- Page 1 Operator’s Manual Vibratory plate Machine Type BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A Material Number 5100060577 Version Date 01/2023 5100060577 Language [en]...
- Page 2 Violations of legal regulations, in particular of the copyright protection, will be subject to civil and criminal prosecution. Wacker Neuson Produktion GmbH & Co. KG reserves the right to change its products and their technical specifications for further technical development at any time without any claim to changes to machines already delivered.
-
Page 3: Table Of Contents
7.1 Safety instructions for operation....................... 33 7.2 Tests before commissioning ......................34 7.3 Putting into operation with Honda engine ..................34 8 Operation [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... - Page 4 13.2 Noise and vibration data ........................51 13.3 BPS Honda ............................51 13.4 Combustion engine .......................... 56 13.5 Conversion table ..........................57 iv Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
-
Page 5: Ec Declaration Of Conformity
EU Declaration of Conformity Manufacturer Wacker Neuson Produktion GmbH & Co. KG, Wackerstraße 6, 85084 Reichertshofen (DE) This declaration of conformity is issued under the sole responsibility of the manufacturer. BPS1030, BPS1135, BPS1340 Product Product type Vibratory plate Function of product... - Page 6 SI 2008 No. 1597 • SI 2001 No. 1701 • SI 2016 No. 1091 • EN 500-1:2006 + A1:2009 EN 500-4:2011 • EN ISO 13766-1:2018 Person responsible for technical documents Andy Williams (Operations Manager), Wacker Neuson Ltd, WN Place, Beacon Way, Stafford ST18 0DG (GB) Reichertshofen (DE), 21.12.2022...
- Page 7 EU Declaration of Conformity Manufacturer Wacker Neuson Produktion GmbH & Co. KG, Wackerstraße 6, 85084 Reichertshofen (DE) This declaration of conformity is issued under the sole responsibility of the manufacturer. Product BPS1550 Product type Vibratory plate Function of product Soil compaction...
- Page 8 SI 2008 No. 1597 • SI 2001 No. 1701 • SI 2016 No. 1091 • EN 500-1:2006 + A1:2009 EN 500-4:2011 • EN ISO 13766-1:2018 Person responsible for technical documents Andy Williams (Operations Manager), Wacker Neuson Ltd, WN Place, Beacon Way, Stafford ST18 0DG (GB) Reichertshofen (DE), 21.12.2022...
- Page 9 EU Declaration of Conformity Manufacturer Wacker Neuson Produktion GmbH & Co. KG, Wackerstraße 6, 85084 Reichertshofen (DE) This declaration of conformity is issued under the sole responsibility of the manufacturer. Product BPS2050 Product type Vibratory plate Function of product Soil compaction...
- Page 10 SI 2008 No. 1597 • SI 2001 No. 1701 • SI 2016 No. 1091 • EN 500-1:2006 + A1:2009 EN 500-4:2011 • EN ISO 13766-1:2018 Person responsible for technical documents Andy Williams (Operations Manager), Wacker Neuson Ltd, WN Place, Beacon Way, Stafford ST18 0DG (GB) Reichertshofen (DE), 21.12.2022...
-
Page 11: Foreword
Indicates an activity. The sequence of the steps must be observed. ⇨ Indicates a result or an intermediate result of an action. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 12: Accident Prevention Regulations
Depending on the country, the contact person is a service partner, a sub- sidiary or a dealer. • On the Internet at http://www.wackerneuson.com. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 13: Limitation Of Liability 2.5
5100067727 BPS2050A 5100061217 BPS2050Aw 5100061218 * In the case of configurable machines, technical data is assigned via the machine's sales designation. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 14: Usage
• Compaction of strongly cohesive soils. • Compaction of frozen soils. • Compaction of hard, non-compactable soils. • Compaction of non-load-bearing soils. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 15: Safety
• Keep safety instructions and information for the future. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 16: Structual Changes
The operator’s manual must be supplemented by further instructions for compliance with operational, official, national or generally applic- able safety guidelines. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 17: Obligations Of The Operator 4.5
It may contain instructions which are not relev- ant for this machine. 4.7.1 Workplace Warning! Hazard of poisoning from exhaust gases. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... - Page 18 • Do not work under the influence of drugs, alcohol or medication. Warning! Danger of being drawn in by unsuitable clothing and long hair. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
- Page 19 4.7.3 Handling and use Warning! Risk of injury from falling loads. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
-
Page 20: Specific Vibration Plate Safety Instructions
• Use the machine, accessories, tools etc. in accordance with these in- structions. Specific vibration plate safety instructions 4.8.1 External influences Warning! Fire and explosion hazard. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... - Page 21 • Block off a large work area and keep unauthorized persons away. • Make sure people in the work area keep a minimum distance of 2 meters from the running machine. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
-
Page 22: Safety Features
• Do not change or remove safety devices. • Reattach safety and protective devices removed for maintenance/ser- vice (e.g. V-belt protection). Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 23: Service 4.10
• Reattach safety and protective devices removed for maintenance/ser- vice (e.g. V-belt protection). Caution! Risk of crushing/risk of burns when the machine is running. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 24: Vehicle Fluids
• In case of skin contact, wash skin immediately with soap and water. • Do not eat or drink while working with vehicle fluids. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 25: Combustion Engine 4.12
Note! Machine damage due to incorrectly set engine speed. • The preset engine speed must not be adjusted. This could lead to en- gine damage. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 26: Description Of The Machine
Keep all safety, warning and operating instructions on the machine in a clearly legible condition. ► Replace missing or damaged labels and signs immediately. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... - Page 27 • Do not operate the machine in closed rooms. • Take the machine out of operation before refelling. • Fire, open flame and smoking are prohibited. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
-
Page 28: Components
