Kremlin-Rexson AIRMIX 08-120 Disassembly/Reassembly

Kremlin-Rexson AIRMIX 08-120 Disassembly/Reassembly

Advertisement

TRANSLATION FROM THE ORIGINAL MANUAL
IMPORTANT : Before assembly and start-up, please read and clearly understand all the
documents relating to this equipment (professional use only).
THE PICTURES AND DRAWINGS ARE NON CONTRACTUAL. WE RESERVE THE RIGHT TO MAKE CHANGES WITHOUT
KREMLIN REXSON
KREMLIN - REXSON
150, avenue de Stalingrad
93 245 - STAINS CEDEX - France
: 33 (0)1 49 40 25 25
www.kremlin-rexson.com
AIRMIX    PUMPS
08-120 / 08-120 T
16-120 / 16-120 T
Disassembly / Reassembly
PRIOR NOTICE.
l
Fax : 33 (0)1 48 26 07 16
N° : 578.166.110-UK-1411

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRMIX 08-120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kremlin-Rexson AIRMIX 08-120

  • Page 1 THE PICTURES AND DRAWINGS ARE NON CONTRACTUAL. WE RESERVE THE RIGHT TO MAKE CHANGES WITHOUT PRIOR NOTICE. KREMLIN - REXSON 150, avenue de Stalingrad 93 245 - STAINS CEDEX - France : 33 (0)1 49 40 25 25 Fax : 33 (0)1 48 26 07 16 www.kremlin-rexson.com KREMLIN REXSON N° : 578.166.110-UK-1411...
  • Page 2 CAUTION : Before any action on the pump, shut off the compressed air supply and depressurize the system. The pump is manufactured under the ATEX agreement and can not be modified. KREMLIN REXSON will not be held responsible for any failure to comply with that instruction. Guards (air motor cover, coupling shields, housings …) have been designed for safe use of the equipment.
  • Page 3 UPPER PACKING Separate motor piston rod from hydraulic piston (3). Unscrew wetting-cup (4) by means of the wrench 3 à 8 mm supplied with the pump. Remove cylinder (2) and pull piston (3) downwards to remove upper packing seals (10 and 11). Reinstall parts in reverse order.
  • Page 4 ASSEMBLY INSTRUCTIONS Index Instruction Description Part number PTFE grease 'TECHNILUB' grease (10 ml) 560.440.101 Anti-seize grease Grease box (450 g / 0.99 lb) 560.420.005 Medium strength Loctite 577 554.180.015 Aneorobic Pipe sealant KREMLIN REXSON - 3 - N° : 578.166.110-UK-1411...

This manual is also suitable for:

Airmix 08-120 tAirmix 16-120Airmix 16-120 t

Table of Contents
