MiLAN MIL-C2112 Installation Manual

Regulatory Approval

•
FCC Class A
• UL 1950
• CSA C22.2 Number 950
• EN60950
• CE
- EN55022 Class B
- EN50082-1

Canadian EMI Notice

This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numerique de la classe A respecte toutes les exigences du Reglement sur le materiel brouilleur du Canada.

European Notice

Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage
Directive (73/23/EEC) issued by the commission of the European Community Compliance with these directives
implies conformity to the following European Norms:
EN55022 (CISPR 22) - Radio Frequency Interference
•
EN50082-1 (IEC801-2, -3, -4) - Electromagnetic Immunity
•
EN60950 (IEC950) - Product Safety
•

Five-Year Limited Warranty

MiLAN Technology warrants to the original consumer or purchaser that each of it's products, and
all components thereof, will be free from defects in material and/or workmanship for a period of
five years from the original factory shipment date. Any warranty hereunder is extended to the
original consumer or purchaser and is not assignable.
MiLAN Technology makes no express or implied warranties including, but not limited to, any
implied warranty of merchantability or fitness for a particular purpose, except as expressly set
forth in this warranty. In no event shall MiLAN Technology be liable for incidental or
consequential damages, costs, or expenses arising out of or in connection with the performance
of the product delivered hereunder. MiLAN Technology will in no case cover damages arising
out of the product being used in a negligent fashion or manner.
Trademarks
© 2000 MiLAN, the MiLAN logo and MiLAN Technology are either trademarks or registered
trademarks of Digi International, Inc. in the United States and/or other countries. All other
trademarks are the property of their respective holders.
To Contact MiLAN Technology
For prompt response when calling for service information, have the following information ready:
•
Product serial number and revision
• Date of purchase
• Vendor or place of purchase
You can reach MiLAN Technology technical support at:
E-mail: support@milan.com
Telephone: +1.408.744.2751
Fax: +1.408.744.2771
MiLAN Technology
1299 Orleans Drive
Sunnyvale, CA 94089-1138
United States of America
Telephone: +1.408.744.2775
Fax: +1.408.744.2793
http://www.milan.com
info@milan.com
© Copyright 2000 MiLAN Technology
.
Printed in the USA P/N: 90000209 Rev. A
ST - Type
Connector
The MIL-C2112 comes equipped with ST-type connectors and
supports Fast Ethernet in both half and full-duplex mode. For
network budget constraint, the MIL-C2112 uses 150 nanoseconds
(approximately 30 meters of cable) during conversion in each
direction.
To maximize the fiber cable distance, use one meter of category 5
(CAT 5) UTP cable when connecting directly to a node (subject to
fiber budget of 16dBm and collision domain restrictions). In full-
duplex environments, up to 100m of CAT 5 UTP and 2Km of
1300 nm multi-mode fiber cable can be used.
-Launch power: -19dB
-Receive sensitivity: -30dB
Installation Guide: MIL-C2112
LEDs
RJ-45
Connector
