dealer. If it flashes, reduce the engine speed until the light stops flashing.
  • Page 44 INSTRUMENT PANEL If these warning lights light up, you must stop as soon as traffic conditions allow: 1.38...
  • Page 45 Consult a Renault Dealer as not go out until the belt is fastened. soon as possible. 1.39...
  • Page 46 INSTRUMENT PANEL If these warning lights light up, you must stop as soon as traffic conditions allow: 1.40...
  • Page 47 You can start the engine once the conditions allow. OK message is displayed. - some radio information, - the OK and diesel preheating Call a Renault Dealer. Diesel version symbol. STOP message with symbol: message appears for There is priority management...
  • Page 48 If the warning disappears, not, check the coolant level (having the message will only let the engine cool down). Call for continue being displayed the assistance of a Renault Dealer if for the brake fluid level necessary. warning. Always consult your Renault Dealer.
  • Page 49 Indicates a fault on the system for recommendation that you should checking the oil pressure circuit. visit a Renault Dealer as soon as possible. ESP warning symbol A beep warns you that the fuel tank is about to reach minimum level Electronic fault symbol (approximately 8.5 litres depending...
  • Page 50 INSTRUMENT PANEL (continued) Oil level indicator C: If the oil is below the minimum level The car must be parked on - Gauge C is displayed for about 20 level ground and the engine seconds and the oil level warning should have been switched symbol may be seen on the several...
  • Page 51 INSTRUMENT PANEL (continued) Fuel level information D Speedometer E 6 - Radio information When there is a change in radio When the level is almost at To obtain the speed in MPH, turn conditions, corresponding minimum (about 8.5 litres of reserve the ignition key to the accessories message will...

  • Page 52: On-Board Computer

    ON-BOARD COMPUTER 1 - Display G Interpreting certain values displayed after a reset: 2 - Reset button The values showing average fuel - press and hold button 2 consumption, range and average speed will become more stable and Zeroing will occur automatically Therefore, average fuel...
  • Page 53 ON-BOARD COMPUTER (continued) Examples of displays Interpreting the display selected by successive presses of button 2 1 - Distance travelled (in km or miles) since the last reset: 2 - Average speed (in KM/H or MPH) since the last reset: (Value displayed after 400 metres or 0.2 miles have been covered.) 3 - Average fuel consumption (in litres per 100 km or mpg) since the last reset: - The value is displayed after the vehicle has driven 400 metres or 0.2 miles...
  • Page 54 • mileage equal to 0 km or date of service reached. The symbol flashes constantly regardless of the information displayed. Reinstalling the display after servicing: consult your Renault Dealer to intialise your display after servicing. 1.48...

  • Page 55: Rear-View Mirrors

    REAR-VIEW MIRRORS Interior rear-view mirror Autodimming rear-view mirror Electrically adjusted door mirrors This is adjustable. If the headlights of the vehicle behind shine on to the mirror, it Turn button 1 to: Lower the small lever 2 located dims slightly to prevent dazzling. - Position A to adjust the left-hand behind the rear-view mirror when Press button 1 to switch on the...

  • Page 56: Steering Wheel

    STEERING WHEEL Adjusting the steering wheel The position of the steering wheel is adjustable. Lower lever 1 and place the steering wheel in the required position: lift the lever to lock the steering wheel in place. For safety reasons, only adjust the steering wheel when vehicle...
  • Page 57 DEMISTING - DE-ICING Electric windscreen de-icing This function is activated at the same time as rear screen de-icing. De-icing switches off automatically. The timed period varies as a function of atmospheric conditions but is never longer than 12 minutes. Heated rear screen With the engine running, press button 1.
  • Page 58 WINDSCREEN WIPER/WASHER Vehicle fitted with windscreen Automatic selection of wiping wiper with rain sensor speed With the ignition on, move the stalk The wiping speed you select while handle 1. you are driving is reduced to a lower speed when the vehicle stops: •...

  • Page 59: Windscreen Wash/Wipe

    WINDSCREEN WASHER/WIPER (continued) Windscreen washer, headlight washer With the ignition on, pull the stalk 1 towards you. In frosty weather, make sure the - Headlights off: wiper blades do not ice over (risk of motors overheating). The windscreen washer will be activated.
  • Page 60 REAR SCREEN WASH/WIPE Special note rear screen wiped intermittently if reverse gear is selected when windscreen wipers are in operation. Rear screen wiper with Rear screen wash/wipe timer With the ignition on, move the end With the ignition on, move the end of stalk 1 to align with mark 2 of stalk 1 to align with mark 2 opposite the symbol.
  • Page 61 EXTERIOR LIGHTING AND SIGNALS Lights on warning buzzer A warning buzzer will sound when a front door is opened and the lights are left switched on after the ignition has been switched off (to prevent discharge of the battery). Side lights Headlight main beam Turn the end of the stalk 1 so With stalk 1 in the dipped...
  • Page 62 EXTERIOR LIGHTING AND SIGNALS (continued) The front and rear fog lights will be switched off when the exterior lights are switched off. Front fog lights Rear fog lights Move the central ring 4 of Turn the central ring 4 stalk 1 to align the symbol opposite on the stalk to align the symbol with the mark 5.
  • Page 63 HORN AND SIGNALS Horn Hazard warning lights Direction indicators Press the end of stalk 1 or press Press switch 2. Move stalk 1 parallel to the steering firmly on either point A on the wheel and in the direction you are This switch lights up all four steering wheel spokes.

