- Page 1 Ver 1.0 M ODEL : DN-70 DIGITAL INDICATOR USER MANUAL DACELL CO.,LTD. Address : 37-9 Cheoksan 5gili, Nami-Myeon,Seowon-gu, Cheongju-city, Chung-buk TEL :82-43-260-2242 FAX : 82-43-260-2245 http://www.dacell.com E-Mail : info@dacell.com...
-
Page 2: Table Of Contents
Contents 1. Features ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-1. Calibration method ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-2. HOLD & PEAK HOLD ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-3. Comparison Output ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-4. Data Back-up ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-5. Watch dog ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 2. Attention ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 2-1. Attention for installation ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 2-2. -
Page 3: Features
1. Features We thank you for using our product. Please refer to this manual or contact our office if you find any problems during using our product. This product is an indicator that emplifies the micro voltage signals from each sensor and display in digital. -
Page 4: Attention
2. Attention For the efficient and safe use, please carefully read and be fully aware of the following details before using this product. It is strictly forbidden to use this product for any other purpose of use or to attempt to make any alteration on this product. -
Page 5: Specification
3. Specification • Available sensor DN-70 : Strain Gauge sensor • SIGNAL DN-70 : 1 ~ 3mV/V • EXCITATION : 5V • Upper limit Display : -19999 ~ +99999 • A/D Converter : 24bit • D/A Converter : 16bit • Temperature Characteristic (Amp Characteristic) Zero : 0.5μV/℃... -
Page 6: Front Panel
4. Front panel ① HI, LO Indication LED: LED will be lighted when measured value exceeds the setting value. ② HOLD Indication LED: This LED will be lighted when the measured value is on Hold. ③ MOD : Measured value stable (on), unstable (off) indication ④... -
Page 7: Rear Panel
5. Rear Panel Please check the location of terminal and its use. While the projected button is being pressed, please insert the cable into the lower hole completely. As soon as you release the button, the connection will be completed. At the point, please slightly pull the calbe and check whether the cable is come off or not. - Page 8 ※ OPTION ⑮ GND, TXD, RXD : RS232C SERIAL INTERFACE Terminal (RS485 : TXD -> TX+, RXD -> TX-) ○ GND, OUT : Analog out Terminal (DC ±10V or DC 4~20mA) ◀Attention▶ 1. When wiring, please pull out the power plug. (Main power supply) 2.
-
Page 9: Wiring Diagram
6. Wiring Diagram <Wiring Diagram> <Example - External Input PLC Connection>... -
Page 10: Components & Function
7. Components & Function 7-1. How to use Hold mode Hold mode is largely divided into Peak Hold and Sample Hold. Please select Peak or Sample. To input Hold, you can use Hold key on the front panel or external input. For the operation method, please refer to the drawing below. -
Page 11: How To Use Comparison Output Function
7-2. How to use comparison ouput function For comparison output function, there are 3 different modes such as Decision, High limit, Low limit. It displays through the relay of rear panel comparing each setup value. On High limit and Low limit mode, Hysteresis can be used. To set up upper limit (High) and lower limit(Low), please use the key on the front panel. -
Page 13: Setting Mode
8. Setting Modes 8-1. Types of Setting mode & Set-up For Setting mode, there are 3 different types of mode such as Function mode, Digital calibration mode, Actual load calibration mode. Mesuring mode While key is being Press, press Function mode ①... -
Page 14: Function Mode (Function Set-Up)
8-2. Function mode 1) How to set function Measuring mode While key is being Press, press... - Page 15 2) How to set RELAY data ① Decision mode (Decision mode: mode 0) ② Limit mode (Low & High limit mode: mode 1 ~ 2) Measuring mode Press Input value...
- Page 16 # Function mode list # Name Function Setting 출고시 기준설정값 F-01 Decimal point 0, 1, 2, 3 F-02 Division 1, 2, 5, 10, 20, 50 F-03 Display filter 1, 2, 5, 10, 20, 50, 100 F-04 Hold mode Sample hold, Peak hold, Absolute peak hold Peak hold F-05 Comparison mode Decision, High limit, Low limit...
- Page 17 F-01. Decimal point (Decimal point Set-up) (Standard setup value: 1) Display data Setting 00000 : No decimal point 0000.0 : One decimal place 000.00 : Two decimal places 00.000 : Three decimal places F-02. Division (Minimum display unit setup) (Standard setup value: 1) Display data Setting Displayed In 1...
