1.3 Hardware Overview
The router case preview is shown in Figure 5. A short description of hardware parts of the
router is listed in Table 1, including the links to the chapters with a detailed description.
#
Item/CaptionType
1
LEDs
-
2
RST
-
3
PWR
2-pin
4
ETH0,
RJ45
ETH1
5
DIV, ANT
SMA
6
WiFi,
SMA,
GNSS
R-SMA
7
DIN clip
-
8
Grounding
M3
screw
9
SIM slots
Mini SIM
10
SERIAL |
10-pin
I/O
terminal
11
Wall clips
-
Figure 5: Hardware Overview of the Router
Description
Status LED indication; see Chapter 2.7.
Button to reboot the router or to restore the default
configuration; see Chapter 2.8.
Power supply 2-pin terminal socket; see Chapter 2.4.
100 MB Ethernet connection for the firts and second LAN; see Chap-
ter 2.3.
Connector for the diversity and main antennas of the cellular module;
see Chapter
2.2
and Chapter
One SMA connecor for the GNSS antenna and two R-SMA connectors
for the WiFi antennas. See Chapter
ter
4.5
for GNSS parameters and Chapter
DIN rail clip, included as standard accessories; see Chapter 1.11.
Pay attention to proper grounding; see Chapter 2.4.
Two SIM card slots; see Chapter 2.1.
RS232, RS485, binary inputs, and binary outputs interfaces. See Chap-
ter
2.6
for more information.
Wall mounting clips, included as standard accessories; see Chap-
ter 1.10.
Table 1: Hardware Overview of the Router
5
ICR-3231
4.4
for cellular module parameters.
2.2
for more information, Chap-
4.6
for WiFi parameters.