  • Page 64: Fuel Tank

    Repriming the the new cap is of the diesel fuel circuits section. During filling, hang the cap on hook same type. Consult your Renault Dealer. Never handle the cap near a source of heat or flame.
  • Page 65 Renault Network This system is intended to disable who must ensure that: and thus isolate the fuel supply system if a severe impact occurs.
  • Page 66 1.60...
  • Page 67 Section 2: Driving (Advice on use relating to fuel economy and the environment) Running in ................................ 2.02 Ignition switch - Starting the engine/Stopping the engine ..............2.03 - 2.04 Special features: petrol versions ........................2.05 diesel versions ........................2.06 Advice on anti-pollution, how to economise on fuel, driving ............2.07 2.09 Environment ..............................

  • Page 68: Running In

    RUNNING IN Petrol versions Diesel version For the first 625 miles (1000 km) For the first 750 miles (1500 km), do do not exceed 70 mph (130 km/h) not exceed 70 mph (110 km/h) in in the highest gear, or 3 000 to 5th gear and do not let the engine 3 500 rpm.
  • Page 69 IGNITION SWITCH / STARTING AND STOPPING THE ENGINE - “Ignition on” position M Starting the engine The ignition is switched on: In the case of an automatic gearbox • Petrol version: the engine may be Refer information started. automatic gearboxes in section 2. •...
  • Page 70 STARTING/STOPPING THE ENGINE (continued) Diesel injection In cold weather (Below –15°C) Cold or warm engine Depress the clutch pedal and Turn the ignition key to the activate the starter. ignition-preheating position and Let the engine idle for a few seconds hold it there until the preheating before gradually talking your foot warning light goes out and the “OK”...
  • Page 71 If the fault cannot be identified, do not persist in attempting to start the engine and call a Renault Dealer. Do not park the car or run the engine in locations where combustible substances or...
  • Page 72 SPECIAL FEATURES OF DIESEL VERSIONS Diesel engine speed Precautions to be taken in winter Diesel engines are fitted with injection equipment which To avoid any problems in icy prevents overrevving of the engine conditions: irrespective of the gear in use. There - ensure that the battery is always is thus no point in continuing to fully charged;...

  • Page 73: Advice On Anti-Pollution, How To Economise On Fuel, Driving

    Dealer for this information. correctly, use it carefully and watch Have your vehicle checked and your driving style. adjusted by your Renault Dealer in • Idling speed: this does not require accordance with the instructions in adjustment. the vehicle’s Servicing booklet.
  • Page 74 ADVICE ON ANTIPOLLUTION AND HOW TO ECONOMISE ON FUEL, DRIVING (continued) • Avoid fierce acceleration. • Do not overrev the engine in the intermediate gears. Always use the highest ratio possible without labouring the engine. • Do not try to maintain the same speed up a hill;...
  • Page 75 ADVICE ON ANTIPOLLUTION AND HOW TO ECONOMISE ON FUEL, DRIVING (continued) • For vehicles with conditioning, extra fuel consumed in the urban cycle can be as much as 2 litres per 100 km: switch the system off when it is not needed.

  • Page 76: Environment

    ENVIRONMENT Your vehicle has been designed • 95% of the plastic components in with the aim of caring for the your vehicle are marked with a environment. symbol which allows principal component material to • All versions are equipped with a be identified.

  • Page 77: Gear Lever

    GEAR LEVER The reversing lights will light up as soon as reverse gear is selected (ignition on). Vehicles fitted with parking assistance - Refer to the Parking assistance section for more details. To change gear Make sure you engage the gear lever in the positions marked on the lever knob.
  • Page 78 HANDBRAKE POWER STEERING To apply Never leave the steering wheel on full lock when the car is parked if Pull the lever up. you have power-assisted steering The lever should travel about fitted, as this may damage the 10 notches to hold the vehicle. Your pump.

  • Page 79: Anti-Lock Braking System (Abs)

    In an comes on, it is essential emergency, therefore, apply that you stop as soon as continuous, heavy pressure to traffic conditions allow. the brake pedal. There is no need Contact a Renault Dealer. to pump it repeatedly. 2.13...

