5. When using your charger, basic precautions should always be followed,
including the following:
• Read warnings on the charger cord label before operating the charger
for the first time. Read all instructions in this guide before using this
charger.
• Never use the charger with an extension cord.
• Never use the charger with any AC adapter.
• Shock hazard – make sure the plug is fully inserted into the wall outlet
so that there are no exposed blade surfaces.
• Children should be supervised when in the vicinity of the charger
while plugged in.
• To reduce the risk of fire, connect only to a circuit provided with
40 amps maximum branch circuit overcurrent protection.

Charging Display Overview

1
2
3
4
1. Real-time voltage
2. Charge amount
3. Charging time
4. Unit temperature
5. Real-time current
Note: Be sure to set the charging current before inserting the handle into
the vehicle.
32.0A
225.39V
0.05KWH
00:02:29
36.0℃ 32A
0.0A
5
225.39V
6
0.05KWH
00:02:29
Leakage Error
7
36.0℃
6. Charging icon
7. Rated current
8. Fault icon
9. Cause of fault
8
FAULT
9
32A
