PM605A Hardware Instruction Manual
PONOVO POWER CO,. LTD
NO. 139 JINGHAI THIRD ROAD, BDA, BEIJING, CHINA, 100176
Office
TEL. +86 (10) 59089666
E-Mail
Info@relaytest.com
Website
www.relaytest.com / www.ponovo.com.cn
This manual is the publisher of PONOVO POWER CO., LTD. To make any kind of copy of this
manual please contact PONOVO POWER CO., LTD in advance.
This manual represents the technical status for the moment of publishing. The product information,
description and specifications mentioned in the manual do not have any contact binding force and
PONOVO POWER CO., LTD remains the right to make modifications to the technical
specifications and configurations without prior notice. PONOVO POWER CO., LTD does not take
responsibility to the possible error/mistakes in this manual.
PM605A
HARDWARE INSTRUCTION MANUAL
VERSION:
DATE:
PM605A-AE-1.10
DEC. 2019
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM605A and is the answer not in the manual?

Questions and answers

Related Manuals for Ponovo PM605A

Summary of Contents for Ponovo PM605A

  • Page 1 DATE: DEC. 2019 This manual is the publisher of PONOVO POWER CO., LTD. To make any kind of copy of this manual please contact PONOVO POWER CO., LTD in advance. This manual represents the technical status for the moment of publishing. The product information, description and specifications mentioned in the manual do not have any contact binding force and PONOVO POWER CO., LTD remains the right to make modifications to the technical...
  • Page 2 PM605A Hardware Instruction Manual Notes 1. This is highly precision device. In order to assure accuracy of output and measurement, it should be preheated more than 30 minutes after switching. 2. The power supply is AC 220V, 50A, 50Hz. DC or AC 380V is not allowed to inserted.

  • Page 3: Table Of Contents

    PM605A Hardware Instruction Manual Content 1.GENERAL DESCRIPTION ....................... 5 1.1....................5 UNCTIONS AND EATURES 1.2....................5 YSTEM ONFIGURATION 1.3......................6 ANEL ESCRIPTION 2. TECHNICAL PARAMETERS ....................8 2.1 AC .......................... 8 OUTPUT 2.2 DC ..................12 OUTPUT FROM CHANNEL 2.3 DC...
  • Page 4 PM605A Hardware Instruction Manual APPENDIX C PGPS02 DIAGRAM .................... 39...

  • Page 5: General Description

    It makes that the setting value is standard value (including phase and power) and output accuracy keeps still with temperature 15~35℃, etc come true. The PM605A software includes many test functions: DC sampling auto calibration, synchronization test, transmitter auto calibration, system function test, harmonic test and manual test unit.

  • Page 6: Panel Description

    PM605A Hardware Instruction Manual 1.3. Panel Description 1.3.1 Front panel Figure 1-1 Front panel  1——AC current signal output terminal: CH1, CH2, CH3  2——AC voltage signal output terminal: CH1, CH2, CH3, CH4  3——DC current/voltage signal output terminal: Idc, Udc ...
  • Page 7 PM605A Hardware Instruction Manual 1.3.2 Rear Panel Figure 1-2 Rear panel  1——Binary input terminal: A, B, C, D, E  2——Binary output terminal: 1, 2, 3, 4  3——Separated 300V DC voltage output terminal (Optional. The indicator will light when the output is beyond safe voltage.)

  • Page 8: Technical Parameters

    PM605A Hardware Instruction Manual 2. Technical Parameters 2.1 AC Output 2.1.1 Three-phase AC Current Three-phase uses the same power source: I1, I2, I3 and IA, IB, IC, they are corresponding to the CH1, CH2, and CH3 of current on the panel. The output amplitude and phase are independent.
  • Page 9 PM605A Hardware Instruction Manual 2.1.2 Three-phase AC Voltage Three-phase uses the same power source: U1, U2, U3 and UA, UB, UC, they are corresponding to the CH1, CH2, and CH3 of current on the panel. The output amplitude and phase are independent.
  • Page 10 PM605A Hardware Instruction Manual 2.1.3 AC Voltage CH4 It shares the same neutral point with CH1, CH2 and CH3. The output amplitude, phase and frequency are independent. Output range 0～120V Output resolution min. adjustment step ≤±0.1%, The relative error is no more than ±0.1% within 5V ～...
  • Page 11 PM605A Hardware Instruction Manual 2.1.5 Power Factor and Others Power factor Power factor adjustment range 1L～0～1C ≤±0.0005 Accuracy ≤±0.0001/3min Stability Active power and inactive power ≤±0.05%; Accuracy ≤±0.01%/3min Stability Active energy and inactive energy Level 0.05 Harmonic 2～21 Harmonic number 0～20%...

