Icom IC-F24/S Service Manual Addendum page 75

[MAIN-B UNIT] (For IC-F26-L)
REF PARTS
NO. NO.
C333 4030017420 S.CER ECJ0EC1H470J
C335 4030018860 S.CER ECJ0EB0J105K
C339 4030016930 S.CER ECJ0EB1A104K
C340 4030016930 S.CER ECJ0EB1A104K
C341 4030016930 S.CER ECJ0EB1A104K
C342 4030017630 S.CER ECJ0EC1H120J
C343 4030017580 S.CER ECJ0EC1H060C
C344 4030017640 S.CER ECJ0EC1H150J
C345 4030016930 S.CER ECJ0EB1A104K
C346 4030016930 S.CER ECJ0EB1A104K
C347 4030016790 S.CER ECJ0EB1C103K
C348 4030016930 S.CER ECJ0EB1A104K
C349 4030016930 S.CER ECJ0EB1A104K
C350 4030017460 S.CER ECJ0EB1E102K
C354 4030017460 S.CER ECJ0EB1E102K
C355 4030018080 S.CER ECJ0EB1H182K
C356 4030018910 S.CER C1608 JB 0J 475K-T
J1 6510021901 S.CNR BM02B-ASRS-TF (LF) (SN)
J2 6450001680 CNR HSJ1122-010010
J3 6450002250 CNR HSJ1456-010320
J4 6510018430 S.CNR AXN330C038P
F1 5210000830 S.FUS ERBFE3R00U
DS1 5040002670 S.LED CL-165HR/YG
MC1 7700002750 MIC EM9745P-38-G <HOR>
S1 2260002840 SW SKHLLFA010
S2 2260002800 S.SW SW-167 (SKQTLAE010)
S3 2260002800 S.SW SW-167 (SKQTLAE010)
S4 2250000490 ECR TP70TF5163-15.9F-2775
EP1 6910015370 S.BEA ACZ1005Y-102-T
EP3 6910015370 S.BEA ACZ1005Y-102-T
[ANT UNIT]
REF PARTS
NO. NO.
L601 6200008240 S.COL 0.30-0.9-5TL 14N
C601 4030017600 S.CER ECJ0EC1H080C
[CONNECT UNIT]
REF PARTS
NO. NO.
C501 4030017460 S.CER ECJ0EB1E102K
C502 4030016930 S.CER ECJ0EB1A104K
J501 6910016390 CNR IMSA-9230B-1-02Z145-PT1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
