Safety instructions GENERAL POWER TOOL SAFETY WARNINGS WARNING! Read safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
Page 9 c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Page 10 e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts.
Page 11 e) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool’s operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
Page 12 e) Do not use battery pack or tool that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. f) Do not expose a battery pack or tool to fire or excessive temperature.
Page 13 b) Always start drilling at low speed and with the bit tip in contact with the workpiece. At higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the workpiece, resulting in personal injury. c) Apply pressure only in direct line with the bit and do not apply excessive pressure.
Page 14 c) Do not carry or store battery together with necklaces, hairpins or other metal objects. d) Do not pierce the battery with nails, strike the battery with a hammer, step on the battery or otherwise subject it to strong impacts or shocks. e) Do not solder directly onto the battery.
Page 15 s) Remove the battery from the drill or charger when not in use. The following information applies to professional users only but is good practice for all users: ADDITIONAL SAFETY WARNING FOR CONSTRUCTION DUST The updated Control of Substances Hazardous to Health Regulations 1st October 2012 now also targets to reduce the risks associated with silica, wood and gypsum dusts.
Page 16 To protect the lung, the COSHH Regulations sets a limit on the amount of these dusts that you can breathe (called a Workplace Exposure Limit or WEL) when averaged over a normal working day. These limits are not a large amount of dust: when compared to a penny it is tiny –...
Page 17 WARNING! Some dust particles created by power sanding, sawing, grinding, drill and other construction jobs contain chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. • Crystalline silica from bricks and cement and other masonry products.
Page 18 The declared vibration total value has been measured in accordance with EN 62841-1 and EN 62841-2-1 and may be used for compare one tool with another. The declared vibration total value may also be used in a preliminary assessment of exposure. WARNING! The vibration emission during actual use of the power tool can differ from the declared total value depending on the ways in which the tool...
Page 19 WARNING! Identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time).
Page 20 c) Use correct attachments for the product and ensure they are in good condition. d) Keep tight grip on the handles/grip surface. e) Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate). f) Plan your work schedule to spread any high vibration tool use across a longer period of time.
Page 21: Product Description
c) Danger of injury and property damage caused by flying objects or poor power tool accessories. Product description Part index The index below refers to Fig. 1 on page 4. 1. Keyless chuck 8. Screw a. Chuck sleeve 9. Belt clip b.
Page 22 > Max. drilling capacity : Wood: 30 mm Steel: 10 mm Brick/Limestone: 10 mm > Weight (without battery pack) : approx. 1 kg Battery pack > Model no. : EHPB12-Li-3 > Type : Li-Ion > Capacity : 3000 mAh > Voltage : MAX.
Page 23 Rating label explanation ECD12-Li-2 = Model number E = Erbauer CD = Combi Drill 12 = 12 V d.c. Li = LITHIUM ION 2 = 2 Gear Speed Symbols On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations.
Page 24: Assembly
WEEE symbol. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or local store for recycling advice. Crossed out dust bin. Batteries and battery packs should not be disposed of with household waste.
Page 25 NOTE: Take care of small parts that are removed during assembly or when making adjustments. Keep them secure to avoid loss. Setup Battery pack Release / Attach 1. Lock the On/Off switch (12) to avoid accidental starting by moving the forward / reverse rotation control (6) into the middle position (See below section “Controls –...
Page 26 Drill and driver bits Different drill and driver bits can be used with this product depending on the material being worked with. WARNING! Always use drill bits according to the intended use! For example, never use drill bit intended for working on wood for working on metal or vice versa! Observe the technical requirements of this product (see section Technical specifications) when purchasing and using drill bits and driver bits!
Page 27: Use
Intended use This product is intended for drilling in wood and similar materials e.g. MDF, plywood, plastic, metal and impact drilling in brick and concrete, as well as for screw driving. It should not be used for working on materials that are dangerous to health. For safety reasons it is essential to read the entire instruction manual before first operation and to observe all the instructions therein.
