Program Settings

This section defines all of the enhanced feature settings for your radio. In most cases, the default settings will
work best.

Memory CH Window

Field Description
RX RAN The receive digital code that must match the TX radio RAN
before squelch will open. The range is 0 to 63, with 0
representing open squelch.
The transmit digital code that must match the RX radio
TX RAN
RAN before squelch will open. The range is 0 to 63, with 0
allowing a match to any RAN code.
Unit ID The unique identification for an individual radio.
The unique identification for a talkgroup.
Talkgroup ID
Squelch If set to OFF, there is only carrier squelch. If set to RAN,
the digital RAN code must match before a squelch will
Type
open. If set to Sel, the RAN and the Unit ID or Talkgroup ID
must match before squelch will open.

Digital/Option Window

Field
Talkgroup Display
on Mode Change
Talkgroup Display
on Receive
Unit ID Display on
Receive
Talkgroup Display
on PTT

Expert Window

Note: Settings in the Synchronization field are for digital operation only. Use the default settings in these fields.
Field
TX All Call
RX All Call
Description
Enables the Talkgroup ID or Zone to display on the
radio when changing the channel or zone.
Allows the receiving radio to display the talkgroup
of the transmitting radio.
Allows the receiving radio to display the Unit ID of
the transmitting radio.
When you select a talkgroup and press PTT, the
selected talkgroup ID will show on your radio's
display.
Description
Allows you to transmit an all call if set to Enable.
You will also need to set a talkgroup ID of
65535.
Allows you to receive an all call if set to Enable.
Suggested Setting
User preference
User preference
User preference
User preference
User preference
Suggested Setting
User preference
User preference
User preference
User preference
Suggested Setting
8/19/2011 11
