NB3720
User Manual for NRSW version 4.4
Administration
HOME INTERFACES
OpenVPN
Administration
Tunnel Configuration
Client Management
IPsec
Administration
Tunnel Configuration
PPTP
Administration
Tunnel Configuration
Client Management
GRE
Administration
Tunnel Configuration
L2TP
Administration
Tunnel Configuration
NetModule Router Simulator
Hostname NB1600
Software Version 4.4.0.103
© 2004-2020, NetModule AG
This page can be used to enable/disable IPsec, you may also specify whether NAT-Traversal should
be used.
NAT-Traversal is mainly used for connections which traverse a path where a router modifies the IP
address/port of packets. It encapsulates packets in UDP and therefore requires a slight overhead
which has to be taken into account when running over small-sized MTU interfaces.
Please note that running NAT-Traversal makes IKE using UDP port 4500 rather than 500 which has to
be taken into account when setting up firewall rules.
ROUTING FIREWALL VPN SERVICES

IPsec Administration

IPsec administrative status:
Propose NAT traversal:
Restart on link change:
Apply Restart
Figure 5.31.: IPsec Administration
106
SYSTEM
enabled
disabled
