Operating Instructions Web512 V2.6.x for Web-server II 1598

General description

The Web-server II (1598) can be used with one, two, three or four of
the following functions:
1. As a web-server when one EBL512 control unit or an EBL512
system with two or more control units shall be connected to
Internet / an intranet (LAN), for presentation of EBL512
status in a PC using the web browser Microsoft Internet
Explorer. See page 9.
2. As a web-server for remote control of EBL512 via encrypted
and safe two-way communication (HTTPS). See page 9.
3. As an e-mail client to send e-mails in case of special events
(e.g. fire alarm, fault, etc.), see page 46.
4. As a Gateway to a separate system, i.e. to transmit and present
fire alarm information in another (PC) system. See chapter
"Gateway", page 51.
NOTE! Pos. 2 and pos. 3
together with pos. 1.
The Web-server II has to be configured and the Web-server II
software has to be downloaded via the Config Tool Web512 II
Config Tool V2.6.x. See also chapter "Introduction", page 5.
NOTE! Remote control is only valid for system EBL512 software
version > 2.5.
Figure 1. A PC is connected to an EBL512 system via internet /
an intranet (LAN) and the Web-server II, 1598.
(above) cannot be used separately, only
