Status Reporting Registers (Read Only) - Danfoss VLT Soft Starter MCD 600 Installation Manual

Modbus RTU Card
Installation Guide
Register Description
40002 Reserved
40003 Reserved
40004 Reserved
40005 Reserved
40006 Reserved
40007 Reserved
40008 Reserved
40009–40xxx Parameter management (single
or multiple read/ write)

5.5.2 Status Reporting Registers (Read Only)

For models MCD6-0063B and smaller (soft starter model ID 1~4), the current and frequency reported via communications regis-
ters are 10 times greater than the actual value.
Table 3: Description of Read Registers
Register Description
30003 Reserved
30004 Reserved
30005 Reserved
30006 Reserved
30007 Reserved
30008 Reserved
30600 Version
30601 Model number
30602 Changed parameter number
10 | Danfoss A/S © 2022.11
Bits Details
10000000 = Reserved
8–14 Reserved
15 Must = 1
0–15 Manage soft starter programmable parameters. See the VLT® Soft Start-
er MCD 600 Operating Guide for a complete parameter list.
N O T I C E
Bits Details
0–5 Binary protocol version
6–8 Parameter list major version
9–15 Product type code: 15 = MCD 600
0–7 Reserved
8–15 Soft starter model ID
0–7
0 = No parameters have changed
1–255 = Index number of the last parameter changed
8–15 Total number of parameters available in the soft starter
Modbus Registers