- Page 18 F-05. Comparision mode (Comparision output mode setup) (Standard setup value: 0) Display data Setting Decision mode : Relay RY1(Lo), RY2(Hi), RY3(Ok) Output High limit mode : Relay RY1, RY2, RY3 Output Low limit mode : Relay RY1, RY2, RY3 Output F-06.
- Page 19 F-10. Baud rate & Print (Communication Speed Setup) (Standard setup value: 9.60) Display data Setting Stream mode Command mode 2.40 2400 bps 4.80 4800 bps 9.60 9600 bps 19.20 19200 bps PRINT PRINT DATA OUT (PT-100) F-11. Auto zero tracking (Auto zero operation range setup) (Standard setup value: 00) Display data Setting...
- Page 20 F-14. Key disabling (Front key locking set up) (Standard setup value: 0000) Display data Setting Hold key Lock (1), Release (0) Hi key Lock (1), Release (0) Lo key Lock (1), Release (0) Zero key Lock (1), Release (0) <Set-up example> 1001 : Zero &...
-
Page 21: Digital Calibration (Calibration By Sensor Output Value)
8-3. Digital calibration (Calibration by sensor output value) At the time of purchasing sensor, the rated capacity (R.C) and rated output (R.O) declared on the calibration sheet can be used for the calibration for easier calibration. Measuring Mode key is being While pressed, press key. - Page 22 8-4. Actual load calibration (실부하 교정) If the actual load (load, displacement, pressure) is applied to the sensor and there is a difference between the value displayed in the indicator and the actual load value, the display value of the indicator can be changed to the actual load value. Up to 8 points can be stored. As the calibration interval is differentiated, the linearity of the sensor can be increased.
-
Page 23: Da T A Ba Ck -U P & R Es T Or
8-5. DATA BACK-UP & RESTORE You can save all the set-up values of the device and then restore them to the current set-up state as per your need. ◦ DATA BACK-UP : Save the current set-up state. ◦ RESTORE : Restore the current set-up state 1) DATA BACK-UP Measuring mode While... -
Page 24: Lock Set-Up
8-6. Lock Set-up You can prevent any accidental operation due to the unnecessary key control by Lock set-up. After finishing calibration, it is recommended to set the Lock. At the first stage, please start while the power is OFF. Related Function when Lock is set : Function related to calibration. Power is OFF key is being pressed, While... -
Page 25: Product Inspection
9. Product Inspection Symptom Cause Action Remark • • Insulation • Load cell input, output. Load cell is damaged. • Check resistance When Display • Load cell insulation resistance • Check load cell’s trembles. (Cable & Case > resistance. • Indirect occurrence insulation resistance. -
Page 26: Option (Op-02, Op-03)
10. OPTION #Option-02 (RS232C) Since RS232C Interface is very sensitive of electric noise. So please do the wiring from AC Power and electric wires separately. Also you must use the shield calbe always. Indicator Host PC TX(Transmission Data) RXD(Receive Datea), No.2 Pin RX(Receive Datea) TXD(Transmission Data), No.3 Pin GN(Ground) - Page 27 2) BYTE3 ~ BYTE6 : fixed character (, N T ,) 3) BYTE7 ~ BYTE14 : DATA 8 BYTE (including +/- ) 4) BYTE15 : CARRIAGE RETURN 5) BYTE16 : LINE FEED 7. Command mode : Please setup as RS485 mode and use.( Refer to OP- 03:RS485 )
-
Page 28: Option 03 (Rs485)
#Option-03 (RS485) Since RS485 Interface is very sensitive of electric noise. So please do the wiring from AC Power and electric wires separately. Also you must use the shield calbe always. 1. TYPE : RS485 2. Method : Half-duplex, asynchronous method 3. - Page 29 9. Transmission Data Form (INDICATOR -> PC) CODE BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 ASCII H EX CODE BYTE9 BYTE10 BYTE11 BYTE12 BYTE13 BYTE14 BYTE15 BYTE16 ASCII H EX 1) BYTE1, BYTE2 : Fixed Charactor (ID) 2) BYTE3 ~ BYTE5 : Device number (1 ~ 32) 3) BYTE6 : Fixed Charactor (,) 4) BYTE7~BYTE14 : DATA 8byte (Including +/- )
