Rhymebus RM6F5 Series Operation Manual

RM6F5 Series
Simple Version
Operation Manual
Thank you for using RHYMEBUS RM6F5 series drive.
For proper operations and safety purposes, please read manual carefully.
Only the qualified personnel may proceed with the installation.
Scan the QR code on the right side for the complete operation manual.
Please pay attention to the safety precautions marked with "DANGER" or
"CAUTION" in complete manual before installation.
DANGER
CAUTION
 Terminals of Main Circuit
R,S,T
(L1,L2,L3)
○ ＋ ○ －
, N
U,V,W
(T1,T2,T3)
P(+), N○ －
Dynamic brake unit
P, N
P, PR
P(+), PR
P(+), P1
PE(or G)
Grounding terminal Ground the drive in compliance with the NEC standard
User may cause the casualty or serious damages if user does not abide
by the instructions of the manual to execute the tasks.
User may cause injuries to the people or damage the equipment if user
does not abide by the instructions of the manual to execute the tasks.
AC power source
input terminals
DC power source
input terminals
Drive outputs to
motor terminals
terminal
External
brakingresistor
terminal
External reactor
terminal
Three-phase; sinusoidal power source input terminals.
External DC power source terminal.
※Only 2007 ~ 2015, 4007 ~ 4020 models have the terminal.
Output three-phase variable frequency and voltage to
motor.
Connect to dynamic braking unit(option).
Connect to external brake resistor (option).
Connect to DC reactor (DCL) for improving power
factor. The default setting is connected by a jumper.
or local electrical code.
1
2022.08.15 Edition XB200235