  • Page 80: Cruise Control

    CRUISE CONTROL Controls Indicator lights When road conditions permit (fluid or motorway traffic), cruise control 1 - Cruise control main “On/Off” This green indicator light allows you to take your foot off the switch. lights up on the instrument accelerator while your panel to indicate that the...
  • Page 81 CRUISE CONTROL (continued) Switching on Driving Exceeding the cruise control speed Move the switch 1 upwards; the Once a cruising speed is stored you green light lights up on the take your foot In the event of an emergency instrument panel. accelerator pedal.
  • Page 82 CRUISE CONTROL (continued) Switching off the ignition The cruising speed will be lost from memory when the ignition is switched off. Switching the function off Recalling the cruising speed Cruise control is deactivated when: If the speed is stored, it can be recalled by pressing R on key 3 on - the brake pedal is depressed, the condition that the speed is...

  • Page 83: Speed Limiter

    SPEED LIMITER Controls Indicator light The speed limiter function allows you to decide on a maximum 1 Speed limiter main “On/Off” This orange indicator light driving speed. switch lights up on the instrument This may be useful, for example, in panel to indicate that the 2 Limit speed storage and control town driving or in areas with speed...
  • Page 84 SPEED LIMITER (continued) Driving When a limited speed is stored, press on the accelerator pedal until you reach the limited speed. From this point, no effort on the accelerator pedal will allow you to exceed programmed speed except emergency (see information exceeding limited speed).
  • Page 85 SPEED LIMITER (continued) Exceeding the limited speed In the event of an emergency It is possible to exceed the limited speed at any time. To do this: depress accelerator pedal firmly and fully (beyond the point of resistance). The SET xxx symbol on the instrument panel flashes to inform you that the cruising speed is being exceeded.
  • Page 86 ELECTRONIC STABILITY PROGRAM: E.S.P. This system helps you to keep When the function is in operation, control of the vehicle in “critical” indicator light 1 flashes. driving conditions (avoiding an obstacle, loss of grip in a bend, etc.). This function additional aid in case of critical driving conditions allow...
  • Page 87 1 lights up on the instrument panel together with SERVICE message multifunction warning light 3. Go to your nearest Renault Dealer. Disabling the function As the E.S.P. offers additional safety, it is recommended that you do not The function is deactivated drive with the function disabled.

  • Page 88: Traction Control System

    TRACTION CONTROL SYSTEM This system helps to limit skidding The system also adjusts the engine on drive wheels and to control the speed to the grip available under the vehicle when pulling away or wheels, independently of the action accelerating. exerted on the accelerator pedal.
  • Page 89 If the system detects an operating fault, warning light 1 lights up on the instrument panel together with SERVICE message multifunction warning light 3. Go to your nearest Renault Dealer. Disabling the function In some situations (driving on very Disabling traction control wet ground: snow, mud, etc., or...
  • Page 90 AUTOMATIC GEARBOX Driving With the gear lever in position P or N, switch on the ignition. P R N D Move the lever from position P with your foot on the brake pedal. The lever must only be engaged in D or R when the vehicle is stationary.
  • Page 91 AUTOMATIC GEARBOX (continued) Accelerating and overtaking Special cases In certain driving conditions (e.g.: Quickly depress the accelerator engine protection, operation of the pedal completely (until you pass electronic stability program: E.S.P., the point of resistance). etc.) the automated system may This will activate the “kickdown”...
  • Page 92 (on the multi-function you change to manual mode. warning light), it indicates a fault. This will prevent the automatic Consult a RENAULT Dealer as soon gearbox changing gears as possible. successively when climbing, and permit engine braking on long descents.

  • Page 93: Parking Assistance

    Consult your Renault Dealer. The driver should always pay attention to sudden occurrences during driving: always ensure that there are no moving obstacles (such as a child, animal, pram or bicycle...) or small, narrow objects...
  • Page 94 2.28...
  • Page 95 Section 3: Your comfort Heating and ventilation: design and features ....................3.02 air vents ...................... 3.02 - 3.03 heating and air conditioning ..............3.04 3.07 automatic air conditioning ..............3.11 3.17 passenger heating control ................3.06 - 3.13 advice on use .................... 3.08 3.10 Interior lights ............................
  • Page 96 HEATING - VENTILATION 3.02...

  • Page 97: Air Vents

    HEATING - VENTILATION (continued) Design and features Air vents Instrument panel air vents (air outlets) 1 Air diffusers for rear seats Air from the outside enters the In order to provide individual passenger compartment via the ventilation, side vents 6 and centre 2 Air diffusers for front footwells vents located above the lenses and vents 8 are controlled manually:...
  • Page 98 HEATING - VENTILATION manual air conditioning version (continued) Controls 5 - Adjusting the air 1a 1b temperature. 1a-1b - De-icing: “See clear” button To raise the temperature, turn the 2 - Air conditioning button to the right and in the reverse 3 - Air distribution control direction to lower it.
  • Page 99 HEATING - VENTILATION manual air conditioning version (continued) (continued) 3-4-8 - Distribution of blown air 7 - Air flow Demisting of the rear screen and rear-view mirrors is also activated. Move the button to the right to We advise the following positions: increase the speed of ventilation.

