Icom IC-F24/S Service Manual Addendum page 69

[MAIN UNIT] (For other than F26-L)
REF PARTS
DESCRIPTION
NO. NO.
R55 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R56 7030003860 S.RES ERJ3GE JPW V
R57 7030004970 S.RES ERJ2GEJ 470 X (47)
R58 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R59 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R61 7030004970 S.RES ERJ2GEJ 470 X (47)
R62 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R65 7030004980 S.RES ERJ2GEJ 101 X (100)
R66 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R67 7030004980 S.RES ERJ2GEJ 101 X (100)
R68 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R69 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R70 7030005530 S.RES ERJ2GEJ 100 X (10)
R71 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R73 7030004980 S.RES ERJ2GEJ 101 X (100)
R75 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R76 7030004980 S.RES ERJ2GEJ 101 X (100)
R77 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R78 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R79 7030006020 S.RES RR0510P-682-D (6.8 k)
R80 7030005120 S.RES ERJ2GEJ 102 X (1 k) [High band]
7030008370 S.RES ERJ2GEJ 561 X (560) [Low band]
R82 7030009320 S.RES ERJ2GEJ 4R7 X (4.7)
R83 7030006020 S.RES RR0510P-682-D (6.8 k)
R84 7030006020 S.RES RR0510P-682-D (6.8 k)
R85 7030006020 S.RES RR0510P-682-D (6.8 k)
R86 7030005530 S.RES ERJ2GEJ 100 X (10)
R87 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R88 7030005010 S.RES ERJ2GEJ 681 X (680) [High band] B
7030008370 S.RES ERJ2GEJ 561 X (560) [Low band]
R89 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R90 7030005170 S.RES ERJ2GEJ 474 X (470 k)
R92 7030005310 S.RES ERJ2GEJ 124 X (120 k)
R93 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R94 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R95 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R96 7030008410 S.RES ERJ2GEJ 392 X (3.9 k)
7030009140 S.RES ERJ2GEJ 272 X (2.7 k)
R97 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R98 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R100 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R101 7030005000 S.RES ERJ2GEJ 471 X (470)
R103 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R104 7030005230 S.RES ERJ2GEJ 334 X (330 k)
R105 7030005170 S.RES ERJ2GEJ 474 X (470 k)
R106 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R107 7030005580 S.RES ERJ2GEJ 560 X (56)
R108 7030005600 S.RES ERJ2GEJ 273 X (27 k) [Low band] T
7030008290 S.RES ERJ2GEJ 183 X (18 k) [High band] T
R109 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R110 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R111 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R113 7030006610 S.RES ERJ2GEJ 394 X (390 k)
R114 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R115 7030007570 S.RES ERJ2GEJ 122 X (1.2 k)
R116 7030007060 S.RES ERJ2GEJ 684X (680 k)
R117 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R118 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R123 7030008400 S.RES ERJ2GEJ 182 X (1.8 k)
R124 7030005170 S.RES ERJ2GEJ 474 X (470 k)
R125 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R131 7510001730 S.TMR ERTJOEP 473J
R132 7030010080 S.RES ERJ2RHD 104 X (100 k)
R133 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R134 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R135 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R136 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R137 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R138 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R141 7030005000 S.RES ERJ2GEJ 471 X (470)
R142 7030005000 S.RES ERJ2GEJ 471 X (470)
R143 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R144 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R145 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R146 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R147 7030007350 S.RES ERJ2GEJ 393 X (39 k)
R148 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R149 7030006610 S.RES ERJ2GEJ 394 X (390 k)
R150 7030008300 S.RES ERJ2GEJ 184 X (180 k)
R151 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
R152 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R153 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R154 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R155 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R156 7030005170 S.RES ERJ2GEJ 474 X (470 k)
R157 7030007290 S.RES ERJ2GEJ 222 X (2.2 k)
R159 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R160 7030004980 S.RES ERJ2GEJ 101 X (100)
R161 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R162 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R163 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R164 7030008410 S.RES ERJ2GEJ 392 X (3.9 k)
R165 7030008410 S.RES ERJ2GEJ 392 X (3.9 k)
R166 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R167 7030009290 S.RES ERJ2GEJ 562 X (5.6 k)
R168 7030005000 S.RES ERJ2GEJ 471 X (470)
R169 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R170 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R171 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R172 7030005700 S.RES ERJ2GEJ 274 X (270 k)
R173 7030005310 S.RES ERJ2GEJ 124 X (120 k)
H/V
M.
