Page 1 Owner’s Manual Sage Cinema Series Line 4 Quad-amplified Coaxial Planar Magnetic Loudspeaker...
Page 2: Table Of Contents
| 16 DOCUMENT CONVENTIONS This document contains general safety, installation, and operation instructions for the Wisdom Audio Sage Cinema Series Line 4 Loudspeaker. It is important to read this document before attempting to use this product. Pay particular attention to: WARNING: Calls attention to a procedure, practice, condition or the like that, if not correctly performed or adhered to, could result in injury or death.
Page 3: Introduction
We recognize that setting up a Wisdom Audio system can be a bit more involved than connecting a common set of loudspeakers, which is why we recommend that our systems be engineered and calibrated by Factory Personnel.
Page 4 inertia than traditional “cone & dome” drivers, so the signal is never blurred in any way. One of the most remarkable things about the sound of well-designed planar magnetic speakers is their lack of thermal or dynamic compression. There are several reasons for this: •...
Page 5 It simply makes more sense to use the best transducer technology in each area of the reproduced spectrum. One of Wisdom Audio’s strengths is in seamlessly blending these technologies — particularly important given the high standards set by our planar magnetic drivers.
Page 6 Instead, it creates a series of point sources, which end up interfering with each other). With Wisdom Audio’s planar magnetic technology, it becomes possible to have drivers that are extremely tall and slim.
Page 7: Unpacking And Installing The Line
Unpacking & Installing the Line 4 Each module of the Wisdom Audio Sage Cinema Line 4 speaker is a substantial piece of equipment. Please exercise caution when unpacking your Sage Cinema speakers to ensure that you do not strain yourself from its (perhaps unexpected) weight.
Page 8 Proper Planar Placement for front L&R and Rear Surrounds When using the Line 4 for front L&R and or Rear Surrounds the planar drivers should always be placed on the inside (shown below) in a front screen wall LCR example. The Importance of a Baffle Wall Whether used as an in-wall or as an on-wall speaker, the Line 4 is optimized for use on a solidly constructed surface.
Page 9 Hence, some suggestions: 1. Using the supplied “ears”, screw the speakers to the surrounding framing rather than to the wall surface (sheet rock, plywood, whatever). The simplest way to do this is to frame in around the speaker locations so there is only an inch or two of space between the speakers and the surrounding studs.
Page 10 Wisdom Audio SA Series amplifiers, and the high-pass section going to additional SA Series amplifiers, which will drive the planar magnetic panels. Connect the outputs of your Wisdom Audio SA Series amplifier to the first woofer section (either top or bottom), taking care to get both the channel assignments and SAGE CINEMA SERIES LINE 4 WISDOMAUDIO.COM...
Page 11: Care And Maintenance
Repeat this process for the High Pass section of the first Line module. The subsequent, multiple Line modules are wired in parallel, using jumpers (not supplied by Wisdom) to connect the top set of connections of one module to the bottom set of connections on the next.
Page 12: North American Warranty
Standard Warranty When purchased from and installed by an authorized Wisdom Audio dealer, Wisdom Audio loudspeakers are warranted to be free from defects in material and workmanship under normal use for a period of 10 years from the original date of purchase.
Page 13: Obtaining Service
If your Wisdom Audio loudspeaker must be serviced, please contact your dealer. Your dealer will then decide whether the problem can be remedied locally, or whether to contact Wisdom Audio for further service information or parts, or to obtain a Return Authorization. The Wisdom Audio Service Department works closely with your dealer to solve your service needs expediently.
Page 14: Specifications
If the packaging to protect the unit is, in our opinion or that of our dealer, inadequate to protect the unit, we reserve the right to repackage it for return shipment at the owner’s expense. Neither Wisdom Audio nor your dealer can be responsible for shipping damage due to improper (that is, non-original) packaging.
Page 15: Dimensions
Line 4 Dimensions SAGE CINEMA SERIES LINE 4 WISDOMAUDIO.COM...
Page 16 WISDOM and the stylized W are registered trademarks of Wisdom Audio. Wisdom Audio 1572 College Parkway, Suite 164 Carson City, Nevada 89706 USA (775) 887-8850 (775) 887-8820 wisdomaudio.com Line 4 OM-3.0 © 11/2021 Wisdom Audio, Inc. All rights reserved. Printed in U.S.A.
