Smart IP Manager - System Operating Manual

5.5.3.2 Booting the loudspeaker

The loudspeaker can be booted by clicking the 'Boot' button. The Smart IP loudspeaker turns OFF

and will drop from the network until it has booted.

The loudspeaker can be put to standby mode by clicking the 'Standby' button. When the

loudspeaker is in the standby mode, it can be woken up by clicking the 'Wake up' button – this is

the same button but with a different text to indicate the action.

The loudspeaker shows a green notification icon when a new firmware is available in the Genelec

Cloud. To update the firmware

1. Select the loudspeaker to be updated in the device tree.

2. Open the 'info' tab and click the 'Update' button. After this, the firmware is uploaded into

the loudspeaker and the icon turns blue. An alternate way to update is to right-click the

loudspeaker line and then select the 'Update firmware'.

3. When the upload of firmware has finished, the loudspeaker boots. In this situation the

loudspeaker goes offline for a moment. When the loudspeaker wakes up and reappears on

the network an orange icon is indicating that the update has been successful.

4. Confirm the update by opening the 'Open info' tab and click the 'Confirm' button. This is

necessary to keep the new firmware. An alternate way to check is to right-click the

loudspeaker and then select the 'Confirm update'. If the confirmation is not done, the

loudspeaker reverts back to the previous firmware version after the next reboot.

Figure 30. Firmware update status indicators.

page 34 of 48
