- Page 1 DIGITAL INDICATOR USER’S MANUAL DN-330 (VER 1.0) DN-340 (VER 1.0) DACELL CO.,LTD. Address : 37-9 Cheoksan 5gil ,Nami - Myeon , Seowon-Gu, Cheongju-city , Chung- Buk,Korea TEL : 043-260-2242 FAX : 043-260-2245 http://www.dacell.com E-Mail : info@dacell.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Features ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-1. Calibration Method ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-2. Comparison Output ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-3. Data Back-up ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-4. Watch dog 2. Precautions ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 2-1. Precautions for Installation ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 2-2. Precautions for Use ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 3. -
Page 3: Features
1. Features Thank you for choosing our product. Please refer to this manual or contact us if any problems occur during use. This product is an indicator that amplifies the micro voltage signal from various sensors to display them digitally. It is mainly used to measure physical quantities at objects using strain gage such as load cells, pressure sensors, displacement sensors, torque sensors, etc. -
Page 4: Precautions
2. Precautions Make sure to read and observe the following precautions to ensure the performance and safe use of this product. Use of this product for any other purpose of use or to attempt to make any alteration to this product is strictly prohibited. 2-1. -
Page 5: Specification
3. Specification Spec. DN-340,DN330 DSC40 Model 1 ~ 3mV/V SIGNAL ANALOG OUT DC 0~10V (4 ~ 20mA option) EXCITATION Pressure Sensor 4 Channel count Stainless gauge sensor Available (bridge 350Ω, 700Ω) Sensors Individual display: -1999 ~ +9999 Display range Sum display: -19999 ~ +99999 24 bit A/D converter D/A converter... -
Page 6: Front Panel
4. Front Panel ① Sum display: Displays 4CH sum, or setting value. ② 1CH Display: Displays the current value of 1CH. ③ 2CH Display: Displays the current value of 2CH. ④ 3CH Display: Displays the current value of 3CH. ⑤ 4CH Display: Displays the current value of 4CH. ⑥... - Page 7 Set-up Mode: Increases the flashing number by 1 digit. ⑬ Set-up Mode: Saves each setting. ***DN-330 : 3CH Total indicator 1.:Sum display: Displays 4CH sum, or setting value 2. 3, 4 : Displays the current value 1ch,2ch,3ch 5.: Relay status 6.: HOLD display LED...
-
Page 8: Rear Panel
5. Rear Panel To connect wiring, check for the position and use of terminals and insert the cable completely into the lower hole of the terminal block while the upper button is being pressed. Check if any cable is missing by pulling the cable slightly. (The recommended length of cable is Φ... - Page 9 ⑫ IN3: N/A ⑬ IN4: N/A ⑭ COM: RELAY Output common terminal ⑮ RY1: RELAY1 (Hi) output terminal RY2: RELAY2 (Lo) output terminal ○ RY3: RELAY3 (Ok) output terminal ○ RY4: RELAY4 output terminal ◀CAUTION▶ 1. Always turn off the system before wiring. 2.
-
Page 10: Wiring Diagram
6. Wiring Diagram < Wiring Diagram > < Example of External Input PLC Connection >... - Page 11 <DSC-40 Internal Wiring Diagram> <DSC-30 Internal Wiring Diagram>...
-
Page 12: Components And Function
7. Component and Function 7-1. How to Use Hold mode Hold mode is mainly classified into Peak Hold and Sample Hold and according to the intended use (High Speed, Low Speed), Analog, Digital, or Display Hold can be selected. Hold mode can be used by using the Hold key at the front panel or by the external input. For operation method, see the following figure. - Page 13 How to Use Comparison Output Function 7-2. In comparison output function, there are 3 different modes such as Decision, High limit, and Low limit. It displays each setup value (comparison output) at the Relay of the rear panel. In High limit and Low limit modes, Hysteresis can be used. To set the upper limit (High) and lower limit (Low), please use the key on the front panel.
-
Page 15: Setting Mode
8. Setting Modes 8-1. Type and Use of Setting Mode In Setting mode, there are three modes: Function mode, Digital calibration mode, and Actual load calibration mode. Measuring Mode While key is pressed, press key. Function mode ① Digital calibration ②... -
Page 16: Function Mode
8-2. Function mode 1) How to Set Function Measuring Mode While key is pressed, press key. -
Page 17: How To Set Relay Output Value
2) How to set RELAY Output Value ① Decision mode (Decision Mode: mode 0) Press the front Lo and Hi key for value setting and then ENT key. ② Limit mode (Comparison Output Mode: mode 1 ~ 3) Measuring Mode Press key. - Page 18 # Function mode list # Name Function Setting Default F-01 Decimal point 0, 1, 2, 3 F-02 Division 1, 2, 5, 10, 20, 50 F-03 Display filter 10, 20, 30, 40 F-04 Hold mode Display SH, Display PH(+) Display Sample hold Comparison mode Decision, High limit, Low limit, F-05...
