Withings ScanWatch Reviewer's Manual

Hide thumbs Also See for ScanWatch:

Advertisement

Quick Links

Download this manual
Reviewer's guide
ScanWatch

Advertisement

loading
Need help?

Need help?

Do you have a question about the ScanWatch and is the answer not in the manual?

Questions and answers

Robert Traer
February 4, 2025

My watch has transferred ECG scans to my cell phone. How do I email these scans from my phone.

0
1 comments:
Mr. Anderson
February 10, 2025

You can share ECG scans from your Withings ScanWatch to your phone using the Health Mate app. Once your ECG results appear in the app, tap “Share PDF” to generate a PDF document. You can then email this document to your phone or directly to your doctor or health provider.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Withings ScanWatch

Summary of Contents for Withings ScanWatch

  • Page 1 Reviewer's guide ScanWatch...
  • Page 2 ScanWatch Hybrid Smartwatch with ECG, Heart Rate & Oximeter C LI NI CALLY VA LIDAT ED...
  • Page 3 • Proactive atrial fibrillation, low and high heart rate notifications • Medical-grade electrocardiogram on your wrist in 30 seconds • Medical-grade oxygen saturation level (SpO2) • Breathing disturbances detection • Rechargeable battery: up to 30 days • Sleep Score, light & deep sleep stages, plus silent alarm & Smart Wake-Up •...

  • Page 5: Table Of Contents

    Table of contents Product overview Get started Heartbeat notifications: 24/7 heart scanning. Invaluable peace of mind. An electrocardiogram anytime, anywhere Medical-grade wrist-based oximetry Respiratory Scan, the most advanced sleep analysis available on a smartwatch In-depth sleep analysis Activity tracking...

  • Page 6: Product Overview

    1. Product overview ScanWatch features a combined heart rate and SpO2 sensor, 3 electrodes, an altimeter and PMOLED screen—all within a stainless steel case protected by sapphire glass. When combined with our proprietary algorithms, the watch is able to provide highly valuable, accurate information that can be shared with doctors.
  • Page 7 By placing a hand on the watch, the user creates a closed electrical circuit with their arms and chest, allowing the measurement of a one-lead ECG.

  • Page 8: Get Started

    2. Get started GET STARTED You now have ScanWatch, the most advanced health wearable ever designed. It is the first-ever hybrid smartwatch to notify users that they are at risk for highly prevalent yet underdiagnosed conditions, including breathing disturbances and atrial fibrillation. Nested in a...
  • Page 9 INSTALLATION ScanWatch connects to the Health Mate application, available for iOS and Android. The application allows you to manage key aspects of your health through detailed information, including your electrocardiogram, your oxygen saturation levels, breathing disturbances episodes, sleep stages, number of steps, sleep, floors climbed, a timeline of all activities, and personalized advice based on your vital parameters.
  • Page 10 Set up your ScanWatch by following the instructions in the app: Device > ScanWatch > Install The Bluetooth on your phone needs to be enabled so it can detect the device. Once connected to Bluetooth, ScanWatch will be able to automatically synchronize your data.
  • Page 11 SCANWATCH AT A GLANCE By pressing the digital crown, you can scroll through data (date, heart rate, steps, distance, calories burned, elevation), launch measurements (oxygen saturation levels, electrocardiogram, workout mode), receive notifications of high, low, or irregular heartbeat, get smartphone notifications, access the alarm, timer &...

  • Page 12: Heartbeat Notifications: 24/7 Heart Scanning

    3. Heartbeat notifications: 24/7 heart scanning. Invaluable peace of mind. Check heart rate and receive heartbeat notifications when heart rate is atypical (low or high) and if signs of atrial fibrillation are detected. The embedded PPG sensor and our exclusive algorithm analyze your heart without disrupting your life.
  • Page 13 You can receive 3 types of notifications: • LOW HEART RATE • HIGH HEART RATE • ATRIAL FIBRILLATION Heartbeat notifications will be displayed on ScanWatch and your smartphone, and you can see a full history of notifications in the Health Mate app.

