Ver 4.0
MODEL : PDN-10
USER MANUAL
DACELL CO.,LTD.
Address : 681-1 Cheoksan-Ri, Nami-Myeon, Cheongweon-Gun,
Chung-buk
TEL :82-43-260-2242
FAX : 82-43-260-2245
http://www.dacell.com
E-Mail : info@dacell.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDN-10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dacell PDN-10

Summary of Contents for dacell PDN-10

  • Page 1 Ver 4.0 MODEL : PDN-10 USER MANUAL DACELL CO.,LTD. Address : 681-1 Cheoksan-Ri, Nami-Myeon, Cheongweon-Gun, Chung-buk TEL :82-43-260-2242 FAX : 82-43-260-2245 http://www.dacell.com E-Mail : info@dacell.com...

  • Page 2: Table Of Contents

    Contents 1. Features ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-1. Σ-∆ Conversion method (Sigma-Delta)⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-2. Calibration method ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-3. DATA BACK-UP & Watch-Dog function ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-4. Standard Built-in product ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 2. Cautions ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 2-1. Set-up Caution ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 2-2. Caution for use ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 3.

  • Page 3: Features

    1. Features We are grateful to you for picking up our product. If you experience problems while using it, you may refer to the user manual or contact the Technical Support Department of the company. This product is an indicator which amplifies micro voltage of various sensors and displays in digital form.

  • Page 4: Cautions

    2. Cautions For running this product’s functions correctly and safe use, please carefully read and understand the following details before you use this product. You must not use this product for any other purpose apart from the contents mentioned in this manual. Please do not attempt to try any altering on this product. 2-1.

  • Page 5: Specification

    3. Specifications. • Available sensor (DC) ① Micor Voltage Output Sensor (mV) ② Strain Gauge Type Sensor (Bridge 350Ω, 120Ω) • Maximum Display - 19999 ~ +19999 • Display Load Display : 4 1/2 Digits LCD Status Display LED : Red LED (3) Key Switch...

  • Page 6: Front Panel

    4. Front Panel 4-1. Display Window on Front Panel ① Load Display ②,③,④,StatusDisplay ⑤ Power Switch On/Off ⑥ Function Key/ZERO Key ⑦ Enter Key / HOLD Key ⑧ Shift Key / READ Key ⑨ Up Key / SAVE Key 4-2. 표시창의 기능 설명 ①...

  • Page 7: Connector Wiring Diagram

    4-3. Connector Wiring Diagram ① LOAD CELL (5 pin connector 16Ф) ② Communication (RS232C) (4 pin Connector 12Ф)

  • Page 8: Set Up

    5. SET UP 5-1. Types of Setting mode & Set-up Setting mode에는 Function mode, Digital calibration mode, Actual load calibration mode, SPAN constant calibration mode로 4가지가 있습니다. Mesuring mode While key is being Press, press Function mode ① Digital calibration ②...

  • Page 9: Function Mode (Function Set-Up)

    5-2. Function mode 1) How to set function. Measuring mode While key is being Press, press...
  • Page 10 # Function mode list # The standard Name Function Setting set-up value F-01 Decimal point 0, 1, 2, 3 F-02 Division 1, 2, 5, 10, 20, 50 F-03 Display filter 4, 8, 16, 32 F-04 Hold mode Sample hold, Peak hold, Absolute peak hold Peak hold F-09 ID Number 0 ~ 32...
  • Page 11 F-01. Decimal point (Decimal point Set-up) (Standard setup value: 1) Display data Setting 00000 0000.0 000.00 00.000 F-02. Division (Minimum display unit setup) (Standard setup value: 1) Display data Setting Displayed In 1 (0, 1, 2, 3, 4 …….) Displayed in 2 (0, 2, 4, 6, 8 …….) Displayed in 5 (0, 5, 10, 15 …….)
  • Page 12 F-09. ID Number (Communication Device Number setup) (Standard setup value: 00) Display data Setting : Device number is not set-up(Stream mode:always transmit data ) 01 ~32 : Device number is set-up(Command mode:Transmit data by command) F-10. Baud rate & Print (Communication Speed & Print Setup) (Standard setup value : 9.60) Display data Setting...

  • Page 13: Measuring Data Saving And Transmitting

    Measuring DATA Saving and Transmitting. 5.3. 1) DATA Saving It is used to save the measured DATA. The value displayed on LCD window will be saved. Please press KEY to display on the display window and then the address to be saved will be displayed as in Please press KEY to save DATA in the displayed address.

  • Page 14: Digital Calibration (Calibration By Sensor Output Value)

    5-4. Digital calibration (Calibration by sensor output value) At the time of purchasing sensor, the rated capacity (R.C) and rated output (R.O) declared on the calibration sheet can be used for the calibration for easier calibration. Measuring mode While key is being Press, press Display Function mode Display Sensor output value calibration mode...
  • Page 15 5-5. Actual load calibration This is a calibration method by adding actual load on the sensor. Standard weight is needed. Measuring mode While key is being Press, press Display Function mode Display Sensor output value calibration mode Display Actual load calibration mode Display R.O.
  • Page 16 5-6. SPAN constant claibration It is to calibrate with the S.CAL value written down for load calibration. You can calibrate without any standard weight. Measuring mode While key is being Press, press Display Function mode Display Sensor output value calibration Display Actual load calibration indicate Display Shunt cal value calibration mode Display R.O.

  • Page 17: Lock Set-Up

    5-7 Lock Set-up You can prevent any accidental operation due to the unnecessary key control by Lock set-up. After finishing calibration, it is recommended to set the Lock. At the first stage, please start while the power is OFF. Related Function when Lock is set : Function related to calibration Power off While key is being Press, and...

  • Page 18: Product Inspection

    6. Product Inspection Symptom Cause Action Remark Load cell is damaged. Load cell input, output. Insulation When Display Load cell insulation Check resistance resistance trembles. resistance. Check load cell’s (Cable & Case > 　 Indirect occurrence insulation resistance. 1000 Mohm) Check load cell’s Loadcell faulty insulation resistance.

  • Page 19: Rs232C

    7. RS232C Since RS232C Interface is very sensitive of electric noise. So please do the wiring from AC Power and electric wires separately. Also you must use the shield calbe always. Indicator Host PC TX(Transmission Data) RXD(Receive Datea), No.2 Pin RX(Receive Datea) TXD(Transmission Data), No.3 Pin GN(Ground)

  • Page 20: Command Mode

    8. Command mode Please set up the device No. referring to INDICATOR Manual. (Can setup from 1 to 32 channel.) 1. Command form (PC -> INDICATOR) CODE BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 ASCII 1) BYTE 1, BYTE2 : Fixed character (ID) 2) BYTE 3, BYTE4 : device n...

  • Page 21: Save Data Transfer (A001~A500)

    9. Save data (A001 ~A500) Transfer 6) BY 1. Command Form (PC -> INDICATOR) CODE BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 ASCII 1) BYTE 1, BYTE2 : Fixed Charactor (A) 2) BYTE 3, BYTE4 : Save Data (1 ~ 500) 3) BYTE : Command Order (P, D, U)) 2.
