WNC1800 Wireless Network Coordinator Gateway Installation
Instructions
MS-WNC1800-x
Applications
The WNC1800 Wireless Network Coordinator (WNC) Gateway, equipped with a ZFR1820 or ZFR1823 Pro Coordinator
Radio, provides an IP interface to wireless enabled field controllers (WEFCs) equipped with a ZFR1821 or ZFR1822
Pro Wireless Router, or TEC3000 wireless thermostats, and a supervisory controller in a Metasys® building automation
system. The WNC Gateway routes messages between the Ethernet network and the WNC1800/ZFR182x Pro
Wireless Field Bus (ZFR Pro) network.
The WNC Gateway also allows you to use smartphones, tablets, or laptop computers to interact with building
automation equipment controllers on a ZFR Pro network. The WNC Gateway serves up web pages through a built-in
Wi-Fi access point or Ethernet connection, which allows you to view and edit equipment controller configuration
parameters, setpoints, schedules, and alarms through a browser. A mobile application is not required to use the
WNC Gateway with your mobile device.
You can use the WNC Gateway in both Metasys® systems and Facility Explorer systems. The WNC Gateway
supports the TEC3000 Series Wireless controller and any Johnson Controls® Wireless Enabled Field Controller
(WEFC).
The Wi-Fi wireless connection on the WNC Gateway allows users of a supported mobile device to be up to 30 m
(100 ft, line of sight) away indoors if there are no obstacles. A typical indoor range in an area with obstacles is 15
m (50 ft). Power is supplied through a supplied external power supply.
You can mount the WNC Gateway directly to a wall or DIN rail using the supplied WNC Gateway mounting bracket.
North American Emissions Compliance
United States
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
this equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area may cause harmful
interference, in which case the users will be required to correct the interference at their own expense.
RF Transmitters: Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
RF Exposure (OET Bulletin 65)
To comply with FCC RF exposure requirements for mobile transmitting devices, this transmitter should only be
used or installed at locations where there is at least 20 cm separation distance between the antenna and all persons.
WNC1800 Wireless Network Coordinator Gateway Installation Instructions
(barcode for factory use only)
Part No. 24-10737-91, Rev A
Issued January 2017
