4-3 RECEIVE ADJUSTMENT (continued)
Select an adjustment item using [MONI]/[QUICK], and then set the adjustment value as specified using [DIAL].
ADJUSTMENT ITEM
93
SQUELCH
Air band
94
Air band narrow
95
VHF
96
VHF narrow
97
UHF Low
98
UHF Low narrow
99
UHF Center
UHF Center narrow 100
101
UHF High
102
UHF High narrow
NOTE: The displayed adjustment frequency is only an example, and the frequency will differ depending on the transceiver version.
TRANSCEIVER'S DISPLAY
CONDITION
• Terminate the antenna connector with
a dummy load (50 Ω), so no signal is
received.
5-9
VALUE
Push [DIAL]
for automatic
adjustment.
