LEDs will flash quickly.
To enter a sub-menu, press the footswitch C button. The "tube-window" color will quickly blink.
Once in a sub-menu, a power-cycle is required to exit.
Valid settings are saved immediately
Every time there is a number displayed to the user, it is done using the channel LEDs:
Channel A : 100s
Channel B : 10s
Channel C : units
Example: Number 123 is reported as 1 blink on channel A, 2 blinks on channel B and 3
blinks on channel C. The same process applies for error messages.
2. Menu Pages
Setup Menu Pages and Color Reference
The Page order is as follows:
FX loop defaults : Pink
Boost defaults : Green
MIDI Monitor : White
MIDI learn : Blue
MIDI Channel : Orange
MIDI PC Number : Purple
FX LOOP MIDI CC : Turquoise
BOOST MIDI CC : Yellow
FW VERSION / Factory Reset : Red

3. MIDI SETUP

3.1 MIDI Monitor
The MIDI monitor uses the RGB LED behind the tube window to display the type of MIDI (PC, CC, or
SYSEX) message received.
Typical behavior when a MIDI message is received is as follows:
Valid message received, channel is wrong - show ORANGE
Valid message received, PC - GREEN, CC - BLUE. The message # is displayed on the channel
LEDs.
Valid SYSEX received, display PINK. The message byte count, if less than 999, is displayed on
the channel LEDs.