  • Page 100: Passenger Heating Control

    HEATING - VENTILATION passenger heating control (continued) When in the passenger seat, you can adjust the heating temperature on your side. To do so: - Activate the control by pressing button 1, the indicator light will come on. - To raise the temperature, turn the button to the right;...
  • Page 101 HEATING - VENTILATION air conditioning (continued) 2 - Air conditioning 9 - Isolation of the passenger 1a 1b compartment Air conditioning must be used with the windows closed for it to be The air is drawn from the passenger effective. compartment recirculated without admitting air from outside.

  • Page 102: Advice On Use

    HEATING - VENTILATION advice on use (continued) To cool your vehicle (after it has been parked in the sun) Lower the windows and start the engine to disperse the hot air . Open the dashboard vents then activate: - the “summer comfort” air supply, - the air conditioning, - maximum air flow for a few minutes,...
  • Page 103 HEATING - VENTILATION advice on use (continued) (continued) To heat your vehicle in cold weather Close the dashboard vents then activate: - the “winter, mid-season comfort” air supply, - the temperature in the maximum heat position, - maximum air flow for a few minutes once the engine has begun to warm up.
  • Page 104 HEATING - VENTILATION advice on use (continued) (continued) Demisting/de-icing your field of 1a 1b vision Close the dashboard vents then activate the See clear function (1b, two indicator lights come on). As soon as your field of vision is clear, change to one of the air distribution buttons 1a-3-4 or 8 to suit you.
  • Page 105 AUTOMATIC AIR CONDITIONING 5 - Adjusting passenger Ambient temperature compartment temperature (+) (automatic mode) 6 - Switching on automatic mode Automatic air conditioning is a system which will ensure that the 7 - Adjusting the ventilation speed temperature passenger 8 - Adjusting passenger compartment is maintained at a compartment temperature (–)
  • Page 106 AUTOMATIC AIR CONDITIONING (continued) If you attempt to select a temperature above 28°C, the display 4 will indicate HI (high). The system will then operate at the maximum temperature setting. Automatic control will no longer be active. attempt select The figure on the display is the temperature below 16°C,...
  • Page 107 AUTOMATIC AIR CONDITIONING (continued) Passenger control The control is overridden when the The passenger can adjust the See clear function is selected. temperature setting passenger side. To do so: - Select an air temperature setting between 16 and 28° using keys 12 or 13.
  • Page 108 AUTOMATIC AIR CONDITIONING (continued) Pressing the button a second time Electrical de-icing activates the See clear function (two windscreen and the rear screen indicator lights come on). It allows Press button 1b: the indicator light fast demisting and de-icing of the in it will light up.
  • Page 109 AUTOMATIC AIR CONDITIONING (continued) Automatic mode is switched off by Varying the blower speed pressing one of the following In automatic mode, the system uses buttons. the most suitable amount of air to reach and maintain the desired The indicator light in button 6 will temperature.
  • Page 110 AUTOMATIC AIR CONDITIONING (continued) Switching the air conditioning Air recirculation mode on or off - Press button 11, the operating indicator light will come on. In automatic mode, the system switches conditioning In this position, air is taken from the system on or off, depending on the passenger compartment...
  • Page 111 If both these points are correct, switch off the system and consult a Renault Dealer. Storing data If the ignition has been switched off for less than 15 minutes, the system...
  • Page 112 INTERIOR LIGHTING Automatic operation interior lights controlled lighting position) Courtesy light 1 and map Light beneath the sun visor reading light 2 - The interior lighting is switched Lower the sun visor. on for approximately 15 seconds Use switch 3 to select between Press switch 4.
  • Page 113 INTERIOR LIGHTING (continued) Automatic operation interior lights controlled lighting position) Rear courtesy light 5 and map reading light 6 - The interior lighting is switched on for approximately 15 seconds Use switch 7 to select between: if the doors are unlocked by - permanent lighting, remote control.

  • Page 114: Interior Lights

    INTERIOR LIGHTS (continued) Footwell lighting Floor lighting Luggage compartment light - Lighting 1 is controlled by one of - A light 2 located in the lower - The light 3 is controlled by the the doors opening. section of each door lights up the tailgate opening.
  • Page 115 FRONT ELECTRIC WINDOWS Reinitialising In the event of a power failure (e.g.: battery flat or disconnected, power supply lead broken, fuses blown ...) Once the fault has been remedied: - open the door - switch on the ignition - lower the window - close the door - lift the switch controlling closure of the window...

  • Page 116: Electric Windows

    REAR ELECTRIC WINDOWS To raise: Press and hold switch 6. Switches 3 and 4 (as illustrated on the previous page) control the rear windows from the driver's seat. Rear electric windows To lower Child safety Switch prevents Press switch 6 briefly to lower the operation of the rear window completely.