  • Page 12: Dc Output From Ac Channel

    PM605A Hardware Instruction Manual 2.2 DC Output from AC Channel 2.2.1 DC Output from AC Current/Voltage Channel DC output from AC current channel Output channel I1, I2, I3 0～5A Output range Output resolution and min 0.1mA adjustment step ≤±0.1%, The relative error is no more than ±0.1% within 500mA～5A.

  • Page 13: Dc Output

    PM605A Hardware Instruction Manual 2.3 DC Output 2.3.1 DC Current DC current Output range 0～20mA Output resolution and min. 0.1μA adjustment step ≤±0.05%, The relative error is no more than ±0.05% within 0.2mA～20mA. The Accuracy absolute error is no more than ±0.1μA within 0～0.2mA...

  • Page 14: Dc Measurement

    PM605A Hardware Instruction Manual 2.4 DC Measurement DC current measurement Input range ±20mA Out of range 120% Resolution 0.001% Display digits or 6 (±20mA range) ≤±0.01%RG Accuracy DC voltage measurement Input range ±10V Out of range 120% Resolution 0.001% or 6 (±10V range)

  • Page 15: Binary

    PM605A Hardware Instruction Manual 2.5 Binary 2.5.1 Binary Output 4 pairs independent binary outputs. Each pair can be extended by 16 channels. The breaking capacity of each binary output is no less than AC/DC 250V, 500mA. The time error of binary output: ≤0.1ms;...

  • Page 16: Pulse Volume

    PM605A Hardware Instruction Manual 2.6 Pulse Volume 2.6.1 Pulse Output Active pulse output, level 5V±5%, current output 100mA; Max. pulse frequency: 5KHz. 2.6.2 Pulse Input Active pulse input, level 5～24V, current input 1mA; Max. pulse frequency: 5KHz 2.7 GPS Time Synchronization Input 2.7.1 PGPS Synchronization Device Signal Input...

  • Page 17: Optional Accessories

    PM605A Hardware Instruction Manual 2.8 Optional Accessories 2.8.1 Separated 300V DC Voltage (Optional) Output range: 0～300V; Output resolution and min. adjustment step: 1mV; Accuracy: ≤±0.1% (The relative error is no more than ±0.1% within 30V～300V. The absolute error is no more than ±30mV within 0～30V.) Stability: ≤±0.05%/3min;...

  • Page 18: Environment Conditions And Factors

    PM605A Hardware Instruction Manual 2.10 Environment Conditions and Factors The basic working conditions are for factory inspection, and the rated working conditions are for products adjustment and usage environment. Factor Basic working condition Rated working condition Environment 20℃±2℃ -5℃～+45℃ temperature Relative humidity 45%～75%...

  • Page 19: Shell Protection

    PM605A Hardware Instruction Manual 2.11 Shell Protection Shell protection standard applies with the IP21 regulated in GB 4208-1993. 2.12 Communication Interface RS-232 interface: synchronized with PGPS. PC communication interface: USB interface or RJ45 interface. 2.13 Other Parameters Aluminum case with cover and handle.

  • Page 20: Off-Line Working Method

    DC fixed point calibration, AC manual calibration, binary calibration, AC U4 calibration, DC 5A calibration and DC 300V calibration, etc. 3.2 Operation Panel PM605A operation panel is showing in figure 3-1. Figure 3-1 PM605A operation panel The operation panel includes LCD monitor, rotary encoder and five function buttons.

  • Page 21: Off-Line Interface

    PM605A Hardware Instruction Manual 3.3 Off-line Interface When PM605A works off-line, it automatically enters into the following interface after power on. Figure 3-2 Main interface of off-line Operate the rotary encoder, move the cursor into the item needed and press the encoder, enter into the selected interface.

  • Page 22: Ac Fixed Point Calibration

    PM605A Hardware Instruction Manual 3.4 AC Test In this unit, we can make AC test of RTU and measuring device according to setting calibration point on basis of rated value. The closed-loop calibration of transmitter power can also be made.
  • Page 23 PM605A Hardware Instruction Manual 3.4.1 AC Sample Calibration 1. AC current calibration Set rated current I Set load current percentage (calibration point); Put out calibration power. 2. AC voltage calibration Set rated voltage U : phase voltage or line voltage can be selected.
  • Page 24 12mA when 0 is input in transmitter. Connect DC signal of transmitter with DC signal input of PM605A. The DC amplitude will be showed in DC ln area and percentage error will be showed in Err area.

