PROGRAMMING
CALIBRATION TEMPERATURE SETTING
Adjusts the temperature reading the sensor
probe is measuring. Press the up or down button
to increase or decrease the data figure in 1°
increments. The calibration cycle ranges from
-20°F to 20°F (or -10°C to 10°C) and will be
applied to the sensor probe's measurements.
CALIBRATION HUMIDITY SETTING
Adjusts the relative humidity reading the sensor
probe is measuring. Press the up or down button
to increase or decrease the data figure in 1%
increments. The calibration cycle ranges from
-10% to 10% and will be applied to the sensor
probe's measurements.
CALIBRATION LEAF OFFSET SETTING
Adjusts the VPD reading the sensor probe
is measuring. Press the up or down button
to increase or decrease the data figure in 1°
increments. The calibration cycle ranges from
-20°F to 20°F (or -10°C to 10°C) and will be
applied to the sensor probe's measurements.