Page 28 Forward / reverse rotation control Change the rotational direction from forward to reverse by pressing the forward / reverse rotation control (6). WARNING! Only change the rotational direction when the product is switched off and has come to a complete stop! Always ensure that the forward / reverse rotation control (6) is adjusted to the correct position depending on the intended operation! Always push the forward / reverse rotation control (6) as far as it will go!
Page 29 Function selection ring Three working modes are available on this tool: drilling, screw driving and impact drilling. To select any of the three modes, rotate the function ring to align it with icon of the drill/screwdriver/ hammer on the housing, depending on the function you desired (Fig.
Page 30 Operation 1. Check the product, as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. 2. Double check that the accessories and attachments are properly fixed. 3. Always hold the product on its handles. Keep the handles dry to ensure safe support.
Page 31 1. Ensure that correct drill bit is applied and all controls are set in correction position. 2. Always hold the product perpendicular to the point to be drilled. Holding it at an angle may cause slipping or jamming of the drill bit. Loss of control can cause personal injury.
Page 32 Additional tips for impact drilling NOTE: In principle, drill masonry in impact drilling mode with maximum speed. However, in the first few seconds, the drill bit may deviate from the original desired position due to the impact action. To avoid this, use inching impact mode or drill mode with low speed and low feeding force before the drill bit tip is well seated in workpiece.
Page 33: Care & Maintenance
Care & maintenance WARNING! Always switch the product off, remove the battery back and let the product cool down before performing inspection, maintenance and cleaning work! Only perform care and maintenance work according to these instructions! All further works must be performed by a qualified specialist! Clean 1.
Page 34 Storage 1. Switch the product off and remove the battery pack. 2. Clean the product as described above. 3. Store the product and its accessories in a dark, dry, frost-free, well-ventilated place. 4. Always store the product in a place that is inaccessible to children. The ideal storage temperature is between 10 °C and 30 °C.
Page 35 Problem Possible cause Solution 3. Unsatisfactory 3.1. Drill / driver bit is worn 3.1. Replace with a new one result 3.2. Drill / driver bit not suitable 3.2. Use suitable drill / driver for intended operation 4. Product 4.1. Product overloaded 4.1.
Page 36: Guarantee
Guarantee We take special care to select high quality materials and use manufacturing techniques that allow us to create products incorporating design and durability. This product Combi Drill) has a manufacturer’s guarantee of 3 years against manufacturing defects, from the date of purchase (if bought in store) or date of delivery (if bought online), at no additional cost.
Page 37 Batteries and battery chargers are not covered under the Erbauer 3 Year Warranty and will have a guarantee period of 2 years from the date of purchase. If the product is defective, we will, within a reasonable time, repair or replace it.
Page 38: Declaration Of Conformity
Declaration of conformity MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V9_210401.indd 38 4/1/21 4:53 PM...
Page 39 21/07/2021 MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V9_210401.indd 39 4/1/21 4:53 PM...
Page 40 EN 62841-1:2015 BS EN 62841-1: 2015 EN 62841-2-1:2018+A11:2019 BS EN 62841-2-1: 2018+A11: 2019 EN 55014-1:2017+A11:2020 EN IEC 55014-1:2021 EN 55014-2:2015 EN IEC 55014-2:2021 BS EN 55014-1: 2017+A11: 2020 BS EN IEC 55014-1:2021 BS EN 55014-2: 2015 BS EN IEC 55014-2:2021 On: 21/07/2021 MNL_Erbauer_GB_EID12-Li-2_12V Impact driver_V12.indd 29 3/30/21 7:04 PM...
Page 44 EU manufacturer: Kingfisher International Products B.V. Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands www.diy.com | www.screwfix.com | www.screwfix.ie To view instruction manuals online, visit www.kingfisher.com/products Customer Helpline: UK 03301248111 erbauer@powertoolservicing.co.uk Eire 0035312479977 erbauer@powertoolservicing.co.uk MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 41 4/22/21 6:20 PM...