  • Page 117: Windscreen/Sun Visor

    WINDSCREEN/SUN VISOR Windscreen with reflective Vanity mirror layers Lift the cover 2 on the sun visor. This windscreen reflects the sun and, particular, limits infrared rays entering the passenger compartment. An area 1 is provided for affixing passes to the windscreen (e.g. motorway permits, car park season tickets, etc.).
  • Page 118 Clean the seal every three months “Full Air” position using products selected This position allows you to open Renault's Technical Department. simultaneously: open sunroof - the front and rear windows immediately after the vehicle has - the sunroof...

  • Page 119: Sunroof Blinds

    SUNROOF BLIND Front sunroof blind Rear sunroof blind Lift up the handle 4 to unlock and With the ignition on: roll up the blind. Ensure that closing the To roll up sunroof will not pose a risk Press switch 3 briefly. to the passengers.

  • Page 120: Passenger Compartment Storage

    PASSENGER COMPARTMENT STORAGE Centre console compartment Drawer Passenger side glove box Lift cover open Press 3 and release to open the Press on the cover 4 to open. compartment. drawer. There is a clip to hold a pen inside The storage compartment lights up Push the drawer in to close it.
  • Page 121 PASSENGER COMPARTMENT STORAGE (continued) Front central arm rest block Door pockets 2 Rear pockets 3 Lift cover 1. Slide the armrest to adjust it to the position of the front seat. 3.27...

  • Page 122: Ashtrays/Cigarette Lighter

    STORAGE COMPARTMENTS/ASHTRAY/CIGARETTE LIGHTER Seatback pouch Ashtray in front console Accessories socket (cigarette lighter type) The pouch 1 will hold slim To open, press the centre of the documents. cover downwards. With the ignition switched on, raise compartment opens automatically. tab 4 and connect the accessory. To empty the ashtray, press the The accessories socket should only bottom of the open cover.

  • Page 123: Rear Parcel Shelf

    REAR PARCEL SHELF Rear parcel shelf 1 Flat floor function To remove, unhook the two straps 2 You can store the parcel shelf flat in from the tailgate. the luggage compartment by turning it over, thus obtaining a flat floor Lift the rear parcel shelf slightly and when the bench seat is folded pull it towards you.

  • Page 124: Rear Bench Seat

    REAR BENCH SEAT To fold down the seatback The seat and the seatback may be folded down in one or two parts to Remove the rear head restraints. allow bulky objects to be carried. Press button 2 and lower the seatback.

  • Page 125: Luggage Compartment

    LUGGAGE COMPARTMENT To close the tailgate: The luggage compartment lid locks and unlocks at the same time as the Lower the tailgate using handle 3 doors when the remote control is inside the tailgate to help you. activated. When the luggage compartment lid shoulder height, release...
  • Page 126 TRANSPORTING ITEMS IN THE LUGGAGE COMPARTMENT Always position objects transported so that the largest surface is against: - The back of the rear bench seat, for normal loading. - The folded down seat, Always position maximum loading. heaviest items directly on the floor.
  • Page 127 Section 4: Maintenance Bonnet ................................4.02 Engine oil level ............................. 4.03 - 4.04 Oil changes: Engine ............................4.05 Engine oil grade ............................ 4.06 - 4.07 Levels: Brake fluid ............................4.08 Coolant ..............................4.09 Power assisted steering pump ......................4.10 Battery ..............................4.10 Screen washer reservoir ........................

  • Page 128: Bonnet

    BONNET Closing the bonnet To close the bonnet, replace stay 3 in its holder 4, grip the bonnet in the middle and follow it down to 8 inches (20 cm) above the closed position, then release it. It will lock automatically under its own weight.

  • Page 129: Engine Oil Level

    1 litre is used every 625 miles (1000 km) after the running in When the ignition is switched on: period, consult your Renault Dealer. - If the oil level is correct, no display appears on the instrument Oil change frequency: Check the oil panel.
  • Page 130 ENGINE OIL LEVEL (continued) V6 L7X 2l F4R 2.2 dCi Topping up - filling Top up by the filler cap 1. Check the level using the gauge 2, do not exceed the “maximum” mark (B) and do not forget to replace the cap.
  • Page 131 ENGINE OIL CHANGE 2l F4R V6 L7X Plug 1 - (remove the protective plate Average capacities of oil change to reach it). (for information) V6 L7X engine : 4.9 litres Change the oil more often if the 2l F4R engine : 5 litres vehicle is subject to severe use.

