Kremlin-Rexson AIRMIX Instruction Manual

Pump and low-pressure pump air motor with reversing block
Hide thumbs Also See for AIRMIX:
Table of Contents

Advertisement

Quick Links

INSTRUCTION MANUAL
AIRMIX  PUMP and LOW-PRESSURE PUMP
air motor with reversing block
Manual : 0306 573.002.212
Date : 12/06/03 – Supersedes : 17/06/02
Modif. § 1 + § 4 added
KREMLIN REXSON – Site de Stains : 150, avenue de Stalingrad
93 245 - STAINS CEDEX - FRANCE
Téléphone : 33 (0)1 49 40 25 25
Fax : 33 (0)1 48 26 07 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIRMIX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kremlin-Rexson AIRMIX

Summary of Contents for Kremlin-Rexson AIRMIX

  • Page 1 Date : 12/06/03 – Supersedes : 17/06/02 Modif. § 1 + § 4 added KREMLIN REXSON – Site de Stains : 150, avenue de Stalingrad 93 245 - STAINS CEDEX - FRANCE Téléphone : 33 (0)1 49 40 25 25...

  • Page 2: Table Of Contents

    INSTRUCTION MANUAL AIRMIX  PUMP and LOW-PRESSURE PUMP air motor with reversing block SUMMARY EC DECLARATION OF CONFORMITY...................... 2 GENERAL SAFETY INSTRUCTIONS ......................2 OPERATING PRINCIPLE..........................3 INSTALLATION ............................4 START UP..............................5 SHUTDOWN AT THE END OF THE WORK....................7 MAINTENANCE............................

  • Page 3: Ec Declaration Of Conformity

    1. EC DECLARATION OF CONFORMITY The manufacturer : KREMLIN REXSON with assets of 6 720 000 euros Head office : 150, avenue de Stalingrad – 93 245 - STAINS CEDEX - FRANCE Tel. 33 (0)1 49 40 25 25 - Fax : 33 (0)1 48 26 07 16...

  • Page 4: Operating Principle

    EQUIPMENT REQUIREMENTS The operating pressure of these equipments are particularly high. Consequently, some precautions must be taken in order to prevent from accidents and from unsafe working conditions. Never exceed the components maximum working pressure of the equipment. HOSES Do not use hoses with a maximum burst-proof pressure less than four times the maximum service pressure of the pump (see data sheet).

  • Page 5: Installation

    P prod : xx bar / xx psi Air supply maximum pressure of the pump motor. P air : 6 bar / 87 psi Serie / Serial Number given by KREMLIN REXSON INSTALLATION INSTRUCTIONS Explosive area Area 1 (Z1) or area 2 (Z2) :...

  • Page 6: Start Up

    6 (filtration size : 168 microns or 85 mesh). The screen is recommended for the use of an AIRMIX gun fitted with a nozzle model n° 6. If the fluid spraying is carried out by means of an other nozzle, choose an other screen (refer to the filter instruction manual).
  • Page 7 Remove the nozzle from the spray gun. FLUSHING WITH SOLVENT Immerse suction rod (L) and the drain rod (O) into the material container. Open the air shut off valve (N). Open the valve (H) of the pump air equipment to supply the air motor. Nota : If the pump air motor is a 5000 version, it needs pilot air to operate.

  • Page 8: Shutdown At The End Of The Work

    Trigger the spray gun to depressurize the system. Unscrew the spray gun air regulator (F) or disconnect the spray gun air inlet. Remove the aircap from the spray gun, (aicap and nozzle for Airmix ® spray gun) and soak it into solvent.

  • Page 9: Safety Device

    FILTER If the pump is mounted with a filter at the fluid outlet, comply with the usual instructions of filter servicing (refer to filter instruction manual). 8. SAFETY DEVICE A relief-valve (setting : 6,5 bar / 94 psi) is fitted on the pump air motor - thus protecting this one from an overpressure which could damage it.
