SPECIFICATIONS

Input
IN 6.35mm (1/4")
SEND 6.35mm (1/4")
RETURN 6.35mm (1/4")
OUT 6.35mm (1/4")
MIDI IN 3.5mm (⅛")
MIDI OUT 3.5mm (⅛")
GND LIFT PUSH BUTTON
BALANCED OUT XLR
12V DC 600 mA 2.1mm

Advanced Functionality

1. Using the Setup Menu System

The setup menu is entered by holding down footswitch A and providing power to the device. When the
setup menu is entered, the "tube window" will show the "first page" color.
Press footswitch B to go to the next page.
Press footswitch A to go to the previous page.
Press footswitch C to enter a page.
When the last page is selected, pressing footswitch B will select the first menu and the channel
LEDs will flash quickly.
When the first page is selected, pressing footswitch A will select the last menu and the channel
https://wiki.two-notes.com/
Size
Jack 6.35 mm (1/4"), unbalanced (TS, Tip/Sleeve)
Impedance: 1MΩ
Jack 6.35mm (1/4"), unbalanced (TS)
Max output level: 11 dBu
Impedance : 10kΩ
Jack 6.35mm (1/4"), unbalanced (TS)
Max input level: 11dBu
Impedance: 1MΩ
Unbuffered, directly connected to Output when active
Jack 6.35mm (1/4"), unbalanced (TS)
Max output level: 11dBu
Impedance: 300Ω
MIDI adapter cable
Pinout: TIP=DIN 5 RING=DIN 4 SLEEVE=DIN 2
MIDI adapter cable
Pinout: TIP=DIN 5 RING=DIN 4 SLEEVE=DIN 2
With the switch engaged it opens (disconnects) the connection
between the ReVolt ground and the balanced audio output.
XLR, balanced Impedance: 600Ω balanced, 300Ω unbalanced
Max output level: 11dBu
Mains power adaptor DC Jack 2.1mm, negative center
Input voltage: 12V DC Power consumption: approx. 6W Current
draw: 600mA
Function / Specifications