  • Page 132: Engine Oil Grade

    ENGINE OIL GRADE - PETROL ENGINE External -30°C -20°C -15°C -10°C 0°C +10°C +20°C +25°C +30°C temperature ACEA A2/A3 15W40-15W50 EU countries ACEA A1*/A2/A3 10W30-10W40-10W50 ACEA A1*/A2/A3 0W30-5W30 ACEA A1*/A2/A3 0W40-5W40-5W50 * Oil for fuel economy External -30°C -20°C -15°C -10°C 0°C +10°C...
  • Page 133 DIESEL ENGINE OIL GRADE External -30°C -20°C -15°C -10°C 0°C +10°C +20°C +25°C +30°C temperature ACEA B2/B3 15W40-15W50 EU countries ACEA B2/B3 10W40-10W50 ACEA B2/B3 5W30 ACEA B2/B3 5W40-5W50 * Oil for fuel economy External -30°C -20°C -15°C -10°C 0°C +10°C +15°C +20°C...
  • Page 134 After operation hydraulic circuit, a specialist must replace the brake fluid. only fluids approved Renault’s Technical Department and which have been taken from a sealed container. Brake fluid level This should be checked frequently, especially if you notice even the slightest loss in braking efficiency.
  • Page 135 Do not If topping up is required, only use change down to a lower gear just to products approved by Renault's help engine cooling by making the Technical Department. This coolant engine rev faster; the engine cooling...

  • Page 136: Power Assisted Steering Pump

    1. cold water. For topping up or refilling with oil, Keep all flames, red-hot objects and use products approved by Renault's sparks away from the battery as Technical Department. there is a risk of explosion.

  • Page 137: Screen Washer Reservoir

    LEVELS (continued) Screen washer reservoir Capacity: - approximately: 8 litres Filling: remove the cap 1 by putting your finger over the hole 2. The level is shown by the amount of liquid in the tube 3. This reservoir also supplies the headlight washers.

  • Page 138: Air Filter

    Frequency of change vehicle. Refer to the Servicing booklet for Replacement: You are advised to your vehicle. consult your Renault Dealer. G9T-V6-L7X Remove the three mounting bolts 1, and tilt the cover towards the front of the vehicle. Change the filter element and then refit the cover.

  • Page 139: Bodywork Maintenance

    • Allow rust to form following products approved and industrial areas). minor impacts. Renault's Technical Department. - Saline atmosphere (near the sea, • Use solvents not approved by If adequate precautions are not particularly in hot weather). Renault's Technical Department...
  • Page 140 - Bird droppings which contain reapplying spray-on products periodically if your vehicle is rapidly chemicals which approved by Renault's Technical protected Renault discolour paintwork and may Department. anti-corrosion warranty. Consult even cause the paint to peel off: the anti-corrosion booklet.

  • Page 141: Interior Maintenance

    • natural soap, Renault's Technical Department • washing up liquid (with one part (or Renault accessory outlets) or of washing up liquid to 200 parts warm soapy water. Clean with a of water). sponge and dry off with a dry cloth.
  • Page 142 4.16...
  • Page 143 Section 5: Practical advice Jack - Wheelbrace - Hubcap ..........................5.02 Changing a wheel ..........................5.03 5.05 Tyres (tyre safety, wheels, winter use) ....................5.06 5.08 Wipers (replacing blades) ..........................5.09 Headlight bulbs ............................ 5.10 5.13 Rear light bulbs ............................5.14 - 5.15 Interior light bulbs ..........................

  • Page 144: Jack - Wheelbrace - Hubcap

    JACK - WHEELBRACE - HUBCAP Jack - Wheelbrace Hubcap These are located underneath the Remove it using the hook supplied rear bench seat. with your vehicle. To refit the hubcap, clip it back in To remove: place, taking care to align it with Fold the bench seat forwards (1/3 valve 2.

  • Page 145: Changing A Wheel

    CHANGING A WHEEL R 1 3 2 4 6 Park your vehicle on firm, level Use the spanner to slacken off the Fitting the jack: ground (if necessary, place a solid wheel bolts slightly. Fit it so that Offer up the jack horizontally, with support under the jack).
  • Page 146 CHANGING A WHEEL (continued) Undo the bolts and take the wheel off. Fit the spare wheel in place on the centre hub and turn it so that the mounting holes for the wheel and the hub are aligned. Tighten bolts using wheelbrace and lower the jack.
  • Page 147 CHANGING A WHEEL (continued) The vehicle is equipped With the wheels on the ground, with an emergency spare tighten the bolts. wheel which has a limited Store the damaged wheel where the use tyre, restricted for use spare wheel would normally go. up to speeds of 70 mph (120 km/h).

  • Page 148: Tyres (Tyre Safety, Wheels, Winter Use)

