PROFINET: Changeover from ASi gateways type K20 to KE5

Transfer Configuration

3 Transfer Configuration
Store ASi configuration on KE5 gateway
1.
Connect the VBG-EP1-KE5-D*, see chapter 2.
2.
Press and hold the pushbutton for 5 seconds.
The ASi 1 LEDs flash yellow.
The configuration of the ASi network 1 can be saved.
3.
Press and hold the pushbutton for 5 seconds.
The Memory LED flashes green
The configuration of ASi network 1 is stored.
4.
Press the pushbutton briefly.
The ASi 2 LEDs flash yellow.
The configuration of the ASi network 2 can be saved.
5.
Press and hold the pushbutton for 5 seconds.
The Memory LED flashes green
The configuration of ASi network 2 is stored.
10
Note
Switching between ASi network 1 and 2 at VBG-EP1-KE5-DMD
Note
The device reboots automatically after saving the configuration.
