RADLEY 5125-017 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

Advertisement

Table of Contents
loading

Related Manuals for RADLEY 5125-017

Summary of Contents for RADLEY 5125-017

  • Page 2 40V Max* Lawn Mower Owner's Manual PRODUCT SPECIFICATIONS 40V MAX* LAWN MOWER Rated voltage 40V (2 x 20V) No Load Rated no load speed 3300 RPM 47" /120cm x 13¾" /35cm x 37" /95cm Dimensions Cutting width 13"/34cm Cutting height "- 3 "...

  • Page 3: Table Of Contents

    5125-017 TABLE OF CONTENTS Product specifications ………….……………………………………………………………1 Table of contents ………….……………………………………………………………2 General safety warnings ……….……………………………………………………………3-4 Lawn mower safety ……….……………………………………………………………4-6 Battery Pack and Charger Safety ………………………………………………………6-8 Recycling and disposal ……….……………………………………………………………9 Symbols …….……………………………………………………………10-12 Assembly …………………………………………………………13 Know your lawn mower ….……………………………………………………………13-14 Assembly ….……………………………………………………………15-17 Know your battery ….……………………………………………………………17-18...

  • Page 4: General Safety Warnings

    40V Max* Lawn Mower Owner's Manual GENERAL SAFETY WARNINGS WARNING: Before using this tool or any of its accessories, read this manual and follow all Safety Rules and Operating Instructions. The important precautions, safeguards and instructions appearing in this manual are not meant to cover all possible situations.

  • Page 5: Lawn Mower Safety

    5125-017 WARNING: Ventilation openings in batteries and chargers must always be open to allow cooling air to circulate freely. Air vents that are blocked, restricted or covered may result in the battery or charger overheating. Overheating may lead to damage to the tool or cause a fire, resulting in possible serious injury.
  • Page 6 40V Max* Lawn Mower Owner's Manual LAWN MOWER SAFETY CONT’D OPERATION Operate the product in daylight or in good artificial light. Avoid operating the product in wet grass, where feasible. Always be sure of your footing on slopes. Walk, never run. Mow across the face of slopes, never up and down.

  • Page 7: Battery Pack And Charger Safety

    5125-017 Be careful during adjustment of the product to prevent entrapment of the fingers between moving blades and fixed parts of the product. Allow the product to cool before storing in any enclosure. When servicing the blades be aware that, even though the power source is switched off, the blades can still be moved.
  • Page 8 40V Max* Lawn Mower Owner's Manual Longer life and better performance can be obtained if the battery pack is charged when the air temperature is between 75˚F /24˚C and 64˚F/18 ˚C. Do not charge the battery pack in air temperature below 41˚F / 5˚C or above 105˚F / 40.5˚C.
  • Page 9 5125-017 Do not attempt to charge battery packs other than those supplied. The charger and battery pack supplied with it are specifically designed to work together. Before each use, check the charger, cable and plug. Do not use a defective charger and do not disassemble the charger.

  • Page 10: Recycling And Disposal

    140V Max* Lawn Mower Owner's Manual RECYCLING AND DISPOSAL WARNING! Do not dispose of batteries/rechargeable batteries into household waste! Please recycle where facilities exist. Check with your local authority or local store for recycling advice.
  • Page 11 5125-017 SAFETY SYMBOLS WARNING! Please read all of the safety and operating instructions carefully before using this tool. Please pay particular attention to all sections of this User Guide that carry warning symbols and notices. Some of the following symbols may be used on this tool.
  • Page 12 40V Max* Lawn Mower Owner's Manual Inspect the area where the Warning! Danger. product is to be used and remove all objects which Read the operator’s manual. can be thrown by the product. If objects are hidden while WARNING! Beware of operating stop the product electric shocks.
  • Page 13 5125-017 Beware of sharp blades. Remove plug from the Blades continue to rotate power source immediately if the power cord is after the motor is switched off - Remove disabling damaged or cut. device before Crossed out dust bin. maintenance.
  • Page 14 40V Max* Lawn Mower Owner's Manual KNOW YOUR 40V MAX* LAWN MOWER...
  • Page 15 5125-017 Part name Part name Grip handle Carry handle Upper handlebar Wire clip (x2) Knob (x4) Control cord a. Washer (x4)* Start lever Bolt (x2) Safety lock-off switch Lower handlebar (Left) Switch box Transport handle Full bag indicator Battery compartment cover...