  • Page 25: Dc Fixed Point Calibration

    Select Idc or Udc in output channel; Set rated value; Connect DC signal output of transmitter with PM605A DC signal input. The DC amplitude will be showed in DC ln area and percentage error will be showed in Err area.

  • Page 26: Ac Manual Calibration

    PM605A Hardware Instruction Manual 3.6 AC Test Step In this unit, users can set any AC current output and voltage amplitude, phase, frequency and binary status, etc. When binary from A to E has change, the output will stop. The t means the action time of binary.

  • Page 27: Binary Calibration

    PM605A Hardware Instruction Manual 3.7 Binary Checker In this unit, users can set 4 binary outputs including Pre-reverse status and reversing status. This function can check the remote signal function and accident resolution of monitoring equipment. BINARY CHECKER State StateTime TripTime 1.000...
  • Page 28 PM605A Hardware Instruction Manual 3.7.3 Event Avalanche Tested Set the parameters of 4 channel binary output reverse status and time the same. Extend 4 channels binary output signals into multi-channel parallel outputs and connect with remote signal input terminal. The binary output needs extra voltage.

  • Page 29: Calibration

    PM605A Hardware Instruction Manual 3.8 AC Test (380V) In this unit, users calibrate the AC sample and AC voltage transmitter based on percentage of rated value. AC TEST(380V) 57.735 0.00 ° 57.735 240.00 ° 57.735 120.00 ° 57.735 0.00 °...

  • Page 30: Dc 5A Calibration

    PM605A Hardware Instruction Manual 3.9 DC Test (5A) In this unit, users can make DC sample and calibrate DC current transmitter based on percentage of rated value. DC TEST (5A) 0.0000 0.0000 0.0000 Trans. DC In mA Err Range 0.00000 4-20mA 0.0000...

  • Page 31: Dc 300V Calibration

    PM605A Hardware Instruction Manual 3.10 DC Test (300V) In this unit, users can make DC sample and calibrate DC voltage transmitter according to the rated value. DC TEST (300V) U1-2 0.000 U1-2 0.000 U300 U300 Trans. U1-2 DC In mA Err Range 0.00000...

  • Page 32: Calibration Wiring And Operation

    PM605A Hardware Instruction Manual 3.11 Calibration Wiring and Operation 3.11.1 Calibration Wiring PM605A and measuring and control unit will be connected under off-line as following diagram PM605A l t a i t t Binary Output Binary Input Control Unit/RTU/ Current Transmitter Figure 3-10 Off-line calibration wiring diagram The current and voltage are the basic wiring connection.
  • Page 33 PM605A Hardware Instruction Manual 3. Start/stop calibration When the kit stops working, the function key 1 will display output. After setting parameters, press function key 1, the kit will start to work. The indicator “Run” on the panel will flash according to set parameters and status.

  • Page 34: Appendix A Abnormal Phenomenon

    PM605A Hardware Instruction Manual Appendix A Abnormal Phenomenon  Switch on the kit, short circuit voltage and over heat occur. The reason might be:  The power supply is too low. Measuring the power supply by multimeter, if the voltage is less than 170V, the power supply should be improved.

  • Page 35: Appendix B Pgps02 (Optional)

    PM605A Hardware Instruction Manual Appendix B PGPS02 (Optional) 1. Main functions ● Output accurate synchronous signals. ● Local timing: synchronous signal trigger time can be set locally. ● Exam antenna connection and indicate the state of connection and power supply.
  • Page 36 PM605A Hardware Instruction Manual Input Voltage DC: +6 V~ +12 V Input Current >500mA Power Supply by RT Device DC: +5 V Environmental Operating Temperature --20 c ~ +70 c Storage Temperature -30 c ~ +80 c General Weight 640g (PGPS02-GPS Only) Dimensions (W×H×D)
  • Page 37 PM605A Hardware Instruction Manual 3 Panel Introductions Front Panel 1. OLED Display: Organic Light Emitting Display 2. Status Indicating Lamps  POWER: Red lamp lighting up after power-on  GPS LOCK: Green lamp lighting up after locking 4 satellites at least ...
  • Page 38 PM605A Hardware Instruction Manual Rear Panel 6. Antenna Connector 7. USB Port Socket: Connect with computer and use host software control PGPS02-GPS. 8. External Power Supply Plug-in: On the condition of RT test instruments power supply failure, use the external power socket.
  • Page 39 PM605A Hardware Instruction Manual Appendix C PGPS02 Diagram Antenna Clock Serial Port Line Note: DC power is supplied while PGPS02 fails to provide power.
