Name
Adjusts the output volume of the MODERN LEAD channel, the volume is positioned pre the
VOLUME FX Loop. In the instance unwanted clipping occurs, try lowering the volume to ensure any
subsequent devices in your signal path are not overdriven.
D - Shared EQ for BRITISH CRUNCH / MODERN LEAD Channels
Name
Adjusts the Low Frequency content of the shared tone stack.
BASS As the knob is rotated the signal is attenuated (down to -9dB) or boosted (up to +4dB),
below 100Hz
Adjusts the Mid-Range frequency content of the shared tone stack.
MID As the knob is rotated the signal is attenuated (down to -10dB) or boosted (up to +10dB),
centered at 750Hz
Adjusts the High frequency content of the shared tone stack.
TREBLE As the knob is rotated the signal is attenuated (down to -6dB) or boosted (up to +6dB),
above 1.5 kHz
E - BOOST
Name
Adjusts the Boost (instantiated by pressing the footswitch of the active channel).
BOOST
Increases the signal from +2 dB to +20dB, centered around 700Hz
2. Footswitch & LED Functionality
2.1 Channel Activation
Each of the channels can be activated by pressing the CLEAN, CRUNCH, and LEAD footswitches. The
LED above the footswitch will light up when the channel is active:
Green for the AMERICAN CLEAN channel
Orange for the BRITISH CRUNCH channel
Blue for the MODERN LEAD channel
Simultaneously pressing the CLEAN and the CRUNCH switches will bypass ReVolt.
2.2 BOOST Activation
The BOOST is engaged by pressing the footswitch of the active channel. For example, if ReVolt is set
to the BRITISH CRUNCH channel, pressing the CRUNCH switch again will activate the boost on this
channel. When BOOST is active on a channel, the color of the tube changes from amber to red.
Pressing for a 3rd time on the active channel will disengage the boost.
By default, the status of the BOOST is not remembered when the channel is changed. This behavior
can be changed via ReVolt's comprehensive setup menu (head to
User's manuals - https://wiki.two-notes.com/
7/17
Function
Function
Function
ReVolt Guitar - User Guide
this section of the manual).
