Features And Specifications - Motorola HMWC1020 Quick Start Manual

Quick Start Guide
Problem
Audio problems
FAQ
How far away can the camera see?
Depending on the lighting conditions and the size of the object(s), you can view objects up to 200 feet (60 m)
away with a viewing angle of 80 degrees. The motion sensor is capable of detecting objects up to 20 ft. (6 m)
away with a field of view of 80 degrees.
How sensitive is the camera's microphone?
The microphone picks up normal conversation 6 to 10 feet away.
Can I use extension cables to extend the reach of the Wired Camera?
Yes, 60' (18m) extension cables are available. You can extend the camera up to 180 feet (55m).

Features and Specifications

• PIR motion detection
• LED in camera illuminates when activity occurs
• Microphone captures audio
• 80 degree field of view for motion and camera lens
• Weather resistant
•
Auto Brightness, Auto Contrast, Auto White-Balance
Integrated Lens:
4.3 mm, F1.8 fixed focus
Focus range: 2 feet to Infinity
Signal/Noise Ratio: 48 dB
Image Sensor 1/3" CMOS
Minimum Illumination: 5 lux
Overall Size: 2 ½ " W x 2 ¾" H x 3 ¼" D (5.7 cm W x 7 cm H x 8.2 cm D)
Page 4
• Is your volume turned on when playing the video?
• Ensure that all cables are firmly connected. For non-standard cable
types, ensure that the proper converter is being used.
• Ensure the sound is within the microphone range (6-10 feet).
• Does the computer have a sound card and are the speakers activated
and loud enough?
Solution
Motion and camera lens:
80 degree field of view
Resolution: 360 horizontal TV lines
High-Speed Electronic Shutter 1/60 - 1/15000 sec
Current Consumption: approximately 40mA
Wired Camera