Always keep the displays and controls of the machine dry, clean and free of oil and grease. Do not lock, manipulate or alter the machine operating elements in an in- admissible manner. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... - Page 29 Description of the Machine Control elements 5.3 Guide bracket Water sprinkling regulation Handle Engine switch Handle reversing starter Throttle lever Choke lever Fuel cock [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
-
Page 30: Transportation
If the machine is unstable, the lifting gear and the hoist may fail and fall down. ► Check the stability of the lifted machine before continuing work. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... - Page 31 Two persons should hold and lift the machine at the provided handles with both hands. Load the machine into or onto the transport vehicle. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
-
Page 32: Lashing The Machine
Only use the lashing points provided for this purpose to secure the ma- chine. ▪ Tie down the machine as shown. ð The machine is secured against unrolling, slipping and tipping over. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 33: Commissioning
► Do not exceed the maximum permissible inclination, see see Tech- nical Data on page • Only approach gradients from below. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 34: Tests Before Commissioning
Danger of burns due to starting aid sprays! Starting aid sprays can ignite and cause severe burns. ► Do not use any starting aid sprays. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... - Page 35 Move the choke lever to position B when the engine is warm. Move the throttle lever 3 into position A. Move the engine switch 4 into position A. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
- Page 36 Move choke lever to position A for starting, move choke lever back to position B while the engine is warm. ð Engine runs. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
-
Page 37: Operation
Move the engine switch 2 into position B. Move the fuel cock 3 into position B. ð Let the machine and engine to cool down. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 38: Maintenance
Splashes of hot oil can cause burns to the skin. ► Switch off the engine and let it cool down. ► Use protective gloves. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... - Page 39 ► Collect contaminated water and dispose of it in an environmentally friendly manner. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
-
Page 40: Maintenance Plan
Do not hold the high-pressure cleaner too close to the machine in order to avoid damage to labels and sensitive components. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... - Page 41 ð Max. fuel level to lower edge of filler neck. Refuel if necessary, see Technical Data on page Close filler cap tightly. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
- Page 42 When reinstalling the cyclone, ensure that the air inlet tab fits snugly in the groove of the pre-cleaner cover. ► Install the air duct in the correct direction. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
- Page 43 Remove dirt. The machine must be horizontal. Unscrew engine oil dipstick 1. Wipe the engine oil dipstick with clean and fiber-free rags. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
- Page 44 Checking and topping up engine oil level on page Tighten the engine oil dipstick again. 9.3.6 Cleaning the deposit cup Move the fuel cock 3 into position B. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
- Page 45 ð Correct the electrode spacing by carefully bending it. Tighten the spark plug again, tightening torque 18 Nm. Plug the spark plug connector onto the spark plug. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
- Page 46 When tightening, turn the V-belt pulley to prevent the V-belt from jam- ming. Tighten the screws. Fit the V-belt guard, tightening torque 10 Nm. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
-
Page 47: Troubleshooting
Change V-belt. ning. Clutch linings worn out. Have the clutch linings replaced.* * Have this work carried out by a service partner. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... -
Page 48: Shutdown
Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 49: Accessories
Secure the wheel set against rolling away or fold it up. Water tank Water tank with continuously adjustable sprinkler system, see Safety in- structions for operation on page [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... - Page 50 Wheel set for easier transport on the construction site. Slide mechanism Surface protection, see Safety instructions for operation on page 34 Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
-
Page 51: Technical Data
Vibrations [1/min] 5880 5880 Area output* [m2/h] Flow [m/min] Gradeability [%] 36,4 36,4 Length (drawbar in working position) [mm] Width [mm] [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... - Page 52 Measurement uncertainty of the total vibration value ahv [m/s2] *Depends on the soil conditions. ** Corresponds to the installed net power according to Directive 2000/14/EC. Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
- Page 53 3600 Operating temperature range [°C] -15 - +45 -15 - +45 Storage temperature range [°C] -15 - +40 -15 - +40 [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
- Page 54 ** Corresponds to the installed net power according to Directive 2000/14/EC. Type BPS1550Aws Material number machine 5100067727 Material number engine 5100045995 5100046324 Centrifugal force [kN] Vibrations [Hz] Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
- Page 55 Storage temperature range [°C] -15 - +40 -15 - +40 Sound pressure level at operator station LpA [dB(A)] Sound power level LWA, measured [dB(A* [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
-
Page 56: Combustion Engine
Cylinder Cubic capacity [cm3] Inclined position max. [°] Fuel type Gasoline Fuel consumption [l/h] Tank volume [l] Oil specification SAE 10W-30 Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]... -
Page 57: Conversion Table 13.5
Conversion table Volume units 1 cm³ 0.061 in³ 1 m³ 35.31 ft³ 1 ml 0.034 US fl.oz. [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual... - Page 58 1 kN 224.81 lbf 1 kW 1.34 hp 1 PS 0.986 hp Torque 1 Nm 0.74 ft.lbs Speed 1 km/h 0.62 mph Acceleration 1 m/s² 3.28 ft./s² Operator’s Manual | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | 5100060577 | 01/2023 | Version: 5 | [en]...
- Page 59 Notes [en] | Version: 5 | 01/2023 | 5100060577 | BPS1030A, BPS1135A, BPS1340A, BPS1550A, BPS2050A | BPS | Operator’s Manual...
- Page 62 Wacker Neuson Produktion GmbH & Co. KG Wackerstraße 6 D-85084 Reichertshofen Tel.: +49 8453 340-0 Email: service-LE@wackerneuson.com www.wackerneuson.com Material Number: 5100060577 Language: [en]...