  • Page 14: An Electrocardiogram Anytime, Anywhere

    4. An electrocardiogram anytime, anywhere WHEN SHOULD YOU TAKE A MEASUREMENT? You should take a measurement after receiving a heartbeat notification or if you feel palpitations or an irregular heart rhythm (for example, a rapid or skipped heartbeat). HOW TO TAKE AN ECG To record an ECG, sit and rest, press the digital crown to wake up the watch, scroll in the menu to find the ECG option, press again, then place your fingers on the front electrode for 30 seconds.
  • Page 15 RESULTS IN THE HEALTH MATE APP The electrocardiogram provides 2 types of insights: - Atrial fibrillation detection, one of the most common arrhythmias, based on the analysis of sinus rhythm (how the heart beats) - An indication of your heart rate state telling you if it seems low or high, which can be associated with bradycardia and tachycardia NORMAL SINUS RHYTHM: A sinus ATRIAL FIBRILLATION:...
  • Page 16 HIGH OR LOW HEART RATE: Know if INCONCLUSIVE: An inconclusive result your heart beat is too fast or too slow means the recording can’t be classified. with clear results. This can happen for many reasons, such as not resting your arms on a table during a recording, contracting arm or hand muscles during measurement, or if your ECG device is too loose around...
  • Page 17 SpO2 option, press again, then place your fingers on the front electrode for 30 seconds. Once the measurement is done, ScanWatch will vibrate and the results will be displayed on the PMOLED screen. More information is available in the Health Mate app after the watch synchronizes.
  • Page 18 RESULTS IN THE HEALTH MATE APP Get oxygen saturation percentage, history and an indication on where it stands: - 100% > X >94%: normal - 94% > X > 90%: below average. This could be due to many factors. More info is given in the app to help the user determine the action to take.

  • Page 19: Respiratory Scan, The Most Advanced Sleep Analysis Available On A Smartwatch

    A Respiratory Scan will measure your heart rate, heart rate variability, respiratory rate and oxygen saturation level throughout the night. From those metrics, ScanWatch is also able to provide the amount of breathing disturbances that were experienced during the previous night.

  • Page 20: In-Depth Sleep Analysis

    ScanWatch provides insights into your sleep patterns. ScanWatch automatically analyzes your sleep, as well as the different parameters that can affect the quality and quantity of your sleep.
  • Page 21 Smart Wake-Up is an added feature that can wake you up at the best time in your sleep cycle. Simply set a window before your usual wake-up time, and ScanWatch will wake you up with a silent vibration during that interval, when your sleep is lightest.

  • Page 22: Activity Tracking

    If you participate in any sport that isn’t walking, running or swimming, the app will ask you to confirm your sport so you can assign it manually. ScanWatch then learns to automatically detect these activities based on your movements.
  • Page 23 WORKOUT MODE Whether you’re into yoga, playing volleyball, boxing, skiing, or playing ice hockey, ScanWatch can track more than 30 activities. Press the digital crown, scroll in the menu to find the Workout option, press again, then scroll through to find your activity and short press again to select.
  • Page 24 Bluetooth. You must also enable the location settings on your smartphone. ALTIMETER ScanWatch has an embedded altimeter to track floors climbed and motivate you to better health. In the Health Mate app, you’ll find the number of floors you have climbed.
  • Page 26 SETTINGS With ScanWatch, you can directly adjust some settings right on your watch at any time. Press the digital crown and access the Settings mode, then short press. In this menu, you'll be able to see the remaining battery life level, set Smart Notifications on/off, and manage quicklook.
  • Page 27 You can easily customize the wristband of your ScanWatch thanks to the quick-release spring bars with which it is attached. The ScanWatch comes with a premium FKM watch band, but you can also accessorize with a wide selection of colorful silicone and premium leather bands that are available on our webstore.
  • Page 28 Still have questions? jf@licencek.com...