  • Page 16: Assembly

    40V Max* Lawn Mower Owner's Manual ASSEMBLY UNPACKING Unpack all parts and lay them on a flat, stable surface. Remove all packing materials. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product and contact Customer Service @ 1-866-349-8665.
  • Page 17 5125-017 UPPER HANDLEBAR Align the upper handlebar (2) to the lower handlebar (5 / 14) and ensure the switch box (21) is pointed downward when viewed from behind. Pass the bolts (4) through the mounting holes of handles (Fig. 4, step 1).

  • Page 18: Know Your Battery

    40V Max* Lawn Mower Owner's Manual WARNING: Do not attempt to use the mower without the grass catcher attached - danger of flying objects! The motor must be switched off and the blade must have stopped rotating before you remove the grass catcher.
  • Page 19 5125-017 1 light 2 lights 3 lights (Red light ON) (Red and Orange (Red/Orange/Green light ON) or less -Fully charged 3. Release the battery status button to turn the LED’s OFF. CHARGING THE BATTERY PACK WARNING: Charge in a safe location away from moisture and heat sources! Place the battery charger (Fig.

  • Page 20: Operation

    40V Max* Lawn Mower Owner's Manual OPERATION INSTALLING THE BATTERY PACKS (Fig. 10) Open the battery compartment cover. Unplug the safety key (8). Remove the discharged battery packs by pressing downward on the battery release button and sliding the battery pack backward until it is removed from the battery compartment.
  • Page 21 5125-017 Adjust the cutting height according to the needs of your lawn. The cutting height depends on the kind of lawn and its actual height. When mowing high grass, start with the maximum cutting height and make a second cut with a lower cutting height.
  • Page 22 40V Max* Lawn Mower Owner's Manual FIG.12 FIG.13 When the full bag indicator (22) is opened the grass catcher has sufficient volume left to collect grass (Fig. 12). When the full bag indicator (22) is closed, the grass catcher is full and must be emptied (Fig.
  • Page 23 5125-017 Switch the product off immediately if you are disturbed while working by other people entering the working area. Always let the product come to complete stop before leaving it unattended. Do not overwork yourself. Take regular breaks to ensure you can concentrate on the work and have full control over the product.

  • Page 24: Maintenance

    40V Max* Lawn Mower Owner's Manual MAINTENANCE WARNING: Always switch the product off, remove the battery packs and the safety key and let the product cool down before performing inspec- tion, maintenance and cleaning work! Keep the product clean. Remove debris from it after each use and before storage.
  • Page 25 5125-017 Keep the cutting blade sharp to ensure a good cutting performance. Replace a worn or damaged cutting blade with a new one of the same type or have it sharpened by a qualified specialist. Loosen the hex bolt counterclockwise using the delivered hex wrench and remove it together with the washer and the cutting blade (Fig.14).
  • Page 26 40V Max* Lawn Mower Owner's Manual CONTROL CORD Check the control cord before each use. WARNING! Do not use the product with a defective or a loose control cable! CHARGER If the power cord of the charger is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a safety hazard.

  • Page 27: Exploded View

    5125-017 EXPLODED VIEW...

  • Page 28: Parts List

    40V Max* Lawn Mower Owner's Manual PARTS LIST WARNING: When servicing, use only original equipment replacement parts. The use of any other parts may create a safety hazard or cause damage to the lawn mower. Any attempt to repair or replace electrical parts on this lawn mower may create a safety hazard unless repairs are performed by a qualified technician.
  • Page 29 5125-017 Key # Part # Part Name Quantity 3152300101139001 Blade hub 3222530101060001 Tension spring 3252300201030001 Brake block 3252300101030001 Friction plate 3122530101049001 Gear box housing 33SBAQA005200101 Screw 33DB600302011 Bearing 3222530301020001 Output shaft 3222530201060001 Torsion spring 3222530101052001 Gearwheel 33DB608001011 Bearing 33CC0120101 Clamp spring...
  • Page 30 40V Max* Lawn Mower Owner's Manual Key # Part # Part Name Quantity 3122530401069001 Rear cover 33SBAQD004150101 M4*12 combination 3222530101039001 Catcher rebar 3122530201094001 Catcher hand shank 3122530501069001 Catcher cover 3122530701069001 Louver cover 3522530101045001 Catcher bag 3222530201057001 Down left push rod 36010101 6.3 terminal 3419510301027001...

  • Page 31: Warranty

    WARRANTY RADLEY 40V MAX* LAWN MOWER WARRANTY If this Radley tool fails due to a defect in material or workmanship within three years from the date of purchase, return it to any Home Hardware store with the original bill of sale for exchange.