    Renault lead to more rapid tyre wear and Maintaining the tyres Dealer. affect safety.
  • Page 149 - the risk of blow-outs or of throwing a tread at high speed. Only use rims approved for your vehicle. Consult your Renault Tyre pressures depend on the Dealer. load and the driving speed. Adjust the pressures according Changing wheels around to the conditions of use.
  • Page 150 Renault Dealer who will be able to advise you on the choice of equipment which is most suitable for your vehicle. 5.08...
  • Page 151 SCREEN WIPERS Replacing windscreen wiper Refitting a windscreen wiper Replacing the rear screen wiper blades 1: blade blade - Lift the windscreen wiper arm. To refit the wiper blade, proceed in - Lift the wiper arm. reverse order to removal. Make sure - Disconnect the screen washer - Turn the wiper blade until it is that the blade is correctly locked in...
  • Page 152 - Remove the bulb connector. headlight bulb must - Unclip spring 2 and take out the changed by a Renault Dealer. Bulb type: W 5 W. bulb. Type of halogen bulb: H7. Do not touch the glass of the halogen bulb. Hold it by its base.
  • Page 153 Finally, carefully dry off with a soft dry cloth. Consult your Renault Dealer about the removal of deeper scratches. Direction indicator lights To refit: Cleaning products containing alcohol are not to be used.
  • Page 154 FRONT FOG LIGHTS: changing the bulbs Please consult your Renault Dealer for information on replacing bulbs and adjusting your headlights. Any work on the electrical circuit of the vehicle must be carried out by Renault network engineers, because system connected...
  • Page 155 SIDE-MOUNTED REPEATERS: changing the bulbs Unclip the side repeater 1 (using a Turn the bulb holder a quarter of a tool such small flat turn and take out the bulb. screwdriver). Bulb type: W 5 W. 5.13...
  • Page 156 REAR LIGHTS: replacing bulbs Third brake light Number plate light Open the tailgate Replace the faulty bulb. - Unclip the light (using a tool such as a flat screwdriver) in notch 2. - Remove the light by undoing both Bulb type: W 5 W. bolts 1 (using the spanner in the - Unclip the bulb holder and vehicle document pouch).
  • Page 157 REAR LIGHTS: replacing bulbs (continued) A Direction indicators. Orange P 21 W pear-shaped, bayonet type. B Fog light. P 21 W pear-shaped, bayonet type bulb. C Reversing lights. P 21 W pear-shaped, bayonet type bulb. D Side lights. P 5 W pear-shaped, bayonet type bulb.
  • Page 158 Ground lighting - Unclip the light (using a tool such - Unclip the light (using a tool such Consult your Renault Dealer about as a flat screwdriver) in notch 1. as a flat screwdriver) in notch 2. the replacement of this bulb.
  • Page 159 INTERIOR LIGHTING: changing the bulbs (continued) Front courtesy light Rear courtesy light Unclip at notch 1 (using a tool such - Turn the bulb holder 2 or 3 Unclip the light (using a tool such as as a flat-blade screwdriver). through 90°...
  • Page 160 INTERIOR LIGHTING: changing the bulbs (continued) Glove compartment light Light beneath the sun visor - Unclip the light (using a tool such - Unclip the light (using a tool such as a flat screwdriver) in notch 1. as a flat-blade screwdriver). - Turn the bulb holder a quarter of a - Turn the bulb through 90°...
  • Page 161 (due to loss or fault), you must take the vehicle and the other remote control unit to your Renault Dealer to have the assembly programmed ready for use. Use CR 2016 3 V batteries, available from your Renault Dealer.

  • Page 162: Fuses

    A wise precaution: obtain a box of spare bulbs and fuses from Also make sure that the faulty your Renault Dealer. component is correctly connected. In the event of a short circuit, isolate the battery by unscrewing the...
  • Page 163 FUSES (continued) Allocation of fuses (depending on the equipment level) (Label B) Symbol Allocation Symbol Allocation Symbol Allocation Front fog lights A.B.S. - E.S.P. Headlights Air bag Navigation/Radio Combined management Rev counter Passenger compartment Inter E.S.P. management Front and rear window washers Passenger compartment Rear right and left electric...
  • Page 164 Front blind described in section 3 to access this located in this unit. The fuses not Rear electric windows fuse box. mentioned are high amperage fuses which must be fitted by your Renault Dealer. Electric passenger seat Electric driver's seat 5.22...

  • Page 165: Loudspeakers

    Consult your Renault Dealer to find out the correct reference number. - No work may be carried out on the electrical or radio circuits, except by Renault network engineers: an incorrectly connected system may result in damage being caused to the electrical system and/or the components connected to...
  • Page 166 - An FME aerial connector; Unclip grille microphone from the Hands-free - A supply connector (+ permanent kit. + auxiliaries, earth, mute radio) located in the compartment 3 beneath the front central armrest. Consult your Renault Dealer when fitting a car phone. 5.24...

  • Page 167: Accessories

    Renault auxiliaries position. fitted to the vehicle: it is advisable network engineers: if the system...

  • Page 168: Roof Bars

    Roof bars Your vehicle is fitted with four mountings into which roof bars may be fitted. Do not carry more than 176 Consult your Renault Dealer. lbs (80 kg) on the roof bars. Distribute the load on the bars uniformly possible and fasten it securely.
  • Page 169 BATTERY: breakdown In the event of a fault: Isolate the battery by unscrewing the negative terminal. Disconnect the battery Switch off the ignition and wait for the red diode of the navigation CD-ROM drive to go out. To avoid all risk of sparks: - Ensure that any consumers are switched off before disconnecting or reconnecting the battery.
  • Page 170 Have the battery's charge status Consult your Renault Dealer. checked regularly. - especially if you use your vehicle for short journeys or for frequent Specific procedures may driving in town.

