  • Page 1 Digital Night Vision Monocular HIKMICRO HEIMDAL Series User Manual...
  • Page 2 INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKMICRO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
  • Page 3 Digital Night Vision Monocular User Manual CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS ABUSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER PREVAILS.
  • Page 4 Digital Night Vision Monocular User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 Digital Night Vision Monocular User Manual Hazardous Substances in Electrical and Electronic Equipment Regulations 2012. Frequency Bands and Power (for CE/UKCA) The frequency bands and modes and the nominal limits of transmitted power (radiated and/or conducted) applicable to this radio device are the following: Wi-Fi 2.4 GHz (2.4 GHz to 2.4835 GHz), 20 dBm.
  • Page 6 Digital Night Vision Monocular User Manual (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
  • Page 7 Digital Night Vision Monocular User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could Danger result in death or serious injury. Indicates a potentially hazardous situation which, if not avoided, Caution could result in equipment damage, data loss, performance...
  • Page 8 Digital Night Vision Monocular User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. Laws and Regulations ● Use of the product must be in strict compliance with the local electrical safety regulations. Transportation ●...
  • Page 9 Digital Night Vision Monocular User Manual We shall not assume any responsibility for problems caused by unauthorized repair or maintenance. ● Wipe the device gently with a clean cloth and a small quantity of ethanol, if necessary. ● If the equipment is used in a manner not specified by the manufacturer, the protection provided by the device may be impaired.

  • Page 10: Table Of Contents

    Digital Night Vision Monocular User Manual Table of Contents Chapter 1 Overview ........................1 1.1 Device Description ......................1 1.2 Main Function ........................1 1.3 Appearance ........................1 Chapter 2 Preparation ........................3 2.1 Install Battery ........................3 2.2 Cable Connection ......................4 2.3 Power On/Off ........................
  • Page 11 Digital Night Vision Monocular User Manual 6.2 Language Settings ......................14 Chapter 7 Maintenance ........................ 15 7.1 View Device Information ....................15 7.2 Upgrade Device ....................... 15 7.3 Restore Device ........................ 15 Chapter 8 Frequently Asked Questions ..................16 8.1 Why is the monitor off? ....................16 8.2 The image is not clear, how to adjust it? ................

  • Page 12: Chapter 1 Overview

    ● EIS: The EIS function keeps the image stable in live view mode and digital zoom process. ● Client Software Connection: The device can capture snapshots, record videos, and set parameters by HIKMICRO Sight App after being connected to your phone via hotspot. 1.3 Appearance The appearance of digital night vision monocular is shown below.
  • Page 13 Digital Night Vision Monocular User Manual Figure 1-1 Buttons and Interfaces Table 1-1 Button and Interface Description Component Function Optical Lens Protect the lens. Focus Ring Adjust focus to find clear targets. Infrared Light Help to view target clearly in dark environment. Beam Angle Adjust the beam angle of the infrared light.

  • Page 14: Chapter 2 Preparation

    Digital Night Vision Monocular User Manual Chapter 2 Preparation 2.1 Install Battery Insert the battery into the battery compartment. Steps 1. Unlock the battery compartment cover. Figure 2-1 Unlock Battery Compartment Cover 2. Open the battery compartment cover. Figure 2-2 Open Battery Compartment Cover 3.

  • Page 15: Cable Connection

    Digital Night Vision Monocular User Manual 4. Close the battery compartment cover and lock it. Figure 2-4 Complete Installation Note ● Take the battery away if the device is not used for a long time. ● Install the battery and charge the device for more than 4 hours before the first use. 2.2 Cable Connection Connect the device and power adaptor with a type-C cable to power on the device.

  • Page 16: Menu Description

    Digital Night Vision Monocular User Manual Auto Power Off Set the auto power off time for your device, and then the device will automatically shut down as the set time. Steps 1. Hold to go to the menu. 2. Rotate the wheel to select , and press to select the auto power off time as required.

  • Page 17: Chapter 3 Image Settings

    Digital Night Vision Monocular User Manual Chapter 3 Image Settings 3.1 Adjust Focus Power on the device, and hold the device steadily, then rotate the focus ring to adjust the focus until the image is clear. Figure 3-2 Adjust Focus Note When adjusting focus, DO NOT touch the surface of lens to avoid smearing the lens.

  • Page 18: Adjust Brightness

    Digital Night Vision Monocular User Manual 3.3 Adjust Brightness You can adjust the brightness for the image, and 10 levels of brightness can be adjusted. Steps 1. Hold to show the menu. 2. Select , and press to enter the adjustment interface. 3.

  • Page 19: Set Smart Ir

    Digital Night Vision Monocular User Manual Steps 1. Hold to show the menu. 2. Select , and press to enable this function. 3. Hold to save and exit. 3.7 Set Smart IR Image overexposure may occur in too bright environment. The smart IR function helps to adjust the overexposed images, and it can improve the image effect in night mode and dark environment.
  • Page 20 Digital Night Vision Monocular User Manual Result The brand logo is displayed at the bottom of the image. Note After enabling this function, the brand logo only displays on the live view interface, captures and videos.

  • Page 21: Chapter 4 Picture And Video

    Digital Night Vision Monocular User Manual Chapter 4 Picture and Video You can manually record video or capture picture when displaying live view. 4.1 Capture Picture On the main live view page, press to capture picture. Note When capturing succeeds, the image freezes for 1 second and a prompt shows on the display. For exporting captured pictures, refer to Export Files.

  • Page 22: View Local Files

    Digital Night Vision Monocular User Manual What to do next For exporting recording files, refer to Export Files. 4.4 View Local Files Steps 1. Hold to show the menu. 2. Select , and press to enter the album interface. 3. Press to select the target album.
  • Page 23 Digital Night Vision Monocular User Manual Note Make sure the device is turned on when connecting the cable. 2. Open computer disk and select the disk of device. Go to the DCIM folder and find the folder named after the capture year and month. For example, if you capture a picture or record a video on June 2021, go to DCIM →...

  • Page 24: Chapter 5 Client Software Connection

    ● Hotspot Name: HIK-IPTS Serial No. ● Hotspot Password: Serial No. 4. Search the HIKMICRO Sight App on App Store (iOS System) or Google Play™ (Android System) to download it, or scan the QR code to download and install the app.

  • Page 25: Chapter 6 System Settings

    Digital Night Vision Monocular User Manual Chapter 6 System Settings You can set unit, time, and language for your device. 6.1 Synchronize Time Steps 1. Hold to show the menu. 2. Select , and press to enter the time setting interface. 3.

  • Page 26: Chapter 7 Maintenance

    Digital Night Vision Monocular User Manual Chapter 7 Maintenance This part introduces the operation of checking device information, upgrading device, and restoring to defaults, etc. 7.1 View Device Information Steps 1. Hold to show the menu of device. 2. Select , and press .

  • Page 27: Chapter 8 Frequently Asked Questions

    Digital Night Vision Monocular User Manual Chapter 8 Frequently Asked Questions 8.1 Why is the monitor off? Check whether the device is off-battery. Connect the device to power supply and turn it on to check the monitor. 8.2 The image is not clear, how to adjust it? Adjust the focus ring until the image is clear.

  • Page 28: Chapter 12 Appendix

    Chapter 12 Appendix 12.1 Device Command Scan the following QR code to get device common serial port commands. Note that the command list contains the commonly used serial port commands for HIKMICRO thermal cameras. 12.2 Device Communication Matrix Scan the following QR code to get device communication matrix.
  • Page 29 UD30476B...
