VIBRATORY PLATE
BPU 2950A
0200201en - 10.2002
0007962 100
Operator´s Manual

Advertisement

Table of Contents
loading

Summary of Contents for Wacker Neuson BPU 2950A

  • Page 1 VIBRATORY PLATE BPU 2950A 0200201en - 10.2002 0007962 100 Operator´s Manual...
  • Page 3 CONTENTS Type Item no. BPU 2950A 0007962 ... This machine has been equipped with an EPA certified engine. Additional information can be found in the engine manufacturers notes. H00450GB...
  • Page 5: Foreword

    FOREWORD Foreword For your own safety and protection from bodily injuries, carefully read, understand and follow the safety instruc- tions in this manual. Please operate and maintain your Wacker machine in accordance with the instructions in this manual. Your Wacker machine will reward your attention by giving trouble-free operation and a high degree of availability. Defective machine parts are to be replaced as soon as possible.
  • Page 6: Table Of Contents

    TABLE OF CONTENTS FOREWORD SAFETY INSTRUCTIONS General instructions Operation Safety checks Maintenance Transport Maintenance checks TECHNICAL DATA DESCRIPTION Application Dimensions Max. admissible inclination Description of function TRANSPORT TO WORK SITE RECOMMENDATIONS ON COMPACTION OPERATION Starting Starting the engine Handling Forward and reverse motion Stopping the engine MAINTENANCE Maintenance schedule...
  • Page 7 TABLE OF CONTENTS FAULTS Forward speed too low Reverse speed too low No reverse motion Loss of hydraulic oil Engine does not start EC - CONFORMITY-CERTIFICATE 0108315GBIVZ.GB.doc...
  • Page 8: Safety Instructions

    SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS FOR THE USE OF VIBRATORY PLATES WITH COMBUSTION ENGINES General instructions Vibratory plates may only be operated by persons who * are at least 18 years of age * are physically and mentally fit for this job * have been instructed in guiding vibratory plates and proved their ability for the job to the employer * may be expected to carry out the job they are charged with carefully.
  • Page 9: Safety Checks

    SAFETY INSTRUCTIONS Make sure the soil or subsoil to be compacted has a high enough load carrying capacity. Use appropriate protective clothing while working or while carrying out maintenance work. When traveling backwards the operator has to guide the vibration plate laterally by its guide handle so that he will not be squeezed between the handle and a possible obstacle.
  • Page 10: Technical Data

    TECHNICAL DATA BPU 2950A Item no. 0007962 ... Forward / reverse speed m/min: to 22 Surface compaction performance to 660 Operating weight (mass) Power transmission From drive engine directly to exciter unit via centrifugal clutch and V-belt Exciter Vibrations rpm’s (Hz):...
  • Page 11: Description

    They are also suited to compact blacktop surfacings and to vibrante interlocking paving stones. Due to its op- timum ratio of centrifugal force to contact area the BPU 2950A is the machine of this series which can be most universally used.
  • Page 12: Description Of Function

    DESCRIPTION Description of function The vibration required for compaction is produced by the exciter (4) which is firmly joinded to the lower mass (3). This exciter (4) is designed as a central vibrator with single-plane vibrations. Such a principle permits the direction of vibration to be changed by turning the eccentric weights (11).
  • Page 13: Transport To Work Site

    TRANSPORT TO WORK SITE Transport to work site Conditions: To transport the vibration plate, use only suitable lifting equipment with a minimum load-bearing capacity of 200 kg. During transport, always switch the engine off! Only attach suitable tackle at the central lifting point (13) provided. During transport on the loading area of a vehicle, tie down the vibration plate using the lugs (12).
  • Page 14: Recommendations On Compaction

    RECOMMENDATIONS ON COMPACTION Ground conditions The max. compaction depth depends on several factors relating to the ground condition, such as moisture, grain distribution etc. It is therefore not possible to specify exact values. Recommendation: In each case determine the max. compaction depth with compaction tests and soil sam- ples.
  • Page 15: Operation

    OPERATION Starting Pre-starting check 1. Oil level check Insert dipstick in oil filler neck, but without screwing in. If oil level is low, fill to the top of the oil filler neck with high grade SAE 10 W 40 oil. 2.
  • Page 16 T00675GB...
  • Page 17: Handling

    OPERATION Handling As the engine warms up, gradually move the choke lever to the OPEN position. Position the throttle lever for the desired engine speed. Oil alert system The oil alert system is designed to prevent engine damage caused by an insufficient amount of oil in the crank- case.
  • Page 18: Stopping The Engine

    OPERATION Stopping the engine To stop the engine in an emergency, turn the engine switch to the OFF position. Under normal conditions, use the following procedure: a) Move the throttle lever fully to the right. b) Turn the engine switch to the OFF position. c) Turn the fuel valve to the OFF position.
  • Page 19: Maintenance

    MAINTENANCE Maintenance schedule Check all external screw connections for tight fit approx. 8 hours after first operation. Parts Maintenance jobs Maintenance interval Air filter Check for external damage and tight fit. daily Check filter cartridge, clean or replace if necessary. Fuel tank Check tank lid fortight fit, replace if necessary.
  • Page 20: Engine Oil

    MAINTENANCE Engine oil Oil change Drain the oil while the engine is still warm to assure rapid and complete draining. 1. Remove the oil filler cap and the drain plug to drain the oil. 2. Install the drain plug, and tighten it securely. 3.
  • Page 21: Spark Plug

    MAINTENANCE Spark plug Spark plug service Recommended spark plug: BP6ES-11, BPR6ES-11 (NGK), W20EP-U11, W20EPR-U11 (ND). Caution: Never use a spark plug of incorrect heat range. To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. 1.
  • Page 22 T00676GB...
  • Page 23: Exciter V-Belt

    MAINTENANCE Exciter V-belt Remove belt guard. Remove nuts situated on the motor V-belt pulley, remove V-belt pulley half. Remove nuber of spacers on (the romoval or one spacer is usually sufficient). Install the removed spacers on the outside of the V-belt pulley. (If one washer is removed, install it on the outer half of the pulley, of two, one on the outer and one on the inner V-belt pulley half etc).
  • Page 24: Exciter

    MAINTENANCE Exciter Check oil level: 1. Position vibration plate horizontally. 2. Open filler bore (16). 3. The oil level must reach the start of the thread of the filler bore (16). 4. If necessary, pour in HD brand oil SAE 10 W 40 through filler bore (use funnel). 5.
  • Page 25 FAULTS Forward speed too low Cause: - Too little hydraulic oil in the centre pole head. - Air in hydraulic control. Remedy: - Top up hydraulic oil. - Bleed system. Reverse speed too low Cause: - Too much oil in centre pole head. Remedy: - Correct oil level in accordance with mark.
  • Page 28 Wacker Construction Equipment AG , Preußenstraße 41, 80809 München hereby certify that the construction equipment specified hereunder: 1. Category: Vibratory plate 2. Type: BPU 2950A 3. Equipment item number: 0007962 ... 4. absolute installed power: 6,6 kW has been evaluated in conformity with Directive 2000/14/EC: Conformity At the following notified...
