- Page 1 AirSpeed 1000A Installation Guide Part Number: DUG01289 Revision: A12 Published: May 2023...
- Page 2 No responsibility is assumed by Airspan Networks Ltd. for the use of the documents nor for the rights of third parties which may be effected in any way by the use thereof. The provision of these documents (and the documents themselves) does not constitute professional advice of any kind.
-
Page 3: Table Of Contents
Maximum Output TX Power ..............8 Product Variants ....................8 Power Consumption ....................8 External Antennas ....................9 About This Document ................10 Purpose ........................ 10 Intended Audience ....................10 Document Conventions ..................10 DUG01289 Airspan Commercial and Internal Use... - Page 4 1.1 AirSpeed 1000A .................... 13 2 Getting Started ................... 14 2.1 Workflow of Installation ................. 14 2.2 AirSpeed 1000A Installation Checklist ............14 3 Verifying Prerequisites ............... 15 3.1 Verifying Site Requirements ................15 3.2 Verify Installation Requirements ..............15 3.2.1 Verify the Tools ....................
- Page 5 Figure 13: Ethernet Cable through Connector ..................26 Figure 14: Power Cable Attached ......................27 Tables Table 1: AirSpeed 1000A ETSI Maximum Output TX Power ..............8 Table 2: AirSpeed 1000A FCC Maximum Output TX Power ..............8 Table 3: Supported Frequency Bands ....................8 Table 4: Power Consumption ........................
-
Page 6: Document Information
AirSpeed 1000A Installation Guide Document Information Abstract This document details procedures for installing the Airspan’s AirSpeed 1000A Pico-class LTE eNodeB variant. Revision History Revision Details Date Summary of Changes Rev 0.1 – 0.2 August 2017 • Initial document – draft(s) •... -
Page 7: Warnings And Cautions
Avertissement et Precautions d’Utilisation Exposition des personnes aux fréquences radioélectriques Les AirSpeed 1000A doivent être installée et utilisée de façon à garantir la distance minimale de sécurité de 20 cm (7.87 in.). Radio Interference This AirSpeed 1000A generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 8: Important Safety Instructions
Toute enfreinte a ces obligations peut annuler la garantie délivrée par Airspan pour ces produits et peut exposer l’utilisateur final ou le fournisseur de services a des dommages légaux et financiers. -
Page 9: Warning Of Hazardous Voltages
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances Regulations 1990). At the end of any Airspan products life cycle, the customer should consult with Airspan to ensure that the product is disposed of in conformance with the relevant regulatory requirements. -
Page 10: Ul Information
This equipment is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Español: Por medio de este Airspan, declara que la unidad cumple con los requisitos esenciales y cualquier otra disposición aplicable o exigible de la Directiva 2014/53 / UE. Greek: ΜΕ... - Page 11 2014/53 / EU. Íslenska: Airspan lýsir hér með yfir að þessi eining uppfylli grunnkröfur og aðrar kröfur tilskipunar 2014/53 / ESB. Norsk: Airspan erklærer herved at utstyrsenheten oppfyller grunnleggende krav og andre relevante krav i direktiv 2014/53 / EU.
-
Page 12: Maximum Output Tx Power
(dBi) 3550-3700 23.08 1000 Note: The AirSpeed 1000A requires operation using an Airspan FCC-specific version of Netspan acting as a CBRS Domain Proxy. Caution: Do not set maximum output TX total power to higher than local regulations. Product Variants AirSpeed supports the following frequency bands with the specific performance values:... -
Page 13: External Antennas
AirSpeed 1000A Installation Guide External Antennas AirSpeed 1000A connects to the external antennas via four (4) N-Type female connectors located at the top panel. The antenna should be mounted to its appropriate mounting facility. The supported antennas must be dual slant, cross polar, DC grounded antennas. -
Page 14: About This Document
Install the AirSpeed 1000A Connect and manage cables Intended Audience This guide is intended for persons who are responsible for installing the AirSpeed 1000A equipment. Document Conventions This document uses the following typographic conventions. Table 5: Typographic Conventions... -
Page 15: Related Reading
AirSpeed 1000A Installation Guide Related Reading The following documents contain related information: AirSpeed 1000A Product Datasheet • Airspan LTE Commissioning Manual • DUG01289 Airspan Commercial and Internal Use... -
Page 16: Customer Care Help Desk
Customer Care Help Desk Airspan’s Customer Care Help Desk offers prompt and efficient customer support services. Note: To avail Airspan’s Customer Care Help Desk support, you must be a registered user and must have a valid support contract. To register, click here and fill the Registration form. -
Page 17: Introduction
AirSpeed 1000A is a Pico-class LTE eNodeB product, providing high-speed data, mobility, Voice over LTE, and broadcast/multicast services. AirSpeed 1000A is a super compact, easy to install Pico-class eNodeB. Allowing an operator to deploy LTE broadband services on any Street Furniture, rooftop or building front AirSpeed 1000A is a dual sector / carrier 2x2 MIMO product. -
Page 18: Getting Started
The Workflow to install the AirSpeed 1000A is displayed in the following diagram: Figure 3: Workflow 2.2 AirSpeed 1000A Installation Checklist Plan the installation of the AirSpeed 1000A by using the Installation Checklist, which you can find as a removable job aid in Appendix B for this guide. -
