Technical Specifications
This section details the specifications and operating conditions of the device.
5.1
Power Supply Specifications
Supply Type
12–24 VDC
HI (125/250
HI (110/230
a
(T) denotes time-delay fuse.
b
This is the same power supply for both AC and DC.
5.2
Failsafe Alarm Relay Specifications
Maximum Switching Voltage
5.3
Copper Ethernet Port Specifications
Data Port
Media
Distance
Connector Type
RUGGEDCOM M969F
Installation Manual, 11/2022, C79000-G8976-1349-04
Power
Minimum
Input
10 VDC
24 VDC
18 VDC
48 VDC
36 VDC
88 VDC
b
VDC)
85 VAC
b
VAC)
30 VDC
125 VDC
125 VAC
220 VDC
250 VAC
10/100 Mbps
CAT-5 UTP or STP
100 m (328 ft)
RJ45 or M12
Maximum
Internal
Input
Fuse Rating
36 VDC
3.15A (T)
36 VDC
72 VDC
300 VDC
265 VAC
Rated Switching Current
2 A, 60 W
0.24 A, 30 W
0.5 A, 62.5 W
0.24 A, 60 W
0.25 A, 62.5 W
Isolation
Maximum
Consumption
a
1.5 kVDC
4 kVAC
5.5 kVDC
Isolation
1500 V
for 1 minute
rms
5
Power
10 W
23