LOCATION
T 80/20.9
T 78/22.4
T 75.2/23.2
[High band] only T 72.1/24
T 71.2/24
T 71.8/36.3
T 72.1/35
T 69.4/34.2
T 67.8/34.2
T 67.8/35.1
T 69.4/35.1
T 64.1/35.2
B 57.6/40.3
T 58.2/38.6
B 57.7/30.5
B 58.4/36.1
B 57.6/39.3
B 56.7/30.5
T 57.8/33.3
T 56.5/39.1
B 54.6/32.8
B 54.6/32.8
T 52.6/32
T 54.1/32.6
T 52.1/28.6
T 54.7/39.1
B 48.2/28.8
B 48.1/25.3
54.6/31
B 54.6/31
B 49.3/41.2
B 46.9/25.1
B 46.9/26.1
T 39.8/39.4
T 41.8/40.8
B 49.9/36.4
[Low band] B 49.3/40.1
[High band] B 49.3/40.1
B 49.3/38.1
T 53.5/44.1
B 52.9/38.8
B 51.4/43.3
T 33.1/27.8
T 31.5/26.9
T 32.6/29.1
T 37.5/32
B 55.9/43.3
44.9/21
44.9/21
T 43.9/21
B 21.8/34.3
T 27.1/28.7
B 46.9/31.1
B 46.9/29.1
T 40.5/32
T 43.4/32.7
T 35.3/40.1
T 37.2/40.1
T 75.2/37.7
T 72.7/40.4
T 73.2/38.9
T 40.9/28.1
T 40.9/27.1
T 84.1/14.2
T 74/14.3
T 24.5/24
T 22.8/24
T 69.8/14.7
T 69.8/16.7
T 37/9.9
T 43/9.9
T 37.2/24.4
B 46.5/13.7
T 33.4/18.1
T 31.6/18.1
T 33.4/16.1
T 31.6/16.1
T 33.4/12.9
T 33.4/11.9
T 33.4/13.9
T 31.1/29.6
T 29.9/29.1
T 28.2/30.1
T 29.8/41.1
T 29.8/40.1
T 31.5/39.1
T 15.7/28.8
B 5.5/31
T 12.9/27.3
T 8.7/29.1
T 14.1/29.8
T 15.7/27.8
T 12.6/31.9
T 12.6/36.1
T 15.7/29.8
T 16.3/40.1
T 18/41.1
T 12.9/29.3
T 11.6/36.1
T 18/39.1
T 19.4/26.8
6 - 2
[MAIN UNIT] (For other than F26-L)
REF PARTS
NO. NO.
R174 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R175 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R176 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R177 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R178 7030005710 S.RES ERJ2GEJ 121 X (120)
R179 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R180 7030005160 S.RES ERJ2GEJ 105 X (1 M)
R181 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R182 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R183 7030006020 S.RES RR0510P-682-D (6.8 k)
R184 7030008250 S.RES RR0510P-562-D (5.6 k)
R185 7030005310 S.RES ERJ2GEJ 124 X (120 k)
R186 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R187 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R190 7030007280 S.RES ERJ2GEJ 331 X (330)
R191 7030008300 S.RES ERJ2GEJ 184 X (180 k)
R192 7030005720 S.RES ERJ2GEJ 563 X (56 k)
R193 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R194 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R195 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R196 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R197 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R198 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R200 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R201 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R206 7030005110 S.RES ERJ2GEJ 224 X (220 k)
R207 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R208 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R209 7030005220 S.RES ERJ2GEJ 223 X (22 k)
R210 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R211 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R212 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R213 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R214 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R215 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R220 7030004980 S.RES ERJ2GEJ 101 X (100)
R221 7030005000 S.RES ERJ2GEJ 471 X (470)
R222 7030005080 S.RES ERJ2GEJ 823 X (82 k)
R223 7030005060 S.RES ERJ2GEJ 333 X (33 k)
R224 7030005000 S.RES ERJ2GEJ 471 X (470)
R225 7030004980 S.RES ERJ2GEJ 101 X (100)
R226 7210003061 VAR TP76N00N-15F-A103-2251A
R227 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R228 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R229 7030005530 S.RES ERJ2GEJ 100 X (10)
R230 7030005530 S.RES ERJ2GEJ 100 X (10)
R231 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R232 7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