Page 19: Verifying Prerequisites
Tightening cable glands - To fit 15 mm Note: Airspan does not provide screws and wall anchors for mounting the unit to the wall. The screw size depends on the structure of the building to which the unit is to be attached. When selecting screw sizes, consideration must be given to the weight of the unit and load that may be induced in windy conditions. -
Page 20: Verify The Parts And Kits
(210 mm) pole GPS antenna Power Cable PWR-10- 454-0010-225 CBL assy, 48V,10m, EXT, Assembly INST-2 UNTERM, SCRT – 10 meters Note: Additional power cable lengths are available, please contact your Airspan sales representative. DUG01289 Airspan Commercial and Internal Use... -
Page 21: Power Supply
For more details on the offered AC/DC converter (sold separately), please contact your nearest Airspan sales representative. 3.2.4 Connections The following diagrams display the connections on the top and bottom panels of the AirSpeed 1000A. Note: The unit requires a secure ground connection and a grounding screw fitted with a flat washer and lock washer is provided on the back and clearly marked with the universal ground symbol. -
Page 22: Physical Dimensions
1 Kg. / 2.2 Lbs. (Bracket Base) 3.2.6 Environmental Note: AirSpeed 1000A is not meant to be used in a Marine environment. AirSpeed 1000A meets the following environmental requirements: IEC 60529 IEC 60068 ETSI EN 300-019-2-4 Operational (non-weather protected equipment) ... -
Page 23: Table 9. Airspeed 1000A Environment Compliance
AirSpeed 1000A Installation Guide Table 9. AirSpeed 1000A Environment Compliance Type Details Operating temperature -40°C to 55°C / -40°F to 131°F Operating humidity 5% - 100% non-condensing Storage temperature -40°C to 70° C / -40°F to 158°F Storage humidity 5% - 100% non-condensing... -
Page 24: Airspeed 1000A Installation
Wall mounting The AirSpeed 1000A Mounting Kit - includes a pole/wall mounting bracket for fastening the unit to a pole or on a wall. Prior to installation of the AirSpeed unit the mounting bracket must first be affixed in place on either the pole or a wall. -
Page 25: Pole Mounting Assembly
4.2 Pole Mounting Assembly Caution: Mount the AirSpeed 1000A unit in an orientation such that its Ethernet port (located on the bottom) face downwards. This prevents rain water from settling on the port, and thereby, avoiding damage to the unit such as corrosion and electrical short–circuiting. -
Page 26: Figure 7: Pole Mounting Assembly
AirSpeed 1000A Installation Guide Figure 7: Pole Mounting Assembly Figure 8: Mounted on Pole DUG01289 Airspan Commercial and Internal Use... -
Page 27: Wall Mount Assembly
4.3 Wall Mount Assembly The following describes the wall mounting procedure: 1. Select the location on the wall to mount the AirSpeed 1000A mounting bracket. 2. Assemble the 2 SEMS screws (M8 x 20) into the lower threaded holes on the mounting (base) bracket, do not tighten. -
Page 28: Led Display
4.4 LED Display The LEDs on the panel on the bottom of the unit, provides unit status indication. When powering up refer to the following table for indication of current status: Table 10. AirSpeed 1000A LED Behavior “During Startup” State Name Color... -
Page 29: Connect And Manage Cables
5.1 Grounding The AirSpeed 1000A requires a secure ground connection and a grounding screw fitted with a flat washer and lock washer is provided on the back and clearly marked with the universal ground symbol The cable should be grounded and bonded according to international or local standards. -
Page 30: Ethernet Cable Installation
Do not tighten the tail nut. Figure 13: Ethernet Cable through Connector Seat (click) the RJ45 connector plug securely into the AirSpeed 1000A. Tighten the Gland body into to the stand-off on unit. Tighten the tail nut on to the body, forcing the seal to compress around the cable. -
Page 31: Figure 14: Power Cable Attached
AirSpeed 1000A Installation Guide Plan the position of the DC power cable run from the AirSpeed 1000A unit to the power supply. The DC power cable is offered in various lengths, to fit different deployments. Uncoil the cable and secure the connector to the connector on the bottom panel of the AirSpeed 1000A unit. -
Page 32: A Job Sheet
AirSpeed 1000A Installation Guide A Job Sheet This job sheet enables the users to keep track of their installation. It covers all the prerequisites required for accomplishing the AirSpeed 1000A installation. Site Requirements Position on Pole / Wall Access restrictions (local regulations) (when applicable) -
Page 33: B Checklist
B Checklist During installation, review and perform all the steps on this checklist (in the given order). This checklist is meant for the person who performs the AirSpeed 1000A installation. Tip: To make sure you complete all the tasks, detach or print this checklist and use it as a job aid. -
Page 34: C Abbreviations
AirSpeed 1000A Installation Guide C Abbreviations Table 12: ABBREVIATIONS & DEFINITIONS Term Expansion 3GPP 3rd Generation Partnership Project, responsible for LTE Additive White Gaussian Noise is a channel model in which the only impairment to AWGN communication is a linear addition of white noise with a constant spectral density and a Gaussian distribution of amplitude. - Page 35 AirSpeed 1000A Installation Guide Term Expansion MTBF Mean Time Between Failures Network Listening Orthogonal Frequency-Division Multiple Access (OFDMA) is a multiple access OFDMA version of OFDM digital modulation scheme, used for eNodeB transmissions to Protocol Data Unit Precision Time Protocol is used to synchronize clocks throughout a network. In this...
