3.2 MIDI Learn

This menu can be used to set the MIDI PC number associated with each ReVolt Channel (including the
Boost state per channel) and the Bypass Mode The Default MIDI PC values are as follows :
Channel
Channel A
A+boost
Guitar PC 1 PC2
BASS PC 1 -
While in this setup menu, pressing a footswitch will set the pedal for the message to be programmed:
Corresponding LEDs will light for 1s before displaying the current assigned PC number for this channel
3.2.1 Assigning "Channel On" PC (A, B, or C)
Press A, B, or C - the corresponding channel LED will momentarily turn ON
After one second, ReVolt will use the channel LEDs to flash the currently assigned PC number.
The user can now send a valid MIDI PC message
If Valid - the channel LED will remain solid for 1 second, then ReVolt will begin flashing the
newly assigned PC number
If Invalid - if the PC message is already assigned to another channel function - the channel LEDs
will flash 3 times. The device remains in assignment mode and will await a valid PC message.
3.2.2 Assigning "Channel On BOOST" PC (A, B, or C)
Press A, B, or C 2 times, the "tube window" indicates boost mode (very red) - the corresponding
channel LED will momentarily turn ON
After one second, ReVolt will use the channel LEDs to flash the currently assigned PC number.
The user can now send a valid MIDI PC message
If Valid, the channel LED will remain solid for 1 second, then ReVolt will begin flashing the newly
assigned PC number
If Invalid - if the PC message is already assigned to another channel function - the channel LEDs
will flash 3 times. The device remains in assignment mode and will await a valid PC message.
3.2.3 Assigning BYPASS PC
Press A+B: All LEDS will blink for 2*500ms.
After one second, ReVolt will use the channel LEDs to flash the currently assigned PC number.
The user can now send a valid MIDI PC message
If Valid, the channel LED will remain solid for 1 second, then ReVolt will begin flashing the newly
assigned PC number
If Invalid - if the PC message is already assigned to another channel function - the channel LEDs
will flash 3 times. The device remains in assignment mode and will await a valid PC message.
https://wiki.two-notes.com/
Channel
Channel B
B+boost
PC3 PC4
PC2 -
Channel
Channel C
C+boost
PC5 PC6
PC3 -
Printed on 2022/12/12 19:40
Bypass
PC7
PC4
