Table 1. System identifier documentation example.
Serial number Genelec MAC
4430AM180 AC:47:23:20:01:3A
: :
4430AM192 AC:47:23:20:00:10
With this information it's possible to track where each loudspeaker is located later without using
LED blinking and being in the same room. Receiver name is the most usable to make a
loudspeaker easier to identify later. The receiver name can be changed from Dante Controller.
Figure 4. Indentifiers.

4.2 Positioning and mounting the loudspeakers

Place the loudspeaker so that the line of the acoustic axis points towards the main listening area.
The AV install designers may indicate different aiming.
Dante MAC IP Address
00:1D:C1:82:22:31 DHCP
: :
00:1D:C1:82:22:41 192.168.1.23
page 12 of 48
Receiver Location
name
Genelec- Meeting
822231 Room1
: :
Genelec- Lobby
822241
