b. Connection
With:
Cable connection
Infra-red connection
Web connection
* Wall plug RJ-45

4. Transport

1. Clear the session then, unplug the instrument.
2. Remove the support rod and near-vision card from the refraction head.
3. Put the forehead rest as close to the refraction head side as possible.
4. Place the arm in the same orientation as the refraction head.
5. Loosen the M5 screw (safety screw) then the M6 screw (attachment screw).

5. Identification and locating of the elements

a. Complete unit
The main components that make up the Vision-R
A refraction head
A console
A power supply box
11
TM
700 unit are:
