CyClone SC50024 Use And Care Manual

OPERATION INSTRUCTIONS
Fan Operation
Fan Speeds: Three speed settings give the customer total control of their fan at the push of
a button.
Timer: This collection features a time-delay off feature to automatically shut the fan off after
1 to 9 minutes to conveniently clear the smoke and grease after cooking. To program the
time-delay feature, press the button with the clock icon while the machine is on and then use
the lowest speed setting button to toggle between 1 to 9 minutes.
Grease Disposal
WARNING!
Do not remove filters or grease cups immediately after cooking or if grease is
still hot.
Nonstick-coated fan blades will separate grease from the air and the grease will then be
deposited into a grease cup for easy, convenient disposal. You will find the grease cup in a
bag with the bracket and screws in the box. The grease cup can be used in conjunction with
the mesh filters with certain models, while others can only use one or the other.
Tip: Soak all parts in soapy water if there is heavy grease.
Changing Light bulbs
WARNING!
Ensure that all power leading to your range hood has been disconnected
before changing bulbs. As well, ensure that lights have fully cooled before changing bulbs.
To change the light bulb, remove light case from the light socket. The light case can be
accessed from the inside of the body of the machine.
1. Disconnect the connecting wires of the light socket from the motherboard wires.
2. Remove grease filters and push light case outward away from the machine.
3. Once the light case has been detached from the range hood, use a flat screw driver to
remove the glass cover of the light case.
4. Detach light bulb and replace with a new bulb.
Baffle Filters
WARNING!
Ensure that all power leading to your range hood has been disconnected
before removing filters and cleaning your fan.
Removal: In order to remove the baffle filters, push downwards on the knob near the front of
the machine and pull the filter downwards away from the machine.
Disassembly: To disassemble the baffle filter, unscrew the top knob with pliers. Your filter
will disassemble into two halves of the filter, the knob, and a nut. The two filter pieces can be
cleaned in the top rack of the dishwasher.
Reassembly: To reassemble the pieces of the baffle filter, first place the two pieces of the
filter against each other. When placing the filter together, ensure that all tabs fit into the slots
to keep both pieces of the filter attached. Place the knob and the nut together, then screw
the knob into the nut.
USE AND CARE GUIDE
MODELS
SC(B)50024
SC(B)30024
Power/Timer
Fan
Light
Control
Control
Fan Housing
