Chapter 1 Getting Started with Your Tablet Client
Tablet Client LEDs, Buttons, Connectors, and Other Components
PC card slot
SD card Slot
Infrared (IrDA)
transceiver
Power switch
DVI-D connector
AC power port
RJ-45/LAN
VGA connector
Docking connector
USB ports (2)
Audio input/output (2)
Speakers (2)
Fingerprint reader
Ambient Light Sensor
Air vent
External battery
connector
8 Motion Computing LE1600
Holds one Type-II PC Card for memory expansion, Smart Card
Holds one SD-type card, for memory expansion (SDIO compatible)
An infrared transceiver built into the Tablet Client. Allows communication with
other devices compliant with the IrDA standard. Effective range is approximately
3 feet
Turns the Tablet Client on and off; can be configured to activate Stand By mode
A digital video interface digital connector for attachment to a digital video
interface monitor. An optional DVI-D cable is available from Motion Computing.
To use a digital video interface monitor you must use this cable with your Tablet
Client.
AC point of connection for the AC adapter
Standard RJ-45 connector for a 10/100/1000 Mbps network
A standard DB-15 monitor connector for an external monitor, projector, or other
VGA device
Connects the Tablet Client with the Motion FlexDock for the LE series (not
pictured in the illustration)
Universal Serial Bus; a port for connecting USB 2.0 devices, such as a storage
device, mouse, printer, digital camera, or optical disk drives. You may need to
install drivers for these devices; consider your available system space when
installing drivers.
Microphone and headset plug; 3.5 mm plug
Integrated speakers that are muted when you connect a headset or external
speakers
Swipe-type sensor for scanning fingerprints; used for password management
and security; also serves as a scroll device in active application window
Measures the background light and automatically balances display brightness
Active cooling system vent, dissipates heat from the Tablet Client (side and
back) (not pictured in the illustration)
An external battery connector is included on the backside of the Tablet Client. It
is located under a sliding panel in the upper center of the chassis. The sliding
panel must be opened before attempting to attach the Extended Battery.