R233 7030007300 S.RES ERJ2GEJ 332 X (3.3 k)
R234 7030005100 S.RES ERJ2GEJ 154 X (150 k)
R235 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R236 7030005230 S.RES ERJ2GEJ 334 X (330 k)
R237 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R238 7410001140 S.ARY EXB28V104JX
R240 7030005590 S.RES ERJ2GEJ 680 X (68)
R241 7030010040 S.RES ERJ2GEJ-JPW
R242 7030010040 S.RES ERJ2GEJ-JPW
R251 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R252 7030005530 S.RES ERJ2GEJ 100 X (10)
R254 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R255 7030008010 S.RES ERJ2GEJ 123 X (12 k)
R256 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R257 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R258 7410001140 S.ARY EXB28V104JX
R259 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R260 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R261 7410001130 S.ARY EXB28V102JX
R262 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R263 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R264 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R265 7410001130 S.ARY EXB28V102JX
R266 7030007340 S.RES ERJ2GEJ 153 X (15 k)
R271 7030005160 S.RES ERJ2GEJ 105 X (1 M)
R272 7030005160 S.RES ERJ2GEJ 105 X (1 M)
R273 7030005160 S.RES ERJ2GEJ 105 X (1 M)
R274 7030005070 S.RES ERJ2GEJ 683 X (68 k)
R275 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R276 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R277 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R278 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R280 7030005050 S.RES ERJ2GEJ 103 X (10 k)
R284 7030004980 S.RES ERJ2GEJ 101 X (100)
R287 7030007280 S.RES ERJ2GEJ 331 X (330)
R288 7030005030 S.RES ERJ2GEJ 152 X (1.5 k)
R291 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R292 7030005090 S.RES ERJ2GEJ 104 X (100 k)
R293 7030008290 S.RES ERJ2GEJ 183 X (18 k)
R294 7030005600 S.RES ERJ2GEJ 273 X (27 k)
R295 7030005240 S.RES ERJ2GEJ 473 X (47 k)
R296 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k)
R297 7030005120 S.RES ERJ2GEJ 102 X (1 k)
R301 7030010040 S.RES ERJ2GEJ-JPW
R302 7030004990 S.RES ERJ2GEJ 221 X (220)
R303 7030005040 S.RES ERJ2GEJ 472 X (4.7 k)
R304 7030005090 S.RES ERJ2GEJ 104 X (100 k)
C1 4030017590 S.CER ECJ0EC1H070C
4030017600 S.CER ECJ0EC1H080C
C2 4030017350 S.CER ECJ0EC1H020B
4030017550 S.CER ECJ0EC1H1R5B
C3 4030017590 S.CER ECJ0EC1H070C
4030017600 S.CER ECJ0EC1H080C
C4 4030017560 S.CER ECJ0EC1H2R5B
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
T 19.4/28.8
T 19.4/27.8
T 17.7/27.8
T 17.7/28.8
T 19.4/30.7
B 11.5/16.8
T 24.7/40.1
T 21.1/40.1
T 24.7/39.1
B 17.2/39.1
B 17.7/40.4
B 18.7/40.4
T 19.4/29.8
B
T 34.7/18.9
T
T
T
T 23.9/10.9
T
T 23.9/11.9
T 23.9/12.9
T 25.7/12.9
T 25.7/14.9
T 23.9/14.9
T
T
T
T
T
T
T
T
T
T
B 15.9/23.3
B 66.5/13.7
B
B
B 75.5/10.3
B
T 94.9/13.9
T 94.2/15.2
T
T 87.2/17.2
T
T
T
B
B
B
T 21.1/39.1
B
T 99.7/12.9
[2CH] only T
[2CH] only T
B
B
B
B
T
T
T
T 21.6/22.1
T
T 19.4/19.9
T 21.3/13.9
T 21.3/12.9
T 21.3/10.9
T
T
B
B
B
B
B
B
B
B
B 16.2/36.2
B
T
T 14.7/22.7
B
B
T 61.4/43.4
T 60.4/43.4
B 95.1/43.4
B 91.8/35.3
T 91.3/36.2
B 93.1/22.4
T 93.3/34.9
T 32.8/20.3
T 33.6/21.8
[High band] B 94.2/41.5
[Low band] B 94.2/41.5
[Low band] B
[High band] B
[High band] B 96.5/33.9
[Low band] B 96.5/33.9
B 94.9/33.9
S.=Surface mount
H/V
9/18.2
18/4.1
18/5.1
18/6.1
19.7/4.1
13.4/4.1
13.4/5.1
15.6/5.1
15.6/6.1
15.6/4.1
27.1/4.1
27.1/5.1
27.1/6.1
29.1/7.1
31/6.1
63.9/8.5
61/11.3
33.9/7.1
86/9.7
90.6/2.8
93.2/4.4
92.7/2.8
23.3/6.2
20.3/4.2
23.3/5.2
40.9/9.5
39.4/6.4
41.4/6.4
5.9/9.1
13.7/9.1
9.3/10.1
7.6/10.1
6/8.6
9/22.1
6.6/20.6
21.5/25
19.7/9.2
5.7/18.8
10/39.3
11/39.3
12/39.3
15/39.3
13/39.3
8/39.3
9/39.3
14/39.3
16.3/27
18.4/24
5.9/12.5
7.6/12.5
93.2/36
93.2/36
