Icom ID-4100A Service Manual page 28

[MAIN UNIT]
REF PART
NO. NO.
EP106 6910018460 S.BEA MMZ1005Y102C-T
EP107 6910018460 S.BEA MMZ1005Y102C-T
EP111 6910014690 S.BEA MPZ1608S221A-T
EP113 6910018460 S.BEA MMZ1005Y102C-T
EP115 6910014690 S.BEA MPZ1608S221A-T
EP118 6910018460 S.BEA MMZ1005Y102C-T
EP200 6910018460 S.BEA MMZ1005Y102C-T
EP201 6910018460 S.BEA MMZ1005Y102C-T
EP202 6910018460 S.BEA MMZ1005Y102C-T
EP300 6910012350 S.BEA MMZ1608Y 102BT
EP304 6910018460 S.BEA MMZ1005Y102C-T
EP305 6910018460 S.BEA MMZ1005Y102C-T
EP307 6910018460 S.BEA MMZ1005Y102C-T
EP309 6910018460 S.BEA MMZ1005Y102C-T
EP312 6910018460 S.BEA MMZ1005Y102C-T
EP315 6910018460 S.BEA MMZ1005Y102C-T
EP316 6910018460 S.BEA MMZ1005Y102C-T
EP320 6910018460 S.BEA MMZ1005Y102C-T
EP321 6910018460 S.BEA MMZ1005Y102C-T
EP323 6910012350 S.BEA MMZ1608Y 102BT
EP324 6910018460 S.BEA MMZ1005Y102C-T
EP330 6910018460 S.BEA MMZ1005Y102C-T
EP334 6910018460 S.BEA MMZ1005Y102C-T
EP351 6910018460 S.BEA MMZ1005Y102C-T
EP352 6910018460 S.BEA MMZ1005Y102C-T
EP353 6910018460 S.BEA MMZ1005Y102C-T
EP354 6910018460 S.BEA MMZ1005Y102C-T
EP355 6910018460 S.BEA MMZ1005Y102C-T
EP356 6910018460 S.BEA MMZ1005Y102C-T
EP357 6910018460 S.BEA MMZ1005Y102C-T
EP358 6910018460 S.BEA MMZ1005Y102C-T
EP359 6910018460 S.BEA MMZ1005Y102C-T
EP360 6910018460 S.BEA MMZ1005Y102C-T
EP361 6910018460 S.BEA MMZ1005Y102C-T
EP362 6910018460 S.BEA MMZ1005Y102C-T
EP405 6910018460 S.BEA MMZ1005Y102C-T
EP409 6910014690 S.BEA MPZ1608S221A-T
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
DESCRIPTION M.
LOCATION
T
T 16.5/28.2
T 126.8/119.2
T 123.7/119.2
T 129.3/119.2
T 124.9/118.9
T 37.9/36.0
B 48.1/37.9
B 46.1/39.7
T 60.5/13.2
B 128.2/54.4
B 128.2/53.3
B 104.5/69.1
B 126.6/40.7
T 80.1/32.4
T 77.4/32.4
T 78.0/24.9
T 78.9/24.9
T 79.8/24.9
T 121.2/9.1
B 82.8/22.3
B 104.1/122.8
B 102.3/122.8
B 129.6/70.1
B 60.6/13.0
B 106.2/125.5
B 106.2/127.9
B 106.6/130.7
B 97.8/122.8
T 82.2/24.9
T 83.1/24.9
T 81.0/32.4
T 81.9/32.4
T 82.8/32.4
T 83.9/31.1
T 87.1/30.2
T 91.4/128.9
H/V
15.5/9.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
6-11