- Page 19 F-01. Decimal point (Decimal point setting) (Default: 1) Display data Setting 00000 : No decimal point 0000.0 : One decimal place 000.00 : Two decimal place 00.000 : Three decimal place F-02. Division (Minimum display unit setting) (Default: 1) Display data Setting Displayed in 1 (0, 1, 2, 3, 4 …….)
- Page 20 F-05. Comparison mode (Comparison Output Mode setting) (기준설정값: 0) Display data Setting Decision mode : Relay RY1(Lo), RY2(Hi), RY3(Ok) Output High limit mode : Relay RY1, RY2, RY3, RY4 Output Low limit mode : Relay RY1, RY2, RY3, RY4 Output Low &...
- Page 21 F-10. Baud rate & Print (Communication Speed and Print Output setting) (Default: 9.60) Display data Setting Stream mode Command mode 2.40 2400 bps 4.80 4800 bps 9.60 9600 bps 19.20 19200 bps 38.40 38400 bps 57.60 57600 bps PRINT PRINT DATA OUT (PT-100) F-11.
- Page 22 F-14. Key disabling (Front key Lock Setting) (Default: 0000) Display data Setting Hold key Locked (1), Unlocked (0) Hi key Locked (1), Unlocked (0) Lo key Locked (1), Unlocked (0) Zero key Locked (1), Unlocked (0) <Setting Example> 1001: Zero and Hold key Lock, Hi and Lo key Unlock...
-
Page 23: Digital Calibration Calibration By Sensor Output
8-3. Digital calibration (Calibration by sensor output value) At the time of purchasing sensor, the rated capacity (R.C) and rated output (R.O) declared on the calibration sheet can be used for easier calibration. Measuring Mode While key is pressed, press key. -
Page 24: Actual Load Calibration
8-4. Actual load calibration This is a calibration method that applies actual load (load, displacement, pressure at the sensor. Standard load is required. Measuring Mode While key is pressed, press key. Display Function mode Display sensor output calibration state Display actual load calibration state Display CHANNEL selection status Display the CH1 Current Value key to enter 0500.0 and then press... -
Page 25: Lock Set-Up
8-6. Lock Set-up You can prevent any accidental operation due to the unnecessary key control by Lock set-up. After finishing calibration, it is recommended to set the Lock. At the first stage, please start while the power is OFF. Related Function when Lock is set : Function related to calibration Power off While key is being press,... -
Page 26: Product Inspection
9. Product Inspection Symptom Cause Action Remark Load cell is damaged. Load cell input, output. Insulation When Display Load cell insulation Check resistance resistance trembles. resistance. Check load cell’s (Cable & Case > Indirect occurrence insulation resistance. 1000 Mohm) Check load cell’s Loadcell faulty insulation resistance. -
Page 27: Option 02 (Rs232C)
10. OPTION #Option-02 (RS232C) Since RS232C Interface is very sensitive of electric noise. So please do the wiring from AC Power and electric wires separately. Also you must use the shield calbe always Indicator Host PC TX(Transmission Data), No.3 Pin RXD(Receive Datea), No.2 Pin RX(Receive Data), No.2 Pin TXD(Transmission Data), No.3 Pin... - Page 28 1) BYTE1 : fixed character (S) 2) BYTE2 : Channel character (CH1 : 1, CH2 : 2) 3) BYTE3 ~ BYTE6 : fixed character (, N T ,) 4) BYTE7 ~ BYTE14 : DATA 8 BYTE(including +/) 5) BYTE15 : CARRIAGE RETURN 6) BYTE16 : LINE FEED 8.
-
Page 29: Option 03 (Rs485)
Option-03 (RS485) Since RS485 Interface is very sensitive of electric noise. So please do the wiring from AC Power and electric wires separately. Also you must use the shield calbe always. 1. TYPE : RS485 2. Method : Half-duplex, asynchronous method. 3. - Page 30 9. Transmission DATA form (INDICATOR -> PC) CODE BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 ASCII CODE BYTE9 BYTE10 BYTE11 BYTE12 BYTE13 BYTE14 BYTE15 BYTE16 ASCII 1) BYTE1, BYTE2 : Fixed character (ID) 2) BYTE3 ~ BYTE5 : Device number (1 ~ 32) 3) BYTE6 : Fixed character (,) 4) BYTE7~BYTE14...