  • Page 171: Battery

    Start the engine as you would Obtain suitable jump leads (with a normally. As soon as it starts, large cross section) from a Renault disconnect cables A and B in Dealer or, if you already have jump reverse order (4-3-2-1).

  • Page 172: Towing

    Workshop jacking do not exceed the towing weight for equipment: your car. Consult your Renault Only use the jacking Dealer. points designed by our Technical Department. 5.30...
  • Page 173 TOWING: breakdown (continued) Renault specifies the use of a rigid towing bar. If a rope or cable is used (where the allows this), vehicle being towed must be able to brake. A vehicle must not be towed if it is not fit to be driven.

  • Page 174: Diesel Fuel Filter (Diesel Version)

    4 (boss B opposite carried out with the greatest mark A); possible care and should be entrusted to a RENAULT Dealer. - Close the bonnet. The alternator, starter and engine - Fill up with fuel as soon as mountings must be protected possible.
  • Page 175 Section 6: Technical specifications Weights and towing/caravan weights ....................6.02 - 6.03 Engine specification ............................6.04 Dimensions ..............................6.05 Vehicle identification plates ......................6.06 6.08 Replacement parts and repairs ........................6.09 6.01...
  • Page 176 WEIGHTS AND TOWING WEIGHTS WEIGHT (in kg) - Basic vehicle and without options, likely to change in the course of the model year: Consult your Renault Dealer. Versions (versions marketed depend on country) 2.0 16V 2.2 dCi Vehicle type DEOU06...
  • Page 177 WEIGHTS AND TOWING WEIGHTS /TOWING A CARAVAN (continued) Consult your Renault Dealer for any modification to towing equipment and its electrical connections. Towing weight (towing a caravan, boat, etc.): - It is important to comply with the towing weights, governed by local...
  • Page 178 *(1) Only use the type specified for your vehicle's engine. The type should be marked on a label affixed to the engine compartment. If it is not then contact your Renault Dealer. Fitting spark plugs which are not to specification may damage the engine.
  • Page 179 DIMENSIONS (in metres) 4,642 1,550 1,835 (2) Turning circle • between walls: 11.7 m 1,556 (1) with roof bars: add approximately 4 inches (11,1 mm) (2) with rear-view mirrors: add approximately 10 inches (25.8 cm) 6.05...
  • Page 180 VEHICLE IDENTIFICATION PLATES 6 Vehicle type 7 Equipment level 8 Vehicle paint reference 9 Fabrication number 10 Limited edition and equipment level 11 Seat upholstery code 12 Interior trim code Quote the information on vehicle 1 Identification number within identification plate A and the series type engine plate when writing or 2 Maximum permissible all-up...
  • Page 181 VEHICLE IDENTIFICATION PLATES (continued) Chassis marking Repeat of: Vehicle Identification Number. 6.07...
  • Page 182 VEHICLE IDENTIFICATION PLATES (continued) Quote the information on the vehicle identification plate and the engine plate in all letters and when ordering parts. Engine plate B (Location varies depending engine) 1 Engine type 2 Engine suffix 3 Engine number 6.08...
  • Page 183 Therefore, they are of at least the same level of quality as the originally fitted part. If you always fit Renault genuine parts to your vehicle, you will ensure that it performs well. Repairs carried out using original parts in the Renault network are guaranteed for one year.
  • Page 184 NOTES 6.10...
  • Page 185 ALPHABETICAL INDEX A Accessories ..............5.25 D Doors ............. 1.03 1.05 Air bag ............1.13 1.18 Driver's position ........... 1.32 1.35 Air conditioning .......... 3.04 3.17 Air filter ..............4.12 Air vents ............3.02 - 3.03 E Electric locking ..........1.02 - 1.04 Anti-lock braking system (ABS) ......
  • Page 186 ALPHABETICAL INDEX I Ignition switch ..........2.02 - 2.03 P Passenger heating control ......3.06 3.13 Instrument panel ......... 1.36 1.45 Power assisted steering ......... 2.12 - 4.10 Instrument panel lighting (adjustment) ....1.55 Pretensioners ............. 1.13 Instruments ..........1.36 1.45 Interior lighting ....
  • Page 187 ALPHABETICAL INDEX T Telephone (pre-equipment) ........5.24 W Warning lights ..........1.36 1.40 Towing (breakdown) ........5.30 - 5.31 Washing ..............4.12 Towing (towing a caravan) ........6.03 Weights ..............6.02 Towing weights ..........6.02 - 6.03 Wheelbrace ............... 5.02 Traction control system .........
  • Page 190 C R É A T E U R D ' A U T O M O B I L E S The driver's handbook - 60 25 411 369 – NU 647-2 – January 2002 – Édition anglaise...

This manual is also suitable for:

De0u06De0t06De0k06De0u02De0t02

Table of Contents
