Adjusting the Throttle Cable

1. Make sure the adjustment nut on the throttle cable is functioning correctly.
2. Check the movement of throttle turning grip is in the desired value.
3. The desired value of the throttle grip is 2-6mm. If it is out of these
measurements please turn the nut to adjust.
Locknut Adjusting nut
Warning
After adjustment, check the throttle grip. Do not increase the idle speed of engine,
and make sure the throttle grip turns automatically to the "Close" position.

Fine tuning the carburetor

1. This motorcycle has passed the state III standard. It is already finely tuned to
this standard.
2. Make sure the engine is hot when you tune the carburetor.
3. Ensure that the motorcycle is on flat ground, adjust the idle by turning the
idle screw.
Idling speed is: 1500+150r/min
Idling screw
25
