Summary of Contents for AGM Global Vision FOXBAT
- Page 1 FOXBAT NIGHT VISION BI-OCULAR USER MANUAL...
- Page 2 EXPORT INFORMATION Buyer acknowledges that all products supplied by AGM Global Vision, LLC are subject to U.S. export control laws, including, but not limited to, the Export Administration Regulations, the International Traffic in Arms Regulations, the International Economic Emergency Powers Act, and various U.S. embargoes and sanctions.
-
Page 3: Table Of Contents
2.1 Installation and mounting 2.2 Controls and Indicators 2.3 Operating Procedures SECTION 3. MAINTENANCE INSTRUCTIONS 3.1 Cleaning Procedures 3.2 Troubleshooting 3.3 Preparation for Extended Storage SECTION 4. WARRANTY INFORMATION 4.1 Warranty Information and Registration SECTION 5. SPECIFICATIONS 5.1 Specifications FoxBat USER MANUAL... -
Page 4: Safety Summary
Light from the IR illuminator is more easily detected by other NVDs when used in fog, smoke, and rain. Avoid prolonged use of the IR illuminator in these conditions. • Do not use contaminated eyecups. If it is contaminated, it must be replaced. AGM Global Vision... - Page 5 Remove the battery from the unit when it will be stored for more than 3 days. Failure to do so may damage the unit. EQUIPMENT LIMITATIONS To avoid injuries and equipment damage from using the FoxBat, carefully read and consider the following equipment limitations. •...
-
Page 6: Section 1. General Information
The FoxBat night vision bi-ocular is the perfect tool for mid-range and long-range observation. The FoxBat combines a single high quality image intensifier tube with a dualized optical axis and double eyepiece, making it applicable for long viewing sessions. The FoxBat is available in two configurations - 5x and 8x magnification. -
Page 7: Standard Components And Optional Equipment
Mounting Rail Battery Cap STANDARD COMPONENTS & OPTIONAL EQUIPMENT The standard components and optional equipment of the FoxBat are shown in Figure 1-3 and listed in Table 1-2. The ITEM column indicates the number used to identify items in Figure 1-3. -
Page 8: Key Features
Biocular optical system for long-term observation • Super-fast, multi-coated, all-glass optics • Rugged and versatile design • Waterproof • Ergonomic, simple, easy-to-operate controls • High-light overload protection • Auto brightness control • Long-range Infrared illuminator • Tipod mountable • Limited 3-year warranty AGM Global Vision... -
Page 9: Section 2. Operating Instructions
1. Carefully press each eyecup over the diopter cell retainer. 2. Rotate each eyecup into the proper viewing position. Adjust for the best fit. The eyecups must seal around your eyes and prevent the green light from showing outside of the eyepieces. FoxBat USER MANUAL... - Page 10 2.1.3 TRIPOD INSTALLATION FoxBat bi-ocular can be used on the tripod. To install FoxBat-5 on tripod, install Tripod Adapter first. Tighten the screw of tripod it in the 1/4” threaded socket of Tripod Adapter. To install FoxBat-8 on tripod, tighten the screw of tripod in the 1/4” threaded socket of bottom Picatinny rail of FoxBat-8.
-
Page 11: Controls And Indicators
CONTROLS AND INDICATORS The FoxBat is adjustable to accommodate different users and will correct for most differences in eyesight. The controls and indicators for the FoxBat are shown or described in Figure 2-4 and Table 2-1. FIGURE 2-4. FOXBAT CONTROLS TABLE 2-1. -
Page 12: Operating Procedures
If an operation must be carried out in changing light conditions, the user can shut down the protective system manually by closing the photoreceiver. CAUTION: DO NOT forget to open the photoreceiver after completing your mission. AGM Global Vision... - Page 13 4. To adjust IR beam divergence, rotate the objective lens. 5. To turn off the IR illuminator press the tail cap button again. 2.3.2 FOXBAT SHUTDOWN 1. Turn the function switch to the OFF position. The green glow of the viewing area will fade to black.
-
Page 14: Section 3. Maintenance Instructions
Doing so may damage the anti-reflective coating on the lens. The FoxBat lens is designed for the harsh outdoor environment and has a coating for durability and anti-reflection, but it may require occasional cleaning. Avoid scratching the lens and/ or leaving fingerprints on the lens. -
Page 15: Preparation For Extended Storage
3. Replace the battery cap. 4. Remove the long-range IR illuminator, if installed. 5. Ensure that the bi-ocular, accessories and case are free of dirt, dust, and moisture. 6. Place the bi-ocular and accessories into the carrying case. FoxBat USER MANUAL... -
Page 16: Section 4. Warranty Information
Customer. AGM Global Vision’s liability hereunder for damages, regardless of the form or action, shall not exceed the fees or other charges paid to AGM Global Vision by the customer or customer’s dealer. AGM Global Vision shall not, in any event, be liable for special,... - Page 17 AGM Global Vision’s service center at the address listed above. All merchandise must be fully insured with the correct postage; AGM Global Vision will not be responsible for improper postage or merchandise that becomes lost or damaged during shipment. When sending product back, please clearly write the RMA# on the outside of the shipping box.
-
Page 18: Section 5. Specifications
5 SPECIFICATIONS 5.1 SPECIFICATIONS TABLE 5-1. FOXBAT BI-OCULAR SPECIFICATIONS ITEM FOXBAT-5 FOXBAT-8 Magnification Lens System 140mm; F/2.0 216mm; F/1.8 9.4° 4.5° Focus Range 10 m to infinity 10 m to infinity Eye Relief 15 mm 15 mm Output Pupil Diameter... - Page 19 Voltage 4.2V Charging Time 2.5 hrs Weight (without battery) 174 g / 0.4 lb Dimension 149 × 45 × 45 mm / 5.7 × 1.8 × 1.8 in NOTE: All data is subject to change without notice. FoxBat USER MANUAL...
- Page 20 AGM Global Vision, LLC MAIN OFFICE 173 West Main Street PO Box 962 Springerville, AZ 85938 Tel. +1.928.333.4300 info@agmglobalvision.com www.agmglobalvision.com EUROPEAN OFFICE #6 Andrey Lyapchev Blvd Sofia, P.C. 1756 Bulgaria Tel. +35.988.560.0326 info@agmglobalvision.eu www.agmglobalvision.eu AGMglobalvision.com...
