Summary of Contents for dacell DN-10
- Page 1 Ver 4.0 MODEL : DN-10 DIGITAL INDICATOR User’s Manual DACELL CO.,LTD. Address : 681-1 Cheoksan -Ri ,Nami - Myeon , Cheongwon - Gun ,Chung-Buk,Korea TEL : 82-43-260-2242 FAX : 82-43-260-2245 http://www.dacell.com E-Mail : dana@danaloadcell.com...
-
Page 2: Table Of Contents
Contents 1. Features ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-1. Sigma-Delta Conversion System ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-2. Calibration System ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-3. Relay Output (Hi, Lo) ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-4. Data Back-up Function ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-5. Option (Analog OUT) ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 2 1-6. Power Supply ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅ 3 ⋅... -
Page 3: Features
1. Features We are grateful to you for picking up our product. If you experience problems while using it, you may refer to the user manual or contact the Technical Support Department of the company. This product is an indicator which amplifies the minute voltage signals of each sensor and converts themit into digital. -
Page 4: Power Supply
OP-03 : RS485 OP-04 : DAC Analog output 1-6. Power Supply Power of this product did 220V(50~60Hz) with standard, 110V speaks when ordering, 1.7. Standard built-in product 1. B 2. O perating instructions 3. I Terminal and Power Cable 4. T he panel the parts for a fixation 2. -
Page 5: Specifications
3. Specifications • Available sensor 1) Micro-voltage output sensor(mV) 2) Strain gage sensor(Bridge 350Ω, 120Ω). • Maximum display Max 32676 • A/D conversion 100 time/sec • Temperature characteristics (Amp characteristics) Zero : 1µV/℃ Span : 100ppm/℃ • Front panel Measured value display : 7 segment 5 LED, Character height 10mm State display LED : Red LED 2 pieces... -
Page 6: Front Panel
4. Front Panel ① HI, LO Indication ② Measured Value Indication ③ Function Key / ESC Key ④ Shift Key / ZERO Key / HOLD RESET key ⑤ Up Key / CAL Key ⑥ Enter Key / HOLD Key ① Hi, Lo indicator : Hi LED will be turned on when measured value is higher than or equal to the set Hi value... -
Page 7: Back Panel
5. Back panel Make sure the terminal site and its use, and wire separately from a lot of nosing wiring. Press protruded button on the top of terminal stand, and insert it into the hole on the lower part of it to the end. Then, pull it gently to make its certainty. - Page 8 ⓓ -OU : Analog Ground Output Terminal (-) , GND ⓔ +EXC : Sensor Supply Voltage + Co nnection Terminal ⓕ -EXC : Sensor Supply Voltage - Connection Terminal [Sensor Shield Connection Terminal (Be sur e to earth the sensor- attached part and this terminal.)] ⓖ...
-
Page 9: Setting Mode
6. Setting Mode 6-1. Setting Method If you push the key for about 3 seconds, will appear and then will come out. If you push the key at that time, the setting mode will change in the following direction, and if you push the key at that time, the setting mode will change in the opposite direction. -
Page 10: Setting Round Off
If the decimal point is changed after presetting, displaying value does not increase according to the decimal point. Press Function key and then Up key to become -> Press ENT key to choose decimal point setting. Press Shift key to choose the required number. Press ENT key to store the number. -
Page 11: Setting Baud Rate ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅10
Press ENT key to choose Hold setting. Press Up key to choose Peak Hold or Sample Hold setting. Press ENT key to store it. -> -> (In case it is not good, will come out.) If you want to get out of the setting mode and return to the measurement mode, you may have to push the Function key. -
Page 12: Setting Dac Zero Scope ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅11
If you want to get out of the setting mode and return to the measurement mode, you may have to push the Function key. (Currently the value is indicated.) 6-8. Setting DAC Zero Scope When using analog output, it sets Zero scope of output value. By Display setting Analog output control is possible. -
Page 13: Setting The Number Of Buffer ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅12
Press ENT key to store it. -> -> (In case it is not good, will come out.) If you want to get out of the setting mode and return to the measurement mode, you may have to push the Function key. (Currently the value is indicated.) ex) When DAC CAPA value sets at 500.0, analog output voltage will be 6-10. -
Page 14: Setting Auto Tracking Time ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅13
If you want to get out of the setting mode and return to the measurement mode, you may have to push the Function key. (Currently the value is indicated.) 6-12. Setting Auto Tracking Time As setting time to operate Auto zero, it set up 0.1~5.0 second. According to 6-1, Press Function key and then Up key to be ->... -
Page 15: Real-Weight Calibration ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅14
7. Calibration Before calibration, You should select Dip switch to the most near thing in sensor output value and make 7-1. Real-weight Calibration Standard weight is necessary. When being used Multiple sensor at one Indicator, It calibtrate certainly at Real-weight. 1) Real-weight Calibration Mode Setting Press Function key about 3 seconds to return to Setup mode. -
Page 16: Sensor Outout Value Calibration ⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅⋅15
If you want to get out of the setting mode and return to the measurement mode, you may have to push the Function key. ※ If, when is indicated or with Real-weight value different case, to repeat the above statement. 7-2. - Page 17 Press Up key to be Press ENT key, It uses Shift key and Up Key and it inputs Sensor output value. Press ENT key to store it. -> -> (In case it is not good, will come out.) If you want to get out of the setting mode and return to the measurement mode, you may have to push the Function key.
-
Page 18: Option 02 (Rs232C)
#Option-02 (RS232C) Make wire separately from power system wiring and noise wiring. Make sure the use of sealed cable as a sensor cable. Indicator Host PC TX(Transmitting Data) RXD(Receiving Data), Number 2 Pin RX(Receiving Data) TXD(Transmitting Data), Number 3 Pin GN(Ground) GND(Ground), 5 Pin 1. -
Page 19: Option 03 (Rs485)
#Option-03 (RS485) Make wire separately from power system wiring and noise wiring because is sensitive to electrical noise noise. Cable uses by Shield Cable certainly. 1. TYPE : RS485 2. Method : half duplex, asynchronous system 3. Baud-rate : Selection in 2400, 4800, 9600, 19200bps 4. - Page 20 9. Transmisssion DATA Form (INDICATOR -> PC) CODE BYTE1 BYTE2 BYTE3 BYTE4 BYTE5 BYTE6 BYTE7 BYTE8 ASCII CODE BYTE9 BYTE10 BYTE11 BYTE12 BYTE13 BYTE14 BYTE15 BYTE16 ASCII 1) BYTE 1, BYTE2 : fixed character (ID) 2) BYTE 3 ~ BYTE5 : equipment number (1 ~ 32) 3) BYTE...
- Page 21 # DN-10 Back panel < RS232C > No.1 No.2 No.3 < RS485 > No.1 No.2...
