MiLAN MIL-225C Installation Manual

R eg ul at or y Ap p rovals
• FCC Class A
• UL 1950
• CSA 22 No. 950
• EN60950
• CE
– EN55022 Class B
– EN50082-1
C an ad ia n EMI No t ice
This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel
brouilleir du Canada.
Europe an Not ice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low
Voltage Directive (73/23/EEC) issued by the commission of the European Community. Compliance
with these directives implies conformity to the following European Norms:
• EN55022 (CISPR 22) - Radio Frequency Interference
• EN50082-1 (IEC801-2, IEC801-3, IEC801-4) - Electromagnetic Immunity
• EN60950 (IEC950) - Product Safety
Five-Year Limited Warranty
MiLAN Technology warrants to the original consumer or purchaser that each of its products,
and all components thereof, will be free from defects in material and/or workmanship for a
period of five years from the original factory shipment date. Any warranty hereunder is
extended to the original consumer or purchaser and is not assignable.
MiLAN Technology makes no express or implied warranties including, but not limited to, any
implied warranty of merchantability or fitness for a particular purpose, except as expressly set
forth in this warranty. In no event shall MiLAN Technology be liable for incidental or
consequential damages, costs, or expenses arising out of or in connection with the performance
of the product delivered hereunder. MiLAN Technology will in no case cover damages arising
out of the product being used in a negligent fashion or manner.
To C ont act MiL AN Tech n ol o g y
For prompt response when calling for service information, have the following information ready:
• Product serial number and rev.
• Date of purchase
• Vendor or place of purchase
You can reach MiLAN Technical Support at 408/744-2751
Or E-mail at support@milan.com
Address: 1299 Orleans Drive
Sunnyvale, CA 94089
Voice: 408/744-2775
Fax: 408/744-2793
Web: www.milan.com
® Copyright 1997 MiLAN Technology Printed in the USA P/N: 90000063 Rev. B
MIL-225C
100BaseFX/OC-3
Single-mode to Multi-mode
Fiber Converter

Installation Guide

Multi-mode to Single-mode
and
Single-mode to Multi-mode
This guide includes the following information:
• "Introduction" on page 2
• "Installation" on page 3
• "Theory of Operation" on page 4
• "Specification" on page 5
Installation Guide MIL-225C
